Electric angle nutrunner

Advertisement

Quick Links

Printed Matter No. 9839 1266 01
Publication Date 2021-07-13
Valid from Serial No. G0530001
Valid to Serial No. G3619999
QST62-600CTV-H25
(120-600 Nm)
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
QST62-600CTV-H25
9831408702
WARNING
Electric angle nutrunner
Product Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QST62-600CTV-H25 and is the answer not in the manual?

Questions and answers

Summary of Contents for Atlas Copco QST62-600CTV-H25

  • Page 1 QST62-600CTV-H25 Printed Matter No. 9839 1266 01 Electric angle nutrunner Publication Date 2021-07-13 Valid from Serial No. G0530001 Product Instructions Valid to Serial No. G3619999 QST62-600CTV-H25 9831408702 (120-600 Nm) WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
  • Page 2: Table Of Contents

    Installation ....................... 6 Installation requirements................... 6 Clamping .................... 6 Motor connector.................. 6 Compression spring................ 6 Service ........................ 7 Preventing ESD problems ................ 7 Maintenance instructions .................. 7 Service recommendations .............. 7 Recycling ......................... 8 Recycling instruction.................. 8 Recycling information for QST (230-1750Nm).......... 8 © Atlas Copco Industrial Technique AB - 9839 1266 01...
  • Page 3: Product Information

    ■ Damage to parts that occurs as a result of inadequate maintenance or performed by parties other than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the warranty. ■ To avoid damage or destruction of tool parts, service the tool according to the recommended mainte- nance schedules and follow the correct instructions.
  • Page 4: Servaid

    ServAid is continuously updated and is available at: https://servaid.atlascopco.com For further information contact your local Atlas Copco representative. Safety Data Sheets MSDS/SDS The safety data sheets describes chemical products sold by Atlas Copco. For more information, consult the website: www.atlascopco.com/sds Country of origin Please refer to the information on the product label.
  • Page 5: Service Overview

    If the product is not working properly, take it out of service and inspect it. If no detailed information about preventive maintenance is included, follow these general guidelines: ■ Clean appropriate parts accurately ■ Replace any defective or worn parts © Atlas Copco Industrial Technique AB - 9839 1266 01...
  • Page 6: Installation

    The motor connector is rotatable ± 150 degrees along two axes. Compression spring The QST nutrunners are delivered with two springs. The strong spring is built in the front part. © Atlas Copco Industrial Technique AB - 9839 1266 01...
  • Page 7: Service

    If the product is not working properly, take it out of service and inspect it. If no detailed information about preventive maintenance is included, follow these general guidelines: ■ Clean appropriate parts accurately ■ Replace any defective or worn parts © Atlas Copco Industrial Technique AB - 9839 1266 01...
  • Page 8: Recycling

    Front part Metal, Steel Transducer Metal, Steel 2 Covers Metal, Steel Cable rail Metal, Zink 2 Screws Metal, Steel Cable Electronic Gear unit Metal, Steel 3 Hex socket screws Metal, Steel © Atlas Copco Industrial Technique AB - 9839 1266 01...
  • Page 9 QST62-600CTV-H25 Recycling Part: Recycle as: Motor Electronic Motor (back part) Metal, Aluminum Communication card tube Metal, Stainless steel Communication card Electronic Connector Electronic © Atlas Copco Industrial Technique AB - 9839 1266 01...
