HIKVISION DS-KH9310-WTE1 User Manual

DS-KH9310-WTE1
Android Indoor Station
E N G L I S H
1
Diagram References
Appearance
1
1 Screen
5 Alarm Terminals
9 Loudspeaker
Note: The appearance of the device varies according to different models. Refers to the actual device for detailed
information.
Terminal
2
AIN1: Alarm Input 1
AIN2: Alarm Input 2
AIN3: Alarm Input 3
AIN4: Alarm Input 4
NO1/NO2: Normally Open
COM1/COM2: Common Interface
2
3
RS485-/RS485+: RS-485 Communication Interface
Note: For Wiring description, refers to the User Manual.
Installation
3
122
92
Mounting Accessories
The wall mounting plate and the gang box are required to install the indoor station onto the wall.
There are 2 sizes of the gang boxes adapted to the device.
Size 1: 75 mm (width) × 75 mm (length) × 46 mm (depth).
Size 2: 55 mm (width) × 101 mm (length) × 38.5 mm (depth).
Before you begin:
Make sure the device in the package is in good condition and all the assembly parts are included.
The power supply of the indoor station is 12 VDC. Make sure your power supply matches your indoor
station.
Make sure all related equipments are power-off during the installation.
Check the product specification for the installation environment.
Wall Mounting with Gang Box
RS485-
1. Cave a hole in the wall.
3
RS485+
Note: The suggested dimension of the installation hole should be larger than the gang box.
2. Insert a gang box to the hole chiseled on the wall.
3. Fix the wall mounting plate to the gang box with 2 screws.
COM2
Notes：
Lock Catch
If you install the device with a gang box (75 mm (width) × 75 mm (length) × 46 mm (depth)), the upper and lower holes
NO2
will be applies.
If you install the device with a gang box (55 mm (width) × 101 mm (length) × 38.5 mm (depth)), the upper and lower
COM1
holes will be applies.
4. Hook the indoor station to the wall mounting plate tightly by inserting the plate hooks into the slots on
NO1
the rear panel of the indoor station, during which the lock catch will be locked automatically.
Getting Started
4
Activate Indoor Station
Lock Catch
1
RS485/Relay Interface
You are required to activate the device first by setting a strong password before
Rear Panel (without Interface)
you can use the device.
Note: If you use the gang box (75 mm (width) × 75 mm (length) × 46 mm (depth)) to install, you should set the screws to up and down screw holes.
1. Power on the device. It will enter the activation page automatically.
2. Create a password and confirm it.
2 Microphone
6 RS-485/Relay Interface
10 Reserved
3
1.5
Unit:mm
Lock Catch
Lock Catch
Hangzhou Hikvision Digital Technology CO.,Ltd. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China
UD19189B
3 Unlock Button
7 Debugging Port
11 TAMPER
1
6
AIN5: Alarm Input 5
AIN6: Alarm Input 6
2
AIN7: Alarm Input 7
AIN8: Alarm Input 8
GND: Grounding
Rear Panel (without Interface)
Note: If you use the gang box (55 mm (width) × 101 mm (length) × 38.5 mm (de
Hook
Hook
Hook
Hook
Alarm Terminals
Screw Wall Mounting Plate
4 5
4 Power Supply Interface
8
12 Network Interface
7 8 12
Lock Catch Lock Catch
Lock Catch Lock Catch
Gang Box Wall
microUSB Interface
9
10
11
Hook
AIN8
AIN7
AIN6
Hook
Ho
AIN5
AIN4
Screw Wall Moun
AIN3
AIN2
AIN1
GND
GND
