  • Page 1 Video Intercom Main Station Operation Guide...
  • Page 2 WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,...
  • Page 3 Video Intercom Main Station Operation Guide CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS. YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR INHERENT SECURITY RISKS, AND HIKVISION SHALL NOT TAKE ANY...
  • Page 4 Video Intercom Main Station Operation Guide Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or Danger could result in death or serious injury. Indicates a potentially hazardous situation which, if not Caution avoided, could result in equipment damage, data loss,...
  • Page 5 Video Intercom Main Station Operation Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 6 Video Intercom Main Station Operation Guide EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, LVD Directive 2014/35/EU, the RoHS Directive 2011/65/EU.

  • Page 7: Table Of Contents

    Video Intercom Main Station Operation Guide Contents 1 Appearance ....................1 2 Terminal Description .................. 4 3 Installation ....................6 3.1 Table Bracket(Optional) ..................6 3.2 Accessory Installation(Optional) ............... 6 3.2.1 Install Speaker ..................6 3.2.2 Install Goose Neck Microphone ..............8 3.3 Wall Mounting ....................
  • Page 8 Video Intercom Main Station Operation Guide 5.3 Release Notice ....................17 5.4 Search Video Intercom Information ..............19 5.4.1 Search Call Logs ..................19 5.4.2 Search Notice ..................21 A. Communication Matrix and Device Command ........23...

  • Page 9: Appearance

    Video Intercom Main Station Operation Guide 1 Appearance Front Panel Figure 1-1 Front Panel Table 1-1 Description Description Description Phone Camera Phone Screen Indicator(Reserved) Power Indicator Call/Hang Up Button Alarm Indicator Unlock Button Information Indicator Speaker Button Microphone...
  • Page 10 Video Intercom Main Station Operation Guide Note You can hold the unlock button to unlock lock 1, and press the unlock button to unlock lock 2. Top Panel and Rear Panel Figure 1-2 Top Panel and Rear Panel Table 1-2 Description Description Description Goose Neck Microphone...
  • Page 11 Video Intercom Main Station Operation Guide Speaker(Optional) Figure 1-3 Speaker Table 1-3 Description Description Description 1 S peaker Fingerprint Module...

  • Page 12: Terminal Description

    Video Intercom Main Station Operation Guide 2 Terminal Description Figure 2-1 Terminal Description Table 2-1 Terminal Description Name Interface Description Video Interface HDMI HDMI Signal Output USB Interface USB 1 USB Interface Note USB 2 USB3 is used to debugging only. It cannot USB 3 connect to USB flash drive.
  • Page 13 Video Intercom Main Station Operation Guide Name Interface Description Grounding Network LAN1(PoE) Network Interface (Support PoE) Interface LAN2 Network Interface (Reserved)

  • Page 14: Installation

    Video Intercom Main Station Operation Guide 3 Installation • Make sure the device in the package is in good condition and all the assembly parts are included. • The power supply the door station support is 12 VDC. Please make sure your power supply matches your door station.
  • Page 15 Video Intercom Main Station Operation Guide Steps 1. Loose 2 screws on the rear panel of the device. Figure 3-2 Loose the screws 2. Remove the cover from the device and install the speaker to the main station. Figure 3-3 Install the Speaker 3.

  • Page 16: Install Goose Neck Microphone

    Video Intercom Main Station Operation Guide Figure 3-4 Secure the Speaker Note • The speaker and earphone can not be used at the same time. If you want to use the earphone, you should remove the speaker. • When using earphones, the small size of the earphone plug should be selected.

  • Page 17: Wall Mounting

    Video Intercom Main Station Operation Guide Figure 3-5 Install the Goose Neck Microphone 3.3 Wall Mounting Before You Start Note • Tools that you need to prepare for installation: Drill (6). • Make sure all the related equipment is power-off during the installation. Steps 1.
  • Page 18 Video Intercom Main Station Operation Guide Figure 3-6 Wall Mounting 3.4 Table Mounting Steps 1. Wiring the device and smooth the cables across the cable hole. Figure 3-7 Smooth the Cable 2. Adjust the table bracket to the right angle and put the device on the right position.

  • Page 19: Local Operation

    Video Intercom Main Station Operation Guide 4 Local Operation 4.1 Call Settings 4.1.1 Call Resident Call the indoor station via the main station. Steps 1. Tap Call → to enter the call page. Figure 4-1 Call Page 2. Enter the calling number to call. Note •...

  • Page 20: View Call Logs

    Video Intercom Main Station Operation Guide When the main station receives the call from the other device, tap the receive call button to receive the call. Or tap the hang up button to end the call. During the call, you can tap the unlock button to unlock the door remotely. Note The maximum call duration between the main station and the indoor station is 120 4.1.3 View Call Logs...

  • Page 21: The Third-Party App Settings

    Video Intercom Main Station Operation Guide Steps 1. Tap Live View on the main page. Figure 4-3 Live View Page 2. View the live videos of other devices. 3. Optional: Tap the unlock button to unlock the door. 4.3 The Third-Party App Settings 4.3.1 Install the App Install the third-party App to your device.

  • Page 22: Uninstall The App

    Video Intercom Main Station Operation Guide Figure 4-4 Add the Third-Party Apps 4. Tap New APP to view the details. 5. Optional: Tap the added third-party app, and tap Clear Memory to clear the app's memory or uninstall the app. 4.3.2 Uninstall the App Steps 1.
  • Page 23 Video Intercom Main Station Operation Guide Take viewing alarm logs as an example. Tap Message → and you can view all received alarm logs. Hold one of the logs to clear all logs or delete the selected log. Note Up to 200 alarm logs, 200 captured pictures, 200 recorded videos, 200 recorded audios can be viewed.

  • Page 24: Remote Operation Via The Client Software

    Video Intercom Main Station Operation Guide 5 Remote Operation via the client software The Video Intercom module provides remote control and configuration on video intercom products via the iVMS-4200 client software. 5.1 View Live Video of Door Station and Outer Door Station You can get the live view of the door station and outer door station in the Main View module and control the door station and outer door station remotely.

  • Page 25: Release Notice

    Video Intercom Main Station Operation Guide Figure 5-1 Call Log 3. Optional: Click the icon in the Operation column to re-dial the resident. 5.3 Release Notice You can create different types of notices and send them to the residents. Four notice types are available, including Advertising, Property, Alarm and Notice Information.
  • Page 26 Video Intercom Main Station Operation Guide Figure 5-2 Release Notice 3. Click Add on the left panel to create a new notice. Figure 5-3 Create a Notice 4. Edit the notice on the right panel.

  • Page 27: Search Video Intercom Information

    Video Intercom Main Station Operation Guide 1) Click ... on the Send To field to pop up the Select Resident dialog. 2) Check the checkbox(es) to select the resident(s). Or you can check the All checkbox to select all the added residents. 3) Click OK to save the selection.
  • Page 28 Video Intercom Main Station Operation Guide Steps 1. On the main page, click Access Control → Video Intercom to enter the Video Intercom page. 2. Click Call Log to enter the Call Log page. Figure 5-4 Search Call Logs 3. Set the search conditions, including call status, device type, start time and end time.

  • Page 29: Search Notice

    Video Intercom Main Station Operation Guide • Check the detailed information of searched call logs, such as call status, ring/ speaking duration, device name, resident organization, etc. • Input keywords in the Search field to filter the desired log. • Click Export to export the call logs to your PC.
  • Page 30 Video Intercom Main Station Operation Guide 4. Optional: You can click Reset to reset all the configured search conditions. 5. Click Search and all the matched notices will display on this page. • Check the detailed information of searched notices, such as sending time, sending status, etc.

  • Page 31: Communication Matrix And Device Command

    A. Communication Matrix and Device Command Communication Matrix Scan the following QR code to get the device communication matrix. Note that the matrix contains all communication ports of Hikvision access control and video intercom devices. Figure A-1 QR Code of Communication Matrix Device Command Scan the following QR code to get the device common serial port commands.
  • Page 32 UD21586B...
