Ameriwood HOME 7983339COMS Instruction Booklet
  1. Manuals
  2. Brands
  3. Ameriwood HOME Manuals
  4. Indoor Furnishing
  5. 7983339COMS
  6. Instruction booklet
Ameriwood HOME 7983339COMS Instruction Booklet

Ameriwood HOME 7983339COMS Instruction Booklet

Queen wall bed, bay oak
Hide thumbs

Advertisement

Quick Links

Download this manual
7983339COMS (Bay Oak)
Queen Wall Bed
Date of Purchase ___ / ___ / ___
Lot Number:
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Visit: www.dorelhome.com
to view the limited warranty valid
in the U.S. and Canada.
THIS INSTRUCTION BOOKLET CONTAINS WARNINGS AND
PRODUCT SAFETY INFORMATION. DO NOT PROCEED WITHOUT
REVIEWING THOUROUGHLY. FOR ANY QUESTIONS, CONTACT
CUSTOMER SERVICE.
Difficulty Meter
Easy
B347983339COMS0
Professional
(see page 2)

Advertisement

loading
Need help?

Need help?

Do you have a question about the 7983339COMS and is the answer not in the manual?

Questions and answers

Related Manuals for Ameriwood HOME 7983339COMS

Summary of Contents for Ameriwood HOME 7983339COMS

  • Page 1 7983339COMS (Bay Oak) Queen Wall Bed B347983339COMS0 Date of Purchase ___ / ___ / ___ Lot Number: THIS INSTRUCTION BOOKLET CONTAINS WARNINGS AND PRODUCT SAFETY INFORMATION. DO NOT PROCEED WITHOUT REVIEWING THOUROUGHLY. FOR ANY QUESTIONS, CONTACT CUSTOMER SERVICE. Difficulty Meter Do Not Return This Product! Contact our customer service team for help first.
  • Page 2 Part 1 - Installation • Installation steps will require the use of one professional and one other person to assist. • The second person must be able to lift wall bed components and hold them in position while the professional installs hardware.
  • Page 3 Before You Start Read through each step carefully and follow the proper order. Separate and count all your parts and hardware before attempting assembly. Parts are labeled on the surface or edge of the part Open your item in an area you plan to keep it. Give yourself enough room for the installation and assembly process.
  • Page 4 Board Identification Not actual size dorelhome.com...
  • Page 5 Board Identification parts for 7983339COMS (Bay Oak) Parts List ITEM PART NUMBER DESCRIPTION 37983339010 LEFT PANEL 37983339020 RIGHT PANEL 37983339030 37983339040 BOTTOM 37983339051 UPPER BACK PANEL 37983339060 CENTER BACK PANEL 37983339071 UPPER SHELF HEADBOARD PANEL 37983339080 37983339091 BOTTOM STRINGER 37983339100...
  • Page 6 WARNING! CHOKING HAZARD - Hardware bag contains small parts. Keep out of reach of children. Part List Note that your unit may Actual Size contain extra hardware (x6) (x6) (x26) (x28) (x26) #A22910 #A22920 #A21660 #A22620 #A22610 connector bolt connector wood dowel cam bolt cam lock...
  • Page 7 WARNING! CHOKING HAZARD - Hardware bag contains small parts. Keep out of reach of children. Part List Note that your unit may Actual Size contain extra hardware shown on pages 32 & 33 (x1) (x1) (x8) A99570 A81340 #A25400 dual LED light kit touch sensor disk washer (x8)
  • Page 8 Bed Frame Identification Not Actual Size Note: Not all parts will be identified. Right Assembly Mattress Holder (2) Left Assembly 9632096-19c 9632096-19b 9632096-19d 9632096-19a Wood Slat (30) Right Pivot Arm Gas Piston (4) Left Pivot Arm U-Bracket (4) Plastic Cap (60) 9632096-19g 9632096-19h 9632096-19f...
  • Page 9 Part 1 - Installation Installation steps will require the use of one professional and one other person to assist. Installation steps will cover pages 10-36. Professional is required for: • all hardware fastening steps • identifying wall structure and appropriate attachment hardware to use •...
  • Page 10 STEP 1 (x1) (x4) (x6) (x6) Proper orientation of Cam Lock Proper orientation of Cam Lock Press in face connector (9) into the holes in the Upper Back Panel (E) then engage the other end of the face connectors (9) into the holes in the Rear Rail (Q). Press the two parts together to lock together. Please note: the parts will be loose in the holes until you press both parts together.
  • Page 11 STEP 2 (x4) (x8) Proper orientation of Cam Lock Proper orientation of Cam Lock dorelhome.com...
  • Page 12 STEP 3 (x6) (x8) (x3) Proper orientation of Connector Proper orientation of Cam Lock Proper orientation of Cam Lock dorelhome.com...
  • Page 13 STEP 4 (x2) (x4) Proper orientation of Cam Lock Proper orientation of Cam Lock dorelhome.com...
  • Page 14 STEP 5 (x4) (x3) Proper orientation of Connector dorelhome.com...
  • Page 15 STEP 6 (x3) (x4) dorelhome.com...
  • Page 16 STEP 7 (x4) (x3) dorelhome.com...
  • Page 17 STEP 8 (x1) Proper orientation of wire saddle dorelhome.com...
  • Page 18 STEP 9 (x13) (x3) Press in face connector (9) into the holes in the Left Panel (A). Then engage the other end of the face connectors (9) into the holes in the Left Side Rail (O). Press the two parts together to lock together. Please note: the parts will be loose in the holes until you press both parts together.
  • Page 19 STEP 10 (x8) (x1) The Left Pivot Arm (19e) is located in the 9632096COM Wall Bed Mechanism box dorelhome.com...
  • Page 20 STEP 11 (x3) (x13) Press in face connector (9) into the holes in the Right Panel (B). Then engage the other end of the face connectors (9) into the holes in the Right Side Rail (P). Press the two parts together to lock together. Please note: the parts will be loose in the holes until you press both parts together.
  • Page 21 STEP 12 (x8) (x1) The Right Pivot Arm (19f) is located in the 9632096COM Wall Bed Mechanism box dorelhome.com...
  • Page 22 STEP 13 turn clockwise to lock in place dorelhome.com...
  • Page 23 STEP 14 turn clockwise to lock in place unfinished surface dorelhome.com...
  • Page 24 STEP 15 Please note: Rear Rail (Q) is assembled on finished surface of the Upper Back Panel (E). unfinished surface dorelhome.com...
  • Page 25 STEP 16 LOCK UNLOCK dorelhome.com...
  • Page 26 STEP 17 Press dowels into place. Gently use rubber mallet if needed. dorelhome.com...
  • Page 27 STEP 18 LOCK UNLOCK dorelhome.com...
  • Page 28 STEP 19 LOCK UNLOCK dorelhome.com...
  • Page 29 STEP 20 LOCK UNLOCK dorelhome.com...
  • Page 30 STEP 21 Start at one end and work your way to the other end to line parts up before locking cams. LOCK UNLOCK dorelhome.com...
  • Page 31 STEP 22 (x4) (x4) Carefully, lay the unit onto its front. Tap in the Bushings (12) with a hammer and then screw in the Glides (11) all the way. dorelhome.com...
  • Page 32 STEP 23 The next steps are to assemble your electrical hardware Cord length information: 1. The power supply cord is 72” from transformer to the plug's tip 2. The loop wire for the sensor disk, from the transformer is 48” to the center of the loop 3.
  • Page 33 STEP 23 continued LED Light Kit Assembly Open the package for the LED Light Kit. Everything will be assembled together. First, unclip the LED Light from the Light Plug as shown... unclip light plug LED light Second, you must disassemble the LED Light. Unscrew the cover off the base and then remove the lens piece.
  • Page 34 STEP 24 (x2) (x1) (x1) Place transformer (20a) on the Headboard Panel (H) in the location shown. Use screws (16) to attach transformer (20a). Thread the power supply plug (20b) in front of the Bottom Stringer (I) if needed for power source. dorelhome.com...
  • Page 35 STEP 25 With the help of another person, carefully stand the unit upright. During these steps, allow another person to securely hold the unit from tipping over. Place touch sensor disk (21) in location shown in Lower Shelf (J). (x1) dorelhome.com...
  • Page 36 STEP 26 (x1) (x1) (x1) With the help of another person holding the unit steady upright, take the Loop Sensor (20c) that is connected to the Transformer (20a) and place underneath the Lower Shelf (J) at the hole location of the Touch Sensor Disk (21). Thread screw (13) through the Loop Sensor and screw into Touch Sensor Disk (21).
  • Page 37 The next steps are to attach your unit to the wall. Wall attachment steps will cover pages 38-46. The following steps are required to be completed by a professional. The second person may assist by holding the cabinet in position while the professional completes alignment, leveling and installation steps.
  • Page 38 STEP 27 Carefully, place the unit FLUSH against the wall There are notches provided at the back of your unit. These notches are to fit around the baseboard on your wall. If your baseboard is higher or thicker than the notches provided on the unit, you will need to remove the baseboard, cut it down to fit on both sides of your unit, then...
  • Page 39 STEP 28 Using a level, be sure the unit is square (height, width, and depth) to function properly A ladder will be required. Do not lean against the top of the unit, it may cause sagging If required, unscrew the Glides counterclockwise as necessary in all 4 corners until your unit is...
  • Page 40 What type of wall do you have? For Steps 29 & 30 you will need to choose between two types of screws to use based on the type of wall you are installing this product to. Wooden & Metal Studs - Follow Steps 29 & 30 - Wooden &...
  • Page 41 STEP 29 - Wooden & Metal Studs Locate at least 3 DIFFERENT studs, in the horizontal direction, but 4 is better. Locate the studs in the wall, Average distance between studs (16") using a stud finder. Using a Wall Studs pencil, mark the stud locations on the upper surface of the Upper Back Panel (E) where...
  • Page 42 STEP 30 - Wooden & Metal Studs (x8) (x8) First, make sure that your unit is still level in all directions. As shown in the view to the right, fasten the unit to the wall studs with screw (18) and washer (19).
  • Page 43 STEP 30 continued... Example of 4 screws being placed horizontally in wall studs on part E and part I. Please note this is just an example - all wall stud distances are different. dorelhome.com...
  • Page 44 STEP 29 - Concrete Choose 4 horizontal predrilled holes equally across the Upper Back Panel (E). Carry and use the same predrilled holes down to the Bottom Stringer (I). Using a pencil, mark the locations on the upper surface of the Upper Back Panel (E) where the predrilled holes are provided.
  • Page 45 STEP 30 - Concrete (x8) (x8) First, make sure that your unit is still level in all directions. As shown in the view to the right, fasten the unit to the concrete wall with screw (24) and washer (19). The view shows the Upper Back Panel (E) but do the same for Bottom Stringer (I).
  • Page 46 STEP 30 continued... Example of 4 screws being placed horizontally in wall studs on part E and part I. Please note this is just an example - all wall stud distances are different. dorelhome.com...
  • Page 47 Part 2 - Assembly The next steps are to assemble the metal bed frame mechanism and door panels. Assembly steps will cover pages 48-65. As mentioned on page 2: Choose one of the two options below... • You may continue to use the Professional and a second person, •...
  • Page 48 STEP 31 (x3) (x4) (x1) (x1) First, press each rubber foot (19u) into each hole in the Leg (19c) as shown below. Then, join and assemble the Left & Right bed frame assemblies (19a & 19b) as shown below using bolts (19o) with the provided hex key (19s). You may use a rubber mallet to help join the two frame assemblies.
  • Page 49 STEP 32 (x8) (x8) (x1) (x4) Place the four U-Brackets (19i) in the locations. Use the bolts (19o) and washers (19q) to assemble the U-Brackets (19i) to the joined bed frame assemblies (19a & 19b) as shown. Use the provided hex key (19s) to assemble.
  • Page 50 STEP 33 (x1) (x4) (x2) Assemble the mattress holders (19d) to the frame assemblies (19a & 19b) with bolts (19p) as shown to the right. Use the provided hex key (19s) to assemble. dorelhome.com...
  • Page 51 STEP 34 (x4) (x4) (x4) long end short end Assemble two pistons (19h) to each side of the bed frame assembly with clevis pins (19l) and secure each one with a cotter pin (19n). 19h 19h long end long end The ends of both pistons need to be inserted into the groove of the bed frame when assembled.
  • Page 52 STEP 35 (x1) (x2) (x2) The cabinet is not shown to allow a clear view of the bed frame assembly With a person on each side, lift the assembled bed frame, line up the holes of the frame assembly with the large bushing hole of the Left and Right Pivot arm (19e &...
  • Page 53 STEP 36 Critical Step... Please read directions carefully! (x4) (x1) With a person on each side, carefully lift the bed frame in the closed position. While one person pushes the bed frame into the cabinet, beyond the 90 degrees, the other person is to engage the "front" Gas Piston (19h) on each side of the unit, to the front pin of the Left and Right Pivot push here...
  • Page 54 STEP 36 continued... This image shows the bed frame pushed into the cabinet, beyond 90 degrees. BED FRAME 90 DEGREES (WHEN THE BED FRAME IS IN THE UPRIGHT MOST POSITION) Please note: it is normal to see the bed frame in this state prior to the gas pistons being installed.
  • Page 55 STEP 37 (x2) (x1) (x2) Be sure the bed frame is fully assembled to the unit cabinet. (This step could use both people). Once certain, carefully pull the bed frame down, then assemble the Leg (19c) as shown with the clevis pins (19m) and cotter pins (19n). The cabinet is not shown to allow a clear view of the bed frame assembly...
  • Page 56 STEP 38 (x4) With the help from another person, carefully place the Top (C) onto the Left Side Rail (O), Right Side Rail (P) and Top Rear Rail (Q). Use screw (10) as shown. BE SURE WIRE SADDLE (17) IS ON TOP OF THE TOP (C).
  • Page 57 STEP 39 (x2) (x2) With the help of another person, assemble the disassembled LED lights (19d) to the Top (C) with screw (15). Thread the LED lights (19d) wires through the holes provided in Top (C) to allow the wires to be placed on top of the Top (C). A ladder will be required.
  • Page 58 STEP 40 With the help of another person, feed the LED light wires through the wire saddle (17) in the Top (C) and Upper Back Panel (E). Clip the Light Plugs (19d) (that is fixed into the transformer (19a)) back into the LED light wires.
  • Page 59 STEP 41 With the help of another person, assemble the LED lights back together. First placing the lens into the base and then screwing the cover back to the base as shown below. Adjust any wires necessary. Assure the Power Supply Plug is close to where power outlet is located.
  • Page 60 STEP 42 (x8) (x12) (x4) Proper orientation of bracket Note: The beveled edges of Vertical Door Moldings (N) face towards the center of Left Door Panel (L). dorelhome.com...
  • Page 61 STEP 43 (x8) (x12) (x4) Proper orientation of bracket Note: The beveled edges of Vertical Door Moldings (N) face towards the center of Right Door Panel (M). dorelhome.com...
  • Page 62 STEP 44 support rail IMPORTANT: First, unlock and flip the leg into the cabinet. Then, lower the bed frame down a bit to allow clearance to hook Door Panels. This step could use both people. Carefully lift Door Panel (L & M), position the Brackets (22) over the three Support Rails of the Bed Frame, and drop into position.
  • Page 63 STEP 45 (x8) (x8) (x16) (x16) Align the entire assembly so that the edges are lined up with the bed frame and push up against the leg. This will set the top gap. Then fasten the panels to the bed frame with the brackets (23).
  • Page 64 STEP 45 continued... View is looking from the top... showing location of brackets (23). BLACK CIRCLES : The locations to use Screw (6) & Screw (7) to fasten the bracket (23). BLACK "SHADED" CIRCLES : The locations to use Screw (6) & Screw (25) to fasten the bracket (23). dorelhome.com...
  • Page 65 STEP 46 (x30) (x60) Press a Plastic Cap (19j) at each end of a Wood Slat (19g). Press both Plastic Caps (19j), attached to the Wood Slat, into the holes of the Metal Bed Frame. Repeat the procedure for all 30 wood slats and 60 plastic caps.
  • Page 66 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. This bed is designed to accommodate a Queen Size Mattress, up to 10" inches thick. * with a maximum weight of 70 lbs (31.8 kgs) * with a minimum weight of 35 lbs (15.9 kgs) After you have finished installing and...
  • Page 67 Register your product to receive the following: * New trend details - sneak peek on what's new * Surveys - have a voice within our community * Exclusive deals and discount codes * Quick and easy replacement part service To register your product, visit ameriwoodhome.com Visit your local retailer's website, rate your purchased product and leave us some feedback! dorelhome.com...
  • Page 68 Español Portada: Cama de pared Queen Size ADVERTENCIAS E INFORMACIÓN SOBRE LA SEGURIDAD DEL PRODUCTO. NO PROCEDA SIN REVISAR DETENIDAMENTE. ANTE CUALQUIER PREGUNTA, CONTÁCTESE CON EL SERVICIO DE ATENCIÓN AL CLIENTE. ¡No devuelva este producto! Contáctese primero con nuestro equipo del servicio de atención al cliente para obtener ayuda. Llame: 1-800-489-3351 (gratuito) Visite: www.dorelhome.com Para ver la garantía limitada válida...
  • Page 69 Español Parte 2: Montaje - Los pasos del montaje requieren emplear a dos personas que deberán ser capaces de alzar y fijar las partes de la cama con elementos de ferretería: - Puede seguir empleando al profesional y a una segunda persona, o bien - Emplear a dos personas que tengan experiencia en el montaje de muebles listos para montar.
  • Page 70 Español Página 4-5: Identificación de la placa Tamaño no real A. Panel izquierdo K. Riel de estante B. Panel derecho L. Panel de puerta izquierdo C. Parte superior M. Panel de puerta derecho D. Parte inferior N. Moldura de puerta vertical E.
  • Page 71 Español Página 8: Identificación del marco de la cama No es el tamaño real No todas las partes estarán identificadas. 19a - Montaje izquierdo 19l - Pasador de horquilla grande 19b - Montaje derecho 19m - Pasador de horquilla pequeño 19c - Pata 19n - Pasador de chaveta 19d - Soporte del colchón...
  • Page 72 Español Página 10: Orientación de la cerradura de leva Presione el conector frontal (9) en los orificios del panel posterior superior (E) y luego coloque el otro extremo de los conectores frontales (9) en los orificios del riel posterior (Q). Presione las dos partes para que se traben. Tenga en cuenta que las partes estarán sueltas en los orificios hasta que presione ambas partes juntas.
  • Page 73 Español Página 32-33: de herrajes eléctricos Información sobre la longitud de los cables: 1. El cable de alimentación mide 72 pulg. desde el transformador hasta la punta del enchufe. 2. El cable del bucle para el disco sensor, desde el transformador es de 48 pulg. hasta el centro del bucle. 3.
  • Page 74 Español Página 34: Coloque el transformador (20a) en el panel de la cabecera (H) en la ubicación que se muestra. Use el tornillo (16) para fijar el transformador (20a). Enrosque el enchufe de la fuente de alimentación (20b) en frente del larguero inferior (I) si es necesario para la fuente de alimentación. Página 35: Con la ayuda de otra persona, coloque la unidad en posición vertical con cuidado.
  • Page 75 Español Página 38: Con cuidado, coloque la unidad AL RAS de la pared. En la parte trasera de la unidad hay muescas. Estas deben coincidir con el zócalo de la pared. Si el zócalo es más alto o más grueso que las muescas incluidas en la unidad, tendrá que quitar el zócalo, cortarlo para que quepa en ambos lados de la unidad y volver a fijarlo luego a la pared.
  • Page 76 Español Página 42: En primer lugar, asegúrese de que la unidad esté nivelada en todas las direcciones. Tal como se muestra en la vista de la derecha, fije la unidad a los montantes con tornillos (18) y arandelas (19). Esta vista muestra el panel trasero superior (E), pero haga lo mismo con el larguero inferior (I). Debe colocar al menos tres tornillos en tres montantes distintos, en dirección horizontal, aunque es mejor atornillar cuatro en la pieza E y la pieza I.
  • Page 77 Español Página 47: Parte 2, Montaje Los siguientes pasos consisten en montar el mecanismo del marco metálico de la cama y los paneles de las puertas. Los pasos del montaje abarcarán las páginas 48-65. Tal como se mencionó en la página 2, elija una de las dos opciones siguientes: - Puede seguir empleando al profesional y la segunda persona, o bien - Emplear a dos personas que tengan experiencia con el montaje de muebles listos para montar.
  • Page 78 Español Página 51: Monte dos pistones (19h) en cada lado del ensamblaje del marco de la cama con pasadores de chaveta (19l) y asegure cada uno con una chaveta (19n). El extremo “largo” de cada pistón debe fijarse al marco Durante su montaje, debe insertar los extremos de ambos pistones en la ranura del marco de la cama.
  • Page 79 Español Página 54: Esta imagen muestra el marco de la cama empujado hacia el gabinete, más allá de los 90 grados. Marco de la cama 90 GRADOS (CUANDO EL MARCO DE LA CAMA ESTÁ EN LA POSICIÓN MÁS VERTICAL) Tenga en cuenta: Es normal ver el marco de la cama en este estado antes de la instalación de los pistones a gas.
  • Page 80 Español Página 59: Con la ayuda de otra persona, vuelva a ensamblar las luces LED. Primero coloque la lente en la base y luego atornille la cubierta a la base como se muestra a continuación. Ajuste los cables necesarios según sea necesario.
  • Page 81 Español Página 66: Cargas máximas Esta unidad ha sido diseñada para soportar las cargas máximas mostradas. Exceder estos límites de carga podría generar un hundimiento, inestabilidad, el desplome del producto o lesiones graves. Esta cama está diseñada para alojar un colchón queen size de hasta 10 pulgadas de grosor. * con un peso máximo de 70 lb (31.8 kg) * con un peso mínimo de 35 lb (15.9 kg) Una vez que haya terminado de instalar y montar la cama abatible, conserve el manual de...
  • Page 82 Français Page de couverture : Lit mural Queen Size AVERTISSEMENTS ET INFORMATIONS RELATIVES À LA SÉCURITÉ DU PRODUIT. NE PROCÉDEZ PAS SANS LES LIRE ATTENTIVEMENT. POUR TOUTE QUESTION, CONTACTEZ LE SERVICE CLIENTÈLE. Ne renvoyez pas ce produit! Contactez d'abord notre service clientèle pour obtenir de l'aide. Appelez-nous : 1-800-489-3351 (gratuit) Rendez-vous sur : www.dorelhome.com pour consulter la garantie limitée valable aux États-Unis et au Canada.
  • Page 83 Français Partie 2 - Assemblage - Les étapes d'assemblage nécessitent l'intervention de deux personnes qui doivent être en mesure de soulever et de fixer les pièces du lit à l'aide de la quincaillerie : - Vous pouvez continuer à utiliser le professionnel et une deuxième personne, ou - Faites appel à...
  • Page 84 Français Page 4-5 : Identification des pièces Pas de taille réelle A. Panneau de gauche K. Rail d'étagère B. Panneau de droite L. Panneau de porte gauche C. Haut M. Panneau de porte droit D. Bas N. Moulure de porte verticale E.
  • Page 85 Français Page 8 : Identification du cadre de lit Pas la taille réelle Toutes les pièces ne sont pas identifiées. 19l - Grand axe de chape 19a - Assemblage gauche 19m - Petit axe de chape 19b - Assemblage droit 19n - Goupille fendue 19c - Pied 19o - Boulon M6 x 16 mm...
  • Page 86 Français Page 10 : Orientation du verrou à came Poussez le connecteur avant (9) dans les trous du panneau arrière supérieur (E), puis placez l'autre extrémité des connecteurs avant (9) dans les trous du rail arrière (Q). Appuyez sur les deux parties ensemble pour les verrouiller ensemble.
  • Page 87 Français Page 32-33 sur le matériel électrique Informations sur la longueur du cordon : 1. Le cordon d'alimentation mesure 72 pouces du transformateur à l'extrémité de la prise. 2. Le câble en boucle pour le disque du capteur, à partir du transformateur, mesure 48 pouces jusqu'au centre de la boucle.
  • Page 88 Français Page 34 : Placez le transformateur (20a) sur le panneau de tête de lit (H) à l'emplacement indiqué. Utilisez la vis (16) pour fixer le transformateur (20a). Enfilez la fiche d'alimentation (20b) devant le rail inférieur (I) si nécessaire pour l'alimentation. Page 35 : Avec l'aide d'une autre personne, replacez soigneusement l'appareil en position verticale.
  • Page 89 Français Page 38 : Placez soigneusement l'unité FLUSH au mur. Il y a des encoches à l'arrière de l'appareil. Ces derniers doivent correspondre à la plinthe du mur. Si la plinthe est plus haute ou plus épaisse que les encoches incluses avec l'appareil, vous devrez retirer la plinthe, la couper pour l'adapter aux deux côtés de l'appareil, puis rattachez-le au mur.
  • Page 90 Français Page 43 : Exemple de quatre vis placées horizontalement dans les goujons de la pièce E et de la pièce I. Veuillez notez qu'il ne s'agit que d'un exemple ; tous les espacements des boulons sont différents. Page 44 : Béton Choisissez quatre trous pré-percés horizontaux espacés uniformément le long du panneau arrière supérieur.
  • Page 91 Français Page 48 : Tout d'abord, insérez chaque tampon en caoutchouc (19u) dans chaque trou du pied (19c), tel qu'indiqué ci-dessous. Ensuite, joignez et assemblez les ensembles de cadres de lit gauche et droit (19a et 19b) comme illustré. ci-dessous à l'aide des boulons (19o) et de la clé Allen (19s). Vous pouvez utiliser un maillet en caoutchouc pour vous aider à...
  • Page 92 Français Page 53 : continued... Pour fixer le piston à gaz « arrière » (19 h) de chaque côté de l'unité, déplacez le cadre de lit d'un côté à l'autre lentement et avec précaution jusqu'à ce que vous puissiez insérer les pistons à gaz ( 19 h) dans l'axe arrière des bras pivotants gauche et droit.
  • Page 93 Français Page 59 : Avec l'aide d'une autre personne, réassemblez les lumières LED. En plaçant d'abord le Insérez la lentille dans la base, puis revissez le couvercle sur la base comme indiqué ci-dessous. Ajustez tous les fils nécessaires. Assurez-vous que la fiche d'alimentation est proche de la prise de courant est situé. Branchez-le sur la prise et assurez-vous que la lumière DEL (20) et le disque du capteur tactile (21) sont fonctionne correctement.
  • Page 94 Français Page 66 : Charges maximales Cet appareil a été conçu pour supporter les charges maximales indiquées. Le dépassement de ces limites de charge peut entraîner un affaissement, une instabilité, un effondrement du produit et/ou des blessures graves. Ce lit est conçu pour accueillir un matelas Queen Size, d'une épaisseur maximale de 10 pouces. * avec un poids maximum de 70 livres (31.8 kg) * avec un poids minimum de 35 livres (15.9 kg) Après avoir terminé...
