Page 1
Easy Tough Visit: www.ameriwoodhome.com Assembly Difficulty Meter WARNING Follow Ameriwood Home - Unit can tip over causing severe injury or death. - Anchor unit to stud in wall - Do Not allow children to climb on unit Tube - Put heavy items on lower shelves or drawers...
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 - Open your item in the area you plan to keep it to avoid excessive heavy lifting.
Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Parts are labeled on the surface or edge of the part Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing,...
Page 4
Before You Start Please Note: You may need to lightly tap the wood dowels into the holes during your assembly process. ameriwoodhome.com...
Page 5
Board Identification Not actual size SIDE BACK SIDE 5 ameriwoodhome.com...
Page 6
Board Identification Not actual size Center Support (2) Left Side Panel Headboard 37191000030 37191341020 37191341010 End Support (2) Bed Slat 37191000040 37191000050 Bed Board (2) 37191000060 Footboard Lower Rail Side Molding (2) Footboard Top Rail 37191341080 37191341090 37191341070 6 ameriwoodhome.com...
Page 7
Board Identification Not actual size Drawer Runner (2) Drawer Front Assembly 37191000100 37191341110 BACK SIDE Drawer Back Drawer Side (2) 39991149090816B 39991149346200C Drawer Bottom Right Side Panel K719133160 37191341120 7 ameriwoodhome.com...
Note that your unit may contain extra hardware Part List Actual Size (x8) (x8) (x16) (x4) (x8) #A22620 #A22610 #A21660 #A21960 #A12930 cam lock cam bolt wood dowel hidden fastener #8 x 1-1/8 ph pn ab (x2) (x8) (x8) #A17030 #A19895 #A22950 8-32 x 5/16"...
Page 9
Part List Not Actual Size Left Cabinet Member Right Cabinet Member (x2) #A54900 drawer brace Left Drawer Member Right Drawer Member (x1) #A56770 drawer slide kit (x1) (x2) (x1) #A23100 #A54520 #A50408 hex key drawer bracket handle ameriwoodhome.com...
Page 10
STEP 1 (x8) (x8) Proper orientation of Cam Lock Proper orientation of Cam Lock ameriwoodhome.com...
Page 22
STEP 13 side molding front view 15 mm 15 mm 22 ameriwoodhome.com...
Page 23
STEP 14 (x1) (x2) The long slot is to point toward the edge hole as shown. 23 ameriwoodhome.com...
Page 24
STEP 15 (x1) (x2) The long slot is to point toward the edge hole as shown. 24 ameriwoodhome.com...
Page 25
STEP 16 Attach the bed slat (E) to the side panels (B&L) by positioning the angle (x4) brackets with the holes and using the screws as shown. 25 ameriwoodhome.com...
Page 26
STEP 17 (x2) (x4) finished edge SIDE SIDE Fasten the brackets on the same surface as the groove ameriwoodhome.com...
Page 27
STEP 18 (x4) SIDE SIDE SIDE ameriwoodhome.com...
Page 28
STEP 19 raw surface SIDE ameriwoodhome.com...
Page 29
STEP 20 (x4) BACK SIDE ameriwoodhome.com...
Page 30
STEP 21 (x1) (x4) (x2) (x1) (x1) SIDE BACK marked with an "L" marked with an "R" SIDE ameriwoodhome.com...
Page 32
STEP 23 Note: The drawer bracket holes are slotted. Drawer fronts can be adjusted by loosening screws, making needed adjustments and retightening screws. roller cabinet member drawer runner roller 32 ameriwoodhome.com...
Page 34
Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 300 lbs 136 kg 30 lbs 13.6 kg (drawer) Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is not approved for use with a television.
Page 35
Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com...
Page 36
Espa ol Cubierta Delantera Este libro de instrucciones contiene informaci n IMPORTANTE de seguridad. Por favor lea y mant ngalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda.
Page 37
Español Página 11, 12 borde acabado orificio frontal Página 13 borde acabado marcado con una (R) Página 14 borde acabado marcado con una (L) Página 17 debe estar al ras Página 18 borde acabado Página 19 La ranura grande es para apuntar hacia el borde del agujero como se muestra. Página 20 La ranura grande es para apuntar hacia el borde del agujero como se muestra. borde acabado Página 22 vista frontal de moldura lateral Página 23, 24 La ranura grande es para apuntar hacia el borde del agujero como se muestra. Página 25 Fije el listón de la cama (E) contra los paneles laterales (B y L) colocando las escuadras con orificios y utilizando los tornillos como se muestra. Página 26 borde acabado Ajuste los soportes en la misma superficie que la ranura. 37 ameriwoodhome.com...
Page 38
Español Página 28 superficie en bruto Página 30 marcado con una (L) marcado con una (R) Página 32 Nota: Los agujeros del soporte del cajón ya tienen ranuras. Las placas frontales pueden ajustarse aflojando las tuercas, haciendo los ajustes necesarios y apretando de nuevo las tuercas. Página 34 CARGA MAXIMA Esta unidad ha sido diseñada para soportar la carga máxima anotada. El exceder estos límites puede causar inestabilidad, colapsarse y/o causar serias lesiones. ADVERTENCIA: Riesgo de lesiones a las personas ‐ no coloque un televisor sobre muebles. Este mueble no está aprobado para su uso con un televisor. Página 35 Registre su producto para recibir lo siguiente: * Detalles de nuevas tendencias ‐ Vistazo a lo nuevo * Encuestas ‐ alec su voz entre su comunidad * Códigos de ofertas y descuentos exclusivos * Fácil y rápido servicio de partes de remplace Para registrar su producto, visite ameriwoodhome.com Clasificasión de 5 estrellas Visite el sitio web de su tienda local, califique su comprado y denos sus comentarios! Nos gustaría enviar un gran "Agradecimiento" a todos nuestros clientes por tomarse el tiempo de ensamblar este producto de Ameriwood Home, y por darnos sus valiosos comentarios. Gracias 38 ameriwoodhome.com...
Page 39
Fran ais Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA S CURIT . VEUILLEZ LIRE ET GARDER POUR UNE R F RENCE FUTURE Ne retournez pas ce produit! Contactez notre quipe de service la client le amicale d'abord pour obtenir de l'aide.
Page 40
Français Page 11, 12 bord fini trou avant Page 13 bord fini marqué d'un (R) Page 14 bord fini marqué d'un (L) Page 17 doit être affleurant Page 18 bord fini Page 19 La longue fente doit pointer vers le côté du trou, tel qu'indiqué. Page 20 La longue fente doit pointer vers le côté du trou, tel qu'indiqué. bord fini Page 22 moulage latéral vue de face Page 23, 24 La longue fente doit pointer vers le côté du trou, tel qu'indiqué. Page 25 Fixez la latte du lit (E) aux panneaux latéraux (B et L) en positionnant les équerres avec les trous et en utilisant les vis comme illustré. Page 26 bord fini Fixes les supports sur la même surface que la rainure. 40 ameriwoodhome.com...
Page 41
Français Page 28 surface brute Page 30 marqué d'un (L) marqué d'un (R) Page 32 Remarque: Les trous du support de tiroir sont fendus. Les façades des tiroirs peuvent être ajustées en desserrant les vis, en effectuant les réglages nécessaires et en resserrant les vis. Page 34 CHARGES MAXIMALES Ce meuble a été conçu pour supporter les charges maximales indiquées. En excédant ces limites de charge, le meuble pourrait devenir instable, s'effondrer, et/ou causer des blessures graves. AVERTISSEMENT : Risque de blessure corporelle ‐ ne pas placer une télévision sur ce meuble. Ce meuble n'est pas approuvé pour une utilisation avec une télévision. Page 35 Enregistrez votre produit pour recevoir les éléments suivantes: * Détails sur les nouvelles tendances ‐ un aperçu sur les nouveautés * Sondages ‐ avoir une voix au sein de notre communauté * Offres exclusives et codes promo * Service de pièces de rechange rapide et facile Pour enregistrer votre produit, visitez ameriwoodhome.com 5 Étoiles Visitez le site Web de votre détaillant local, évaluez votre produit acheté et laissez‐nous quelques commentaires ! Nous tenons à offrir un grand "Merci" à tous nos clients pour avoir pris le temps d'assembler ce produit "Ameriwood Home", et de nous donner vos commentaires précieux. Merci 41 ameriwoodhome.com...
