Wired Remote
Controller
Installation Handbook
MODEL BRC1H64W/BRC1H64K
• Be sure to read before conducting the installation
of this product, and conduct installation according
to this manual.
• Refer to this manual together with the installation
manual of the indoor unit.
• It is possible to perform settings of some functions
from a smart phone app.
• For details, refer to the BRC1H64W/BRC1H64K
manual on our company website.
Advertisement
Related Manuals for Daikin BRC1H64W
Summary of Contents for Daikin BRC1H64W
- Page 1 • Refer to this manual together with the installation manual of the indoor unit. • It is possible to perform settings of some functions from a smart phone app. • For details, refer to the BRC1H64W/BRC1H64K manual on our company website.
- Page 2 Contents Safety Precautions ............. 2 Components and Accessories ..........3 Button Locations and Descriptions ........4 Remote Controller Installation Procedure......7 Field Setting ..............18 Updated by OTA ............... 21 License ................23 Certification ..............24...
- Page 3 Safety Precautions „ Also refer to installation manual attached to the indoor unit. Please read these “Safety Precautions” carefully before installing the remote controller. • This manual classifies the precautions into WARNINGS and CAUTIONS. Be sure to follow all the precautions below: They are all important for ensuring safety. Indicates a potentially hazardous situation which, if not avoided, could WARNING result in death or serious injury.
- Page 4 CAUTION Install the remote controller in the living area. To avoid electric shocks due to entry of water or insects, fill the wiring through hole with putty. Do not operate with wet hands to avoid electric shocks. Do not wash the remote controller with water. Failure to do so many cause electric shock or a fire.
- Page 5 Button Locations and Descriptions Functions items (i.e., Operation Mode, Fan Speed, and Setpoint) are set from the menu screen. NOTICE • Do not install the remote controller in places exposed to direct sunlight. The LCD may be damaged. • Do not pull or twist the remote controller cord. The remote controller may be damaged. •...
- Page 6 c Centralized Control Home screen • Displayed when under centralized management. d Operation mode • Displays the current operation mode. ˚C e Ventilation mode f Room temperature • Displays the current room temperature. g Setback • Blinks during setback operation. •...
- Page 7 * The Bluetooth® and Zigbee™ word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc and Zigbee Alliance, respectively, and the use of such marks by Daikin Industries LTD. is under license. Other trademarks and trade names are those of their respective owners.
- Page 8 Remote Controller Installation Procedure Deciding where to install the remote controller Select the installation location based on “Safety Precautions” (see page 2) and obtain consent of the customer. Creating a wiring through-hole in the wall (when opening a hole in the wall and installing) [Unit : inch (mm)] 3-11/64 (80.5) Back plate...
- Page 9 Determining the wire routing direction for the back plate Before mounting the controller, determine the wiring direction and remove a piece of the controller’s back plate accordingly (i.e.: a, b, c). The wiring can be routed from the top, the left, or the bottom of the back cover.
- Page 10 Securing the back plate Wall installation 1 : Take the cross recessed round head wood screws and drywall anchors out of the accessory bag. 2 : Mount the back plate to a flat surface. Drywall anchors Cross recessed round head wood screws CAUTION •...
- Page 11 Connecting the electrical wiring All wiring must comply with the following requirements: Wire specification Value Wiring type Non-shielded, 2-conductor, Stranded copper wire Wiring size AWG-18 Wiring length Maximum 1640 feet (500 m) Prepare the wiring for connection to the remote controller following these instructions: Approx.
- Page 12 Top outlet P1P2 P1P2 terminal Rear outlet P1P2 Left outlet P1P2...
- Page 13 Bottom outlet P1P2 CAUTION • Keep the wiring away from the power wire so that electrical noise (external noise) is not received. • In order to prevent the entry of water or insects, use putty (field supply) to securely seal the wiring lead-in hole.
- Page 14 When removing the upper casing Insert a flat head screwdriver into the recess in the back plate and remove the upper casing. (2 locations) CAUTION • The remote controller circuit board is attached to the upper casing. Be careful not to damage the circuit board and casing when removing the upper casing.
- Page 15 Designating a controller as main or sub Prerequisite: A remote controller is already connected to the indoor unit. Connect a second controller. After turning on the power, perform setting of the second controller. Result: It will start up automatically. Home screen Wait for a U5, U8 error code to appear on the screen.
- Page 16 Releasing the changeover master (VRV only) To change the authority to choose cooling/heating, you must first specify the remote controller with the authority, then release the authority. Depending on the system, setting may not be available. Prerequisite: You are in the installer menu. You are operating the controller of the indoor unit that you want to release from being the changeover master.
- Page 17 Sub-menu screen Press to release the indoor unit from its authority. Result: • The indoor unit is released from its authority. • The controllers of all indoor units display a blinking “ ” icon.
- Page 18 Setting up the changeover master This setting is available only when none of the remote control in the system has master control. Prerequisite: No indoor unit is yet set as the changeover master (“ ” icon blinking on all controllers). You are operating the controller of the indoor unit that you want to set as the changeover master.
- Page 19 Field Setting Field settings method This section describes how to perform field setting. Home screen Press and hold button for 5 seconds or longer to display the information screen. ˚C Information screen Press (in that order) and hold them down ...
- Page 20 Sub-menu screen Press button, to select Mode No. and press Mode 20 to enter the field setting menu. Press button, to scroll the desired Mode No. Unit 00 and press button. a Mode No. b Unit No. c Enter d Return Sub-menu screen Press button, to select Unit No.
- Page 21 Sub-menu screen Press button, to move Second Code No., and SW 00 then press button. Press button, to scroll to the desired Second – 01 Code No., and then press button. Sub-menu screen Press button, select , and then press SW 00 button to fix the setting and return to the previous screen.
- Page 22 If you need to update the software in the remote controller, follow the steps below. The Bluetooth setting screen can also be accessed via a shortcut operation on the home screen. For details, please refer to the BRC1H64W/BRC1H64K manual on the company website.
- Page 23 Bluetooth setting screen Launch the DAIKIN APP and update the software. For details, refer to the manual for the DAIKIN APP. XX:XX:XX * The last 6 digits of the Bluetooth device address are displayed on the remote controller, select the same 6 digits that are also displayed on the app.
- Page 24 License The following OSS is included in the remote controller. [micro-ecc] Copyright (c) 2014, Kenneth MacKay All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: * Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
- Page 25 Certification COMPLIANCE WITH REGULATIONS • In Singapore Complies with IMDA Standards DA107930 • In Thailand • In Australia/In New Zealand...
- Page 26 3P607378-6H EM24A013A [2503] HT...
