AVS Carflector Installation Instructions Manual

Bugflector
For proper installation and best possible fit, please read all instructions BEFORE you begin.
For technical assistance or to obtain missing parts, please call Customer Relations at 1-800-241-7219.
Important Safety Information
• CAUTION - Before driving, ensure that the hood shield is properly secured to vehicle.
• Do not use automatic "brush-style" car washes.
• Do not use cleaning solvents of any kind.
• Periodically check all components for tightness.
Contents
NOTE: Actual product may vary from illustration.
Tools Required
Preparation Before Painting / Installation
• A trial fit is recommended to ensure proper positioning and fit.
• Check fit of parts before painting as we will not accept the return of modified or painted parts.
• Wash and dry your vehicle to remove any debris and/or dirt from the installation area.
Installation Steps
Raise hood and clean the leading edge thoroughly,
1
Installation Instructions
®
- Bugflector II
Hood shield
Clean Towel
Car Wash Supplies
NOTE: Actual application may vary slightly from illustrations.
and allow to dry.
® ®
- Carflector - Chrome Hood Shield
Screw
x 6
Phillips
screwdriver
Test fit hood shield by centering it on the hood edge.
Note where the mounting holes in the hood shield flange
2
Page 1 of 2
I - Sheet Number BF119 Rev.A
Receptacle Bump On
x 6 x4
Grease Pencil
will be and mark with a grease pencil.
™
