Unitronics UniStream UAG-XK Series User Manual

UniStream ® Local
Expansion Adapter Kits
Local Expansion Adapter Kits allow you to increase the number of I/Os connected to a single UniStream
by enabling you to link the controller to additional Uni-I/O™ modules.
This guide provides specifications for Unitronics' Short Range and Long Range Local Expansion Adapter
Kit for Uni-I/O™.
All Kits comprise a Base unit, an End unit, and a connecting cable. The cable length varies according to
kit model.
Short-range adapter Kits
▪
Up to 3 meters
Long-range adapter Kits
▪
3 meters and up
Kits whose models contain the letter 'P' include a built-in power supply; a powered adapter module
supports a greater number of I/O modules.
There are two main classes of adapters:
▪ UAG-XK
Both the Base and End units of these adapters have DIN-rail clips. You can:
▪ Snap the base onto the DIN-rail type structure on the back of UniStream Modular HMI
▪ Snap the base directly onto a UniStream PLC
▪ UAG-CX
The base unit of these adapters has a plug; the end unit has DIN-rail clips. You can plug the base unit
only into the I/O Expansion Jack offered by the UniStream Built-in series.
Note that the maximum number of modules supported by a single controller is provided in the controller's
technical specifications.
Technical specifications are available in Unitronics' Technical Library at www.unitronicsplc.com.
Adapter Models
The 'x's in the model numbers are placeholders for the cable lengths.
Model
UAG-XKxxx
UAG-XKPxxx
UAG-XKPLxxxx
UAG-CX-XKPxxx,
UAG-CX-XKPLxxxx
Before You Begin
Before installing the device, the installer must:
▪ Read and understand this document and related technical specifications and documents, located in the
Technical library section of the Unitronics website.
Verify the Kit Contents.
▪
Unitronics
Installation
Options
DIN-rail structure
DIN-rail
Plug into controller
Jack
User Guide
UAG-XKxxx, UAG-XKPxxx,
UAG-CX-XKPxxx, UAG-CX-XKPLxxxx,
and UAG-XKPLxxxx
Integrated Module Support
Power Supply
No 8, includes any modules
directly connected to the
controller
Yes 16, in addition to any modules
directly connected to the
controller
Yes 16
®
1
