Microphone Trim Control
A small circular potentiometer is located on the side of the preamp that faces the
back of the guitar. This control can be accessed by opening the battery compart-
ment. Set the Blend slider to the center position and with a small slotted screwdriv-
er and adjust the Trim Control until both the microphone and pickup levels are bal-
anced to your taste.
Endpin Jack
When you plug into the endpin jack, the Prefix Pro Blend switches on. To conserve
the battery, remove the instrument cable from the endpin jack when the system is
not being used. It is a good idea to turn down your amp or mixer input before you
plug into the endpin jack. Doing so will protect your speakers (and your ears) from
loud pops.
Battery Low LED
Plug into the endpin jack and the Low Battery light will flash momentarily, indicating
that the power is on. When the Low Battery light stays on, it is time to change the
battery.
