- Page 1 Smart Motorized Valve YS5002-UC Installation & User Guide Revision Mar. 22, 2023...
- Page 2 Contents . Welcome! . Before You Begin . In the Box . Required Items . Get to Know Your Smart Motorized Valve . Install the App . Add Your Valve to the App . Installation . Manual Operation . About Control-D2D .
- Page 3 Welcome! Thank you for purchasing YoLink products! We appreciate you trusting YoLink for your smart home & automation needs. Your 100% satisfaction is our goal. If you experience any problems with your installation, with our products or if you have any questions that this manual does not answer, please contact us right away.
- Page 4 Before You Begin Visit our Smart Motorized Valve support page on our website, for the latest installation guides, additional resources, information and videos by visiting: www.shop.yosmart.com/pages/smart- motorized-valve-product-support Or by scanning the QR code: Download the most current version of the user guide by scanning the QR code:...
- Page 5 The Smart Motorized Valve can be installed on CPVC or PEX pipe using the appropriate male NPT thread to compression or push-fit copper, CPVC or PEX adapters. YoLink recommends SharkBite brand fittings. Visit sharkbite.com or find additional information on our Smart Motorized Valve Support page.
- Page 6 In the Box Motorized Valve Model:YS5002-UC Battery: AA x 2 FCC ID: 2ATM75002 Quick Start Guide Made in China PULL UP BEFORE MANUALLY OPEN/SHUT Batteries (Installed) Smart Motorized Valve Required Items These tools or items may be required: Pipe Wrench Locking Pliers Copper Pipe Cutting Tool...
- Page 7 Get to Know Your Smart Motorized Valve The YoLink Smart Motorized Valve is a motorized valve with an integrated YoLink valve controller. To get to know your new Smart Motorized Valve, refer to the illustrations below. Manual Control Knob Lift, then turn either clockwise to...
- Page 8 Install the App If you are new to YoLink, please install the app on your phone or tablet, if you have not already. Otherwise, please proceed to the next section. Scan the appropriate QR code below or find the “YoLink app” on the appropriate app store.
- Page 9 Add Your Valve to the App 1. Tap Add Device (if shown) or tap the scanner icon: Scanner icon 2. Approve access to your phone’s camera, if requested. A viewfinder will be shown on the app. Motorized Valve Model:YS5002-UC Battery: AA x 2 FCC ID: 2ATM75002 Made in China PULL UP BEFORE...
- Page 10 Add Your Fob to the App, Continued 4. You can change the device name and assign it to a room later. Tap Bind device. 5. If successful, the screen will appear as shown. Tap Done. 6. If the Smart Motorized Valve is not already on, press the SET button for a moment, until the LED illuminates briefly.
- Page 11 Installation 1. Shut-off the water serving the pipe where the valve is to be installed. Drain the water from the pipe, by turning on a faucet, or by other method as required. 2. Depending on the adapter fitting used, mea- sure the length of pipe that must be cut, and mark the cut lines on the pipe, as shown below.
- Page 12 Installation, Continued 5. Install your adapter fittings in the pipe ends, per the manufacturer instructions. 6. Wrap each adapter’s threaded end with thread seal tape, per the tape manufacturer’s instruc- tions, as shown below. 7. Install the Smart Motorized Valve on the adapter fittings, ensuring a secure connection at each fitting, as shown below.
- Page 13 Installation, Continued 10. Test the Smart Motorized Valve several times by pressing the SET button and listening for the smooth closing/opening of the valve, and by checking the water flow at a faucet. The water should be completely turned off while the valve is in the shut position.
- Page 14 Manual Operation It is recommended to use the app or the SET button on the valve, when you need to open or close the valve. But if you need to manually operate the valve, follow these instructions: 1. On the top of the Smart Motorized Valve, lift the manual control knob.
- Page 15 Control-D2D, YoLink devices can be controlled without the Hub or an internet connection. (Use of YoLink Control-D2D is optional; you can use the Automation feature in the app OR use YoLink Control, but YoLink Control-D2D offers the benefit of operation without the Hub or internet connection.) One device controls another,...
- Page 16 About Control-D2D, Continued 3. Test your paired devices. Upon the detection of water at the leak sensor, the valve should automatically close. Please note: the valve will not open when water is removed from the leak sensor. The valve should be closed from the app or by pressing the SET button on the valve.
- Page 17 Using the App & 3rd-Party Services Please visit our website’s Product Support page for the YoLink app guide and for product specific app settings and instructions: www.yosmart.com/support-and-service...
- Page 18 Battery Replacement 1. Loosen the two battery cover screws and remove the battery compartment cover Motorized Valve Model:YS5002-UC Battery: AA x 2 FCC ID: 2ATM75002 Made in China PULL UP BEFORE MANUALLY OPEN/SHUT 2. Replace both batteries, observing the polarity and orientation of each battery.
- Page 19 Factory Reset Factory reset will erase device settings and restore it to factory default settings. Doing a factory reset will not remove the device from your account and it will not harm the device, or lose any data or require you to redo your automations, etc.
- Page 20 Firmware Update Your YoLink products are constantly being improved, with new features added. It is periodically necessary to make changes to your device's firmware. For optimal performance of your system, and to give you access to all available features for your devices, these firmware updates should be installed when they...
- Page 21 Troubleshooting Symptom: 1. Device is offline - If valve is not connected to the cloud, press the SET button on Smart Motorized Valve - If Hub is offline, reconnect the Hub to the Internet and press the SET button on Smart Motorized Valve - If Hub is not on, power on the Hub again and press the SET button on Smart Motorized...
- Page 22 Warnings Please install, operate and maintain the Smart Motorized Valve only as outlined in this manual. Improper use may damage the unit and/or void the warranty Do not install or use the Smart Motorized Valve outside of the temperature and humidity range listed in the Environmental section in Specifications, on the Smart Motorized Valve Support page...
- Page 23 Warnings, Continued Power the Smart Motorized Valve only with two AA batteries (see below, regarding batteries) Use only new, alkaline or lithium non- rechargeable AA batteries. Do not use zinc blend batteries Do not mix new and old batteries Do not puncture or damage batteries. Leakage can cause harm on skin contact, and is toxic if ingested Do not dispose of batteries in fire as they...
- Page 24 Warranty 1 Year Limited Electrical Warranty YoSmart Inc. warrants to the original user (“customer”) of this product that it will be free from defects in materials and workmanship, under normal use, for 1 year from the date of purchase. This warranty does not apply to devices that have been improperly installed, modified, put to a use other than designed, or subjected to acts of God (such as floods,...
- Page 25 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 26 FCC Statement, Continued - Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. PRODUCT NAME: SMART MOTORIZED VALVE PARTY: YOSMART, INC.
- Page 27 IC Caution -English: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
- Page 28 Support Home Page Finally, if you have any feedback or suggestions for us, please email us at feedback@yosmart.com Thank you for trusting YoLink! Eric Vanzo Customer Experience Manager 15375 Barranca Parkway Ste. J-107 | Irvine, California 92618 © 2023 YOSMART, INC IRVINE, CALIFORNIA...
