- Page 1 OWNER’S MANUAL THRU-THE-WALL AIR CONDITIONER MODELS 7PATW8000, 7PATW10000, 7PATW10002, 7PATW12000, 7PATW12002, 4PATW14002, 4PATWH10002, 4PATWH12002, 4PATWH14002...
- Page 3 ITEMS IN KIT ....................................13 INSTALLATION OVERVIEW ..............................14 WALL SLEEVE BRANDS ..........................16 #1 PERFECT AIRE, WHITE-WESTINGHOUSE, FRIGIDAIRE, CARRIER 52F SERIES 16 IN. & 17 ½ IN. DEEP ..................16 #2 FEDDERS 19 ¾ IN. DEEP ..............................17 #3 FEDDERS OR FRIEDRICH 16 ¾ IN. DEEP ........................18 #4 GENERAL ELECTRIC OR HOTPOINT 16 7/8 IN.
- Page 4 IMPORTANT SAFETY INSTRUCTION READ THESE SAFETY PRECAUTIONS BEFORE INSTALLATION AND OPERATION. For your safety, it is important that you read and follow the instructions in this manual to minimize the risk of personal injury, fire or electrical shock. To prevent injury to the user or other people and property damage, the following instructions must be followed.
- Page 5 IMPORTANT SAFETY INSTRUCTION (Continued) CAUTION When removing air filter, DO NOT touch metal parts of the unit. Doing so may cause an injury. Water may enter the unit and degrade the insulation DO NOT clean with water. causing an electric shock. Ensure proper ventilation, especially in rooms with a stove or Failure to do so may result in an oxygen shortage.
- Page 6 IMPORTANT SAFETY INSTRUCTION (Continued) OPERATION OF CURRENT DEVICE WARNING The power supply cord contains a current device ELECTRICAL INFORMATION that senses damage to the power cord. To test your power supply cord do the following: The complete electrical rating of your new room air conditioner is stated on the serial plate.
- Page 7 IMPORTANT SAFETY INSTRUCTION (Continued) • Save this manual for possible future use in • Appliance shall be installed, operated and removing or installing this unit. stored in a room with a floor area larger than 43 sq. ft. (4 m ).
- Page 8 IMPORTANT SAFETY INSTRUCTION (Continued) CAUTION: Risk of fire flammable materials Explanation of symbols displayed on the unit This symbol shows that the operation manual should be read carefully. CAUTION This symbol shows that a service professional should be handling this equipment CAUTION with reference to the installation manual.
- Page 9 IMPORTANT SAFETY INSTRUCTION (Continued) • The ventilation machinery and outlets are WARNING operating adequately and are not obstructed. For using R32 refrigerant • If an indirect refrigerating circuit is being used, the secondary circuit shall be checked 5. Presence of a fire extinguisher: If any hot for the presence of refrigerant.
- Page 10 IMPORTANT SAFETY INSTRUCTION (Continued) followed since flammability is a consideration. WARNING • The following procedure shall be adhered to: For using R32 refrigerant • Remove refrigerant • Safely remove refrigerant following local CABLING and national regulations; • Check that cabling will not be subject to wear, •...
- Page 11 IMPORTANT SAFETY INSTRUCTION (Continued) • Pump down refrigerant system, if possible. WARNING • If a vacuum is not possible, make a manifold so For using R32 refrigerant that refrigerant can be removed from various parts of the system. • Cylinders should be kept upright. •...
- Page 12 IMPORTANT SAFETY INSTRUCTION (Continued) WARNING IMPORTANT NOTICE: WARRANTY VOID For using R32 refrigerant FOR IMPROPER INSTALLATION • The recovery equipment shall be in good Please note that the warranty for the working order with a set of instructions thru-the-wall air conditioner will be void if concerning the equipment that is at hand and shall be suitable for the recovery of flammable any other type of installation method not...
- Page 13 INSTALLATION INSTRUCTIONS DO THIS FIRST (FOR EXISTING SLEEVE) CAUTION Note that the air conditioner dimensions are: DO NOT, under any circumstances, cut or remove 24.25 inches wide, 14.5 inches high, and 18.5 the third (ground) prong from the power cord. inches deep (without front).
- Page 14 STEP 1 IDENTIFY WALL-SLEEVE BRAND Identify the wall-sleeve brand for your installation from the chart below. WALL SLEEVE DIMENSIONS PERFECT AIRE, Frigidaire, STEP 2 White-Westinghouse, Carrier (52F Series) REMOVE OLD AIR CONDITIONER WIDTH HEIGHT DEPTH Remove old air conditioner from wall sleeve and 25 ½"...
- Page 15 ASSEMBLE AND INSTALL THE TRIM FRAME (SEE INSTRUCTIONS) Prepare the wall sleeve for installation of the new unit per the following brand instructions. IMPORTANT PERFECT AIRE, Frigidaire, • The unit’s increased performance White-Westinghouse, Carrier (52F Series) characteristics result from having two rear air...
- Page 16 WALL SLEEVE BRANDS 7. Remove the plastic washer from the screw. #1 PERFECT AIRE, 8. Screw and attach the other end of the ground WHITE-WESTINGHOUSE, wire to the unit as shown in picture. Make sure FRIGIDAIRE, CARRIER 52F SERIES that the toothed washer is against the cabinet.
- Page 17 WALL SLEEVE BRANDS (Continued) 7. Cut (2) 1" x ⅜" x 25" long seal to 14" long and #2 FEDDERS attach it to the vertical sections of the rear 19 ¾ IN. DEEP grille as shown. 1. Remove existing rear grille and replace with provided louvered panel.
- Page 18 WALL SLEEVE BRANDS (Continued) 7. Cut (2) 1" x ⅜" x 25" long seal to 14" long and #3 FEDDERS OR FRIEDRICH attach it to the vertical sections of the rear 16 ¾ IN. DEEP grille as shown. 1. Remove existing rear grille and replace with provided louvered panel.
- Page 19 WALL SLEEVE BRANDS (Continued) 6. Cut (2) 1" x ⅜" x 25" long seal to 14" long #4 GENERAL ELECTRIC OR HOTPOINT and attach to the vertical sections of the 16 7/8 IN. DEEP rear grille as shown. 1. Remove existing rear grille and replace with provided louvered panel.
- Page 20 WALL SLEEVE BRANDS (Continued) 6. Cut (2) 1" x ⅜" x 25" long seal to 14" long and #5 SEARS OR CARRIER 51S SERIES attach it to the vertical sections of the rear 18 5/8 IN. DEEP grille as shown. 7.
- Page 21 WALL SLEEVE BRANDS (Continued) 6. Cut (2) 1" x ⅜" x 25" long seal to 14" long #6 WHIRLPOOL and attach to the vertical sections of the 17 1/8 IN. DEEP rear grille as shown. 1. Remove existing rear grille and replace with provided louvered panel.
- Page 22 WALL SLEEVE BRANDS (Continued) 7. Cut (2) 1" x ⅜" x 25" long seals to 14" long #7 WHIRLPOOL and attach to the vertical sections of the 23 IN. DEEP grille as shown. 1. Remove existing rear grille and replace with provided louvered panel.
- Page 23 WALL SLEEVE BRANDS (Continued) 17. Remove the plastic washer from the screw. 3. Attach the (2) 1" x ⅜" x 14" long seals to the left and right sides of the sleeve. 18. Screw and attach the other end of the ground wire to the unit as shown in picture.
- Page 24 WALL SLEEVE BRANDS (Continued) 7. Attach (1) 1" x 1 ½" x 25" long seal in the center #9 WHITE WESTINGHOUSE, FRIGIDAIRE at the top of the sleeve. Remove the backing 22 IN. DEEP paper and press into position. Proceed to step 1.
- Page 25 WALL SLEEVE BRANDS (Continued) 17. Screw and attach the other end of the ground 22. Position the grille over the rear of the unit wire to the unit as shown in picture. Make sure making sure that: that the toothed washer is against the cabinet. a.
- Page 26 SEAL & FRAME AND NORMAL SOUNDS SEAL & FRAME NORMAL SOUNDS 1. Install the 1" x 1 ½" x 84" long stuffer-seal between the wall sleeve and the unit. A flat bladed screwdriver or putty knife is recommended. High Pitched Chatter High efficiency compressors may have a high 2.
- Page 27 OPERATION INSTRUCTIONS TO TURN UNIT ON OR OFF GET TO KNOW THE FEATURES Press POWER button to turn unit on or off. WARNING • To reduce the risk of fire, electric shock, The unit will initiate automatically the NOTE: or injury to persons, read the IMPORTANT Energy Saver function under COOL, DRY and SAFETY INSTRUCTIONS before operating this AUTO modes.
- Page 28 OPERATION INSTRUCTIONS (Continued) CHECK FILTER FEATURE TO SELECT THE OPERATING MODE Press Check filter button to initiate this feature. To choose operating mode, press the Mode This feature is a reminder to clean the Air Filter button. Each time you press the button, a mode for more efficient operation.
- Page 29 OPERATION INSTRUCTIONS (Continued) TIMER: AUTO START/STOP FEATURE To operate on AUTO mode • Auto Mode is designed to automatically regulate • Press button, the TIMER ON or TIMER OFF the room temperature around the temperature indicator light illuminates. It indicates the Auto point set by you.
- Page 30 OPERATION INSTRUCTIONS (Continued) DISPLAY ADDITIONAL THINGS YOU SHOULD KNOW Shows the set temperature in ”°F" or ”°C" and the Now that you have mastered the operating Auto-timer settings. While on FAN only mode, it procedure, here are more features in your control shows the room temperature.
- Page 31 CARE & MAINTENANCE (Continued) CHECK THE AIR FILTER ONCE A MONTH TO SEE IF CLEANING IS NECESSARY The air filter should be checked at least once a month to see if cleaning is necessary. Trapped particles in the filter can build up and cause an accumulation of frost on the cooling coils.
- Page 32 CARE & MAINTENANCE (Continued) 5. Store the Remote Control: INSTRUCTIONS FOR WINTER STORAGE If your air conditioner has a remote control, Choose the Storage Location remove the batteries before storage to Select a dry, cool, and indoor location for prevent potential corrosion. Always use storage.
- Page 33 TROUBLESHOOTING Before calling for service, review this list. It may save your time and expense. This list includes common occurrences that are not the result of defective workman-ship or materials in this appliance. Problem Solution Be sure unit is not too large or too small for the area of the room. Verify that all doors, windows, curtains and any other openings are closed.
- Page 34 5 minutes. It is also recommended to try another wall outlet. For further assistance, contact customer service at 844-472-2473. The design and specifications are subject to change without prior notice for product improvement. Any updates to the manual will be uploaded to the Perfect Aire website (www.perfectaire.us), please check for the current version.
