S&P PC80XP Installation, Operation And Maintenance Manual

PC80XP, PC110XP, PC150XP INSTALLATION,
OPERATION, AND MAINTENANCE MANUAL
INTRODUCTION
DO NOT INSTALL, USE OR OPERATE THIS EQUIPMENT UNTIL THIS MANUAL HAS BEEN READ AND UNDERSTOOD. READ AND SAVE
THESE INSTRUCTIONS FOR FUTURE USE.
These instructions are intended to supplement sound installation practices and are not intended to cover detailed instruction procedures
because of the wide variety of fan types and field conditions that exist.
It is the responsibility of the purchaser to assure that the installation and maintenance of this equipment is handled by qualified personnel
experienced in such work and equipment.
Contact your local representative should you need further information.
SAFETY INFORMATION
WARNING! To reduce the risk of fire, electric shock, or injury to persons, observe the following:
a. Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer.
b. Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting means to prevent power from being
switching on accidentally. When the service disconnecting means cannot be locked, securely fasten a prominent warning device, such as a
tag, to the service panel.
c. Installation work and electrical wiring must be done by a qualified person(s) in accordance with all applicable codes and standards,
including fire-rated construction codes and standards.
d. Sufficient air is needed for proper combustion and exhausting of gases through the flue (chimney) of fuel burning equipment to prevent
backdrafting. Follow the heating equipment manufacturer's guideline and safety standards such as those published by the National Fire
Protection Association (NFPA), and the American Society for Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and the local
code authorities.
e. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.
f. Ducted fans must always be vented to the outdoors.
g. Acceptable for use over a tub or shower when connected to a GFCI (ground fault circuit interrupter)—protected branch circuit (ceiling
installation only).
h. This unit must be grounded.
i. Not for use in kitchens.
j. To reduce risk of fire and to properly exhaust air, be sure to duct air outside—do not vent exhaust air into spaces within walls/ceilings or into
attics, crawl spaces, or garages.
k. WARNING: To Reduce The Risk Of Fire Or Electric Shock, Do Not Use This Fan With Any Solid-State Speed Control Device.
i. The fan must not be installed in a ceiling thermally insulated to a value greater than R40.
®
