This Technical Publication details Reading Unit and Control PCB Assembly changes for the CR-190i,
CR-190i II and CR-135i.
DETAILS:
Hardware Changes

Front and Back Reading Units.

ntrol PCB Assembly for new Reading Unit compatibility.
Co
 Serial prefix plate.
Firmware Changes

Has been upgraded from version 1.26 to version 2.02.

BOTH old and new Reading Unit compatibility.

Fixed the trouble that the main body freezes when USB cable is inserted and removed in status of Imprint ON.
Service Tool Changes

Added the function to display the version of Control PCB in the Service tool.

Has been upgraded to version 1.17.2017.1218.
SERVICE PARTS:
Description
IMAGE SENSOR UNIT,
Old
FRONT
1
IMAGE SENSOR UNIT,
New
FRONT
IMAGE SENSOR UNIT,
Old
BACK
2
IMAGE SENSOR UNIT,
New
BACK
PCB ASSEMBLY,
Old
CONTROL
3
PCB ASSEMBLY,
New
CONTROL
PCB ASSEMBLY,
Old
CONTROL 135i
4
PCB ASSEMBLY,
New
CONTROL 135i
Note: The old and new parts are interchangeable ONLY if replaced simultaneously #'s 1, 2, 3 (4 – if CR-135i).
