Siemens SIMATIC RTLS PCB OEM PULSE Operating Instructions Manual
Localization systems
Hide thumbs
Also See for SIMATIC RTLS PCB OEM PULSE:
- Manual (11 pages) ,
- System manual (204 pages) ,
- Operating instructions manual (20 pages)
Table of Contents
Related Manuals for Siemens SIMATIC RTLS PCB OEM PULSE
Summary of Contents for Siemens SIMATIC RTLS PCB OEM PULSE
- Page 1 SIMATIC RTLS PCB OEM PULSE Introduction Device description SIMATIC RTLS Installation & Operation Technical specifications Localization systems SIMATIC RTLS PCB OEM PULSE Approvals Operating Instructions 05/2023 C79000-G8976-C552-05...
-
Page 2: Legal Information
Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems. -
Page 3: Table Of Contents
Order data RTLS PCB OEM PULSE ..................10 Pin assignment ........................10 LED status indicator ......................11 Dimension drawing ......................11 Installation & Operation ........................13 Notes on installation ......................13 Technical specifications ........................15 Approvals ............................. 17 SIMATIC RTLS PCB OEM PULSE Operating Instructions, 05/2023, C79000-G8976-C552-05... - Page 4 Table of contents SIMATIC RTLS PCB OEM PULSE Operating Instructions, 05/2023, C79000-G8976-C552-05...
-
Page 5: Introduction
You can find the complete documentation for all SIMATIC RTLS products at the following address: Link: (https://support.industry.siemens.com/cs/us/en/ps/25277/man) Trademarks The following and possibly other names not identified by the registered trademark sign ® registered trademarks of Siemens AG: SIMATIC RTLS SIMATIC RTLS PCB OEM PULSE Operating Instructions, 05/2023, C79000-G8976-C552-05... - Page 6 Introduction Industry Online Support In addition to the product documentation, the comprehensive online information platform of Siemens Industry Online Support offers support at the following Internet address: (https://support.industry.siemens.com/cs/start?lc=en-US) Apart from news, there you will also find: • Project information: Manuals, FAQs, downloads, application examples etc.
-
Page 7: Security Information
Use of product versions that are no longer supported, and failure to apply latest updates may increase customer’s exposure to cyber threats. To ensure that you are always informed about product updates, subscribe to the Siemens Industrial Security RSS feed at: (https://www.siemens.com/cert) Note on firmware/software support Check regularly for new firmware/software versions or security updates and apply them. - Page 8 Do not dispose of the products at public disposal sites. For environmentally compliant recycling and disposal of your electronic waste, please contact a company certified for the disposal of electronic waste or your Siemens representative. Note the different national regulations.
-
Page 9: Device Description
Precautionary measures against electrostatic discharge The transponder can be damaged by electrostatic discharge (ESD). Take suitable precautionary measures when unpacking and operating the transponder to avoid damage. Characteristics SIMATIC RTLS PCB OEM PULSE Characteristics Design ① Status indicators (LED) ② Connection solder contacts operating voltage and communication P4 ③... -
Page 10: Order Data Rtls Pcb Oem Pulse
2.3 Order data RTLS PCB OEM PULSE Order data RTLS PCB OEM PULSE Table 2- 1 Order data RTLS PCB OEM PULSE Article number SIMATIC RTLS PCB OEM PULSE 6GT2700-8AF03 Pin assignment Solder contact P4 Description / Function Optional serial interface (level 3.3 V) Optional serial interface (level 3.3 V) -
Page 11: Led Status Indicator
The antenna is connected to the PCB via a 5 cm long U.FL cable. The contacts used are P3 on the PCB and P1 on the antenna. Figure 2-1 All dimensions specified in millimeters. SIMATIC RTLS PCB OEM PULSE Operating Instructions, 05/2023, C79000-G8976-C552-05... - Page 12 Device description 2.6 Dimension drawing Antenna Figure 2-2 All dimensions specified in millimeters. SIMATIC RTLS PCB OEM PULSE Operating Instructions, 05/2023, C79000-G8976-C552-05...
-
Page 13: Installation & Operation
Metal surfaces reflect radio waves more than any other types of surfaces. Water, on the other hand, attenuates radio waves. You should therefore evaluate your working environment and integration for these influences. SIMATIC RTLS PCB OEM PULSE Operating Instructions, 05/2023, C79000-G8976-C552-05... -
Page 14: Maintenance
(de-sensing). This is true, for example, for the 2.4 GHz ISM band and PULSE in the UWB channel 5. Maintenance Only authorized dealers or the manufacturer are permitted to repair the transponder. SIMATIC RTLS PCB OEM PULSE Operating Instructions, 05/2023, C79000-G8976-C552-05... -
Page 15: Technical Specifications
Technical specifications Table 4- 1 Technical specifications of the RTLS PCB OEM PULSE transponder 6GT2700-8AF03 Product name SIMATIC RTLS PCB OEM PULSE PULSE radio frequencies (localization) Wireless method IEEE 802.15.4-2015 UWB HRP PHY Transmission speed 850 kbit/s Operating frequency rated value 3993.6 MHz (UWB channel 2;... - Page 16 Technical specifications SIMATIC RTLS PCB OEM PULSE Operating Instructions, 05/2023, C79000-G8976-C552-05...
-
Page 17: Approvals
(TR CU) USA (FCC) This device complies with part 15 of the FCC rules. Alternative: FCC ID: XXXXYYZZZZ IC: XXXXYYZZZZ Canada (ISED) This device complies with Industry Canada licence-exempt RSS standard(s). SIMATIC RTLS PCB OEM PULSE Operating Instructions, 05/2023, C79000-G8976-C552-05... - Page 18 Para maiores informações, consulte o site da ANATEL (www.anatel.gov.br). ANATEL: XXXXYYZZZZ Importer UK: Siemens plc, Sir William Siemens House, Princess Road, Manchester M20 2UR Mexico (NOM) La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación...
- Page 19 Siemens plc, Manchester M20 2UR You can find the current UK Declaration of Conformity for these products on the Internet pages under Siemens Industry Online Support (https://support.industry.siemens.com/cs/en/en/view/109801531). The SIMATIC RTLS products described in this document meet the requirements of the following directives/regulation: •...
- Page 20 Electromagnetic compatibility (EMC) - Part 6-1: Generic standards - Immunity for residential, commercial and light-industrial environments • EN 61000-6-2 Electromagnetic compatibility (EMC) - Part 6-2: Generic standards - Immunity for industrial environments SIMATIC RTLS PCB OEM PULSE Operating Instructions, 05/2023, C79000-G8976-C552-05...
- Page 21 3.2 of the Directive 2014/53/EU; Part 2: Requirements for UWB location tracking FCC information Siemens SIMATIC RTLS PCB OEM PULSE (MLFB 6GT2700-8AF13); FCC ID NXWOEMPULSE This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:...
- Page 22 20 mm separation from the human body at all times. IC information Siemens SIMATIC RTLS PCB OEM PULSE (MLFB 6GT2700-8AF33); IC ID 267X-OEMPULSE This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:...
- Page 23 Pour être conforme aux exigences de la ISED relatives à l'exposition aux radiofréquences, ce matériel doit être installé de manière à assurer à tout moment une distance d'au moins 20 mm du corps humain. SIMATIC RTLS PCB OEM PULSE Operating Instructions, 05/2023, C79000-G8976-C552-05...
