Summary of Contents for Immergas UI SP
- Page 1 UI SP Instructions and recommendations Installer Maintenance technician Technical data...
- Page 2 Cod. 1.049325 UI SP...
- Page 3 1.7 Conducting the Tests ............................22 Instructions for Maintenance ....................... 23 2.1 General Warnings ............................... 23 2.2 Care and maintenance ............................23 2.3 Troubleshooting ..............................25 Technical Data ............................27 3.1 SP Technical Data ............................... 27 Cod. 1.049325 UI SP...
- Page 4 DEAR CUSTOMER Congratulations for having chosen a top-quality Immergas product, able to assure well-being and safety for a long period of time. As an Immergas Customer, you can also count on a qualified Authorised Technical After-Sales Centre, prepared and updated to guarantee constant efficiency of your product.
- Page 5 Read the instructions provided with the product carefully to ensure proper installation. • This instruction manual provides technical information for installing Immergas products. As for the other issues related to the installation of products (e.g. safety at the workplace, environmental protection, accident prevention), it is necessary to comply with the provisions of the standards in force and the principles of good practice.
- Page 6 Failure to follow the indications can generate appliance malfunctions. INFORMATION Indicates useful tips or additional information. EARTH TERMINAL CONNECTION The symbol identifies the appliance’s earth terminal connection point. PERSONAL PROTECTIVE EQUIPMENT SAFETY GLOVES SAFETY GOGGLES SAFETY FOOTWEAR Cod. 1.049325 UI SP...
- Page 7 To dispose of the device, refer to waste electrical and electronic equipment collection centres or contact the dealer that you purchased it from. Discharged batteries must be taken out of the remote controls and disposed of separately in compliance with local regulations. Cod. 1.049325 UI SP...
- Page 8 - Dual level energy-saving mode: ECO and GEAR; - To quickly reach the room setpoint, Turbo mode can be activated to reach the maximum air flow rate; - Very quiet operation thanks to the Silence function that reduces noise to a minimum; UI SP 0-01 Cod. 1.049325...
- Page 9 Description • Remote control manual • Safety manual Supplied documentation • User manual • Warranty Leaflet Remote control Battery AAA LR03 Remote control mount with screws Magnetic Ring 1/4” (6,35 mm) Brass Nut 1/2" (12.7 mm) Cod. 1.049325 UI SP...
- Page 10 • If the air conditioner is installed in a room with burners or other C.H. devices, thoroughly ventilate the room to avoid any lack of oxygen. The place of installation of the device and relative Immergas accessories must have suitable features (technical and struc- tural), such as to allow for (always in safe, efficient and comfortable conditions): •...
- Page 11 • Switch off the device and disconnect the power supply before cleaning or before performing maintenance on it. Failure to observe this rule can cause electric shocks. • Do not clean the air conditioner with excessive amounts of water. • Do not clean the air conditioner with flammable detergents. Cod. 1.049325 UI SP...
- Page 12 1-01 Dimensions Dimensions Dimensions Dimensions Couplings centre Model (Width mm) (Depth mm) (Height mm) distances (in mm) UI SP 1068 Connections Condensate drain Ø Flow pipe internal Ø Return pipe internal Model Net weight (kg) (mm) (liquid) Ø (gas) UI SP 1/4”...
- Page 13 (sold separately). With monosplit installation, the outdoor unit is only connected to the indoor unit, whereas with multisplit installation to a single outdoor unit, multiple indoor units are connected. Cod. 1.049325 UI SP...
- Page 14 Keep doors and windows closed. • Limit energy consumption with TIMER ON and TIMER OFF functions. • Do not block the air intakes and outlets. • Check and clean the air filters on a regular basis. Cod. 1.049325 UI SP...
- Page 15 2. Install the drain pipe 3. Install the outdoor unit 4. Connect the pipes 5. Connect the wiring 6. Evacuate the cooling system 7. Conduct the tests. 1-04 ATTENTION See the reference manual for the specifications of the outdoor unit. Cod. 1.049325 UI SP...
- Page 16 The unit can be installed both on the wall and ceiling. NOTE: • Tie rods or threaded metric bars can also be used. Buy the appropriate fastening systems depending on the type of wall and the weight of the unit to be installed. Cod. 1.049325 UI SP...
- Page 17 2. Using a minimum 65mm size cutter bit for the drill, drill a hole in the wall, ensuring that it is angles slightly downwards, so that the outer end is about 12 mm lower than the inner end. Cod. 1.049325 UI SP...
- Page 18 The drain pipe must slope at least 1% to prevent water from back-flowing into the air conditioner. • Install suspension elements every 1-1,5 m so that the pipe does not bend. • An incorrect installation can cause water backflow into the unit. Cod. 1.049325 UI SP...
- Page 19 When stripping the wires, be sure to clearly identify the “L” phase cable. • Strictly follow the wiring diagram to connect the cables. • The cooling circuit can become very hot, keep the interconnection cable away from the copper pipe. Cod. 1.049325 UI SP...
- Page 20 HO7RN-F multipolar cable Number of poles: 3 Minimum conductor cross-section: 2.5 mm² 1-29 Maximum current absorbed Example of UI SP 18 connection. OUTDOOR UNIT MULTI 28 QUADRI = 19.0 A MULTI 36 QUADRI = 21.5 A L(B) N(B) S(B) L(C)
- Page 21 7. Refit the electric compartments cover and tighten the screws. KEY: 1. Cable outlet 2. Cover of electrical connections 3. Wiring diagram sticker 1-19 Do not insert fingers or other objects into the air inlet or outlet. Cod. 1.049325 UI SP...
- Page 22 • Stop the air conditioner by pressing the main power switch and refit the cover. NOTE: If the unit is not working correctly or is not working as expected, refer to the Troubleshooting section of the User Manual for the Indoor Unit before calling customer service. 1-21 Cod. 1.049325 UI SP...
- Page 23 The device’s warranty shall be rendered null and void if unapproved or unsuitable parts are used for maintenance or repairs. These will also compromise the product’s compliance, and the said product may no longer be valid and fail to meet the current regulations. In regard to the above, only use original Immergas spare parts when replacing components. 2.2 CARE AND MAINTENANCE...
- Page 24 Switching back on after a Long Idle Period: 1. Clean all Filters 2. Replace the batteries 3. Check for any damaged cables 4. Check for any leaks 5. Make sure that nothing is blocking the air vents and outlets Cod. 1.049325 UI SP...
- Page 25 Disturbance of cell phone antennas/repeaters can cause the unit to malfunction. In this case, Operation is irregular, unpredict- try the following: able or the unit does not respond • Disconnect power, then reconnect. • Press the ON/OFF button on the remote control to restart operation. Cod. 1.049325 UI SP...
- Page 26 •EH(xx), EL(xx), EC(xx) •PH(xx), PL(xx), PC(xx) NOTE: If the problem persists after having carried out the above checks and diagnostics, immediately switch the unit off and contact an au- thorised assistance centre. Cod. 1.049325 UI SP...
- Page 27 TECHNICAL DATA 3.1 SP TECHNICAL DATA UI SP Heating performance Rated output power Btu/h (kW) 19,000 (5.57) Rated absorbed power Rated absorbed current 0.44 Room temperature °C 0-30 Cooling performance Rated output power Btu/h (kW) 18.000(5,28) Rated absorbed power Rated absorbed current 0.44...
- Page 28 Immergas S.p.A. 42041 Brescello (RE) - Italy Tel. 0522.689011 immergas.com This instruction booklet is made of ecological paper...
