Page 1 UI THOR 9-12-18-24 UI GOTHA 9-12 Instructions and UE THOR 9-12-18-24 recommendations UE GOTHA 9-12 Installer User Maintenance technician Technical Data...
Page 2 ST.007729/008 UI-UE THOR 9-12-18-24 UI-UE GOTHA 9-12...
Page 3 INDEX Dear Customer ........................................4 General Warnings ........................................5 Safety symbols used ....................................... 6 Personal protective equipment .................................... 6 Disposal Method ........................................7 Monosplit air conditioners features: Gotha and Thor ............................. 8 Content of the packaging ..................................... 9 Installation....................................10 1.1 General Warnings ......................................
Page 4: Dear Customer
DEAR CUSTOMER Congratulations for having chosen a top-quality Immergas product, able to assure well-being and safety for a long period of time. As an Immergas Customer, you can also count on a qualified Authorised Technical After-Sales Centre, prepared and updated to guarantee constant efficiency of your product.
Page 5: General Warnings
Read the instructions provided with the product carefully to ensure proper in- stallation. • This instruction manual provides technical information for installing Immergas products. As for the other issues related to the installation of products (e.g. safety at the workplace, environmental protection, accident prevention), it is necessary to comply with the provisions of the standards in force and the principles of good practice.
Page 6: Safety Symbols Used
SAFETY SYMBOLS USED GENERIC HAZARD Strictly follow all of the indications next to the pictogram. Failure to follow the indications can generate hazard situations resulting in possible serious harm to the health of the operator and user in general, and/or serious material damage. ELECTRICAL HAZARD Strictly follow all of the indications next to the pictogram.
Page 7: Disposal Method
DISPOSAL METHOD DISPOSAL WARNING The user must not dispose of the appliance at the end of its service life as municipal waste, but send it to appropriate collection centres. This marking on the product means that waste electrical and electronic equipment must not be mixed with generic household waste.
Page 8 MONOSPLIT AIR CONDITIONERS FEATURES: GOTHA AND THOR Direct expansion “split” inverter reversible single phase air to air heat pumps, consisting of an outdoor unit and an indoor unit. There is a separate code for the outdoor and indoor unit. Main components: - Outdoor unit (UE GOTHA/UE THOR), which mainly includes rotary compressor, inverter electronics, throttle valve, 4-way valve for cycle inversion, finned exchange coil with outdoor air (with single fan), Interception cocks for the R32 circuit.
Page 9: Content Of The Packaging
CONTENT OF THE PACKAGING INDOOR UNIT Description • Remote control manual • Safety manual Supplied documentation • User manual • Warranty Leaflet Mounting plate Referred to “INSTALLATION” paragraph Remote control Battery AAA LR03 Remote control mount with screws Screws with plugs Carbon filter Wifi Kit (ONLY FOR GOTHA)
Page 10: Installation
• If the air conditioner is installed in a room with burners or other C.H. devices, thoroughly ventilate the room to avoid any lack of oxygen. The place of installation of the device and relative Immergas accessories must have suitable features (technical and struc- tural), such as to allow for (always in safe, efficient and comfortable conditions): •...
Page 11 The manufacturer cannot be held liable for damage resulting from unauthorised changes or improper connection of the electric and cooling lines. Installation must be carried out according to UNI and IEC regulation standards, current legislation and in compliance with local technical regulations and the required technical procedures. In particular, standards UNI EN378 and CEI 64-8 need to be complied with.
Page 12 NOTE ON FLUORINATED GASES: • Installation, maintenance of the cooling circuit and the uninstallation of this unit must be carried out by a certified technician. • The refrigerant gas leak check must be carried out in accordance with the relative legislation. This job must be carried out by certified personnel only.
Page 13 INSTALLING THE INDOOR UNIT 1.2.1 MAIN DIMENSIONS 1-01 Dimensions Dimensions Dimensions Dimensions Model (L mm) (P mm) (A mm) UI THOR 9 UI THOR 12 THOR UI THOR 18 UI THOR 24 1082 UI GOTHA 9 GOTHA UI GOTHA 12 Connections Condensate...
Page 14: Main Components
1.2.2 MAIN COMPONENTS KEY: Wall-mounting plate Front panel Filter Condensate drain pipe Connection cable Cooling piping Outdoor Unit power cable Remote control 10. Remote control mount 1-02 NOTE: • The drawing refers both to the GOTHA solution and to the THOR solution •...
Page 15: Overview Of Installation
1.2.3 OVERVIEW OF INSTALLATION KEY: 1. Select the installation position (X = 15 cm, Y = 2,3 mt, Z = 12 cm) 2. Determine the position of the hole in the wall. 3. Secure the mounting plate 4. Drill the hole in the wall 5.
Page 16 1.2.4 INSTALLATION Before installing the indoor unit, see the label on the box of the product to make sure that the model number of the indoor unit matches the number of the Outdoor Unit. STEP 1: Choosing the place of installation. Before installing the indoor unit, choose a place for correct installation.
Page 17 90mm for UI Thor-24) and with an angle inclined slightly downwards, so that the slope facilitates water drainage (see figure below and table) UI GOTHA 9-12 - UI THOR 9-12 UI THOR 18-24 Hole in the wall for pipe passage...
Page 18 Using a minimum 65mm size cutter bit for the drill (for UI Thor-24 it must be a minimum of 90mm), drill a hole in the wall, ensuring that it is angles slightly downwards, so that the outer end is about 5-7mm lower than the inner end. Indoor Outdoor KEY:...
Page 19 STEP 4: Preparation of cooling pipes The cooling pipes are located inside an insulated sleeve connected to the back of the indoor unit. The pipes must be prepared before threading them through the hole in the wall. 1. Based on the position of the hole in the wall for the mounting plate, choose the side from which the pipes will exit the unit. 2.
Page 20 STEP 5: Connection of drain pipe By default, the drain pipe is connected on the left side of the unit (in a front position with respect to the back of the unit). However it can also be connected on the right side. To guarantee adequate drainage, connect the drain pipe on the same side that the cooling pipes exit the unit.
Page 21 STEP 6: Signal and power supply cables connection The connection cable between the indoor and outdoor unit allows to power the indoor unit(s) and communication. The type of cable and relative dimensions to be used are indicated in the wiring diagram below. All electrical connections must be made strictly complying with the wiring diagram sticker applied on the inside of the front panel and checking the connection wiring diagram in this manual.
Page 22 2. Open the front panel of the indoor unit. 3. Using a screwdriver, remove the terminal block cover on the right side of the unit. This allows you to access the terminal block below. KEY: 1. Terminal block 2. Cover 3.
Page 23 STEP 7: Wrapping pipes and cables Before passing the pipes and cable through the hole in the wall, they must be wrapped together to save space, and to protect and in- sulate them. Indoor unit KEY: 1. Space behind unit 2.
Page 24 If the cooling pipes are already recessed in the wall, proceed as follows: Couple the top of the indoor unit to the upper hook of the fixing plate. Use a bracket or wedge to prop up the unit, leaving enough space to connect the cooling pipes, the signal pipe and the drain pipe. Connect the drain pipe and the cooling pipes (see dedicated paragraphs in this manual).
Page 25 OUTDOOR UNIT INSTALLATION 1.3.1 MAIN DIMENSIONS 1-17 Dimensions in mm. models THOR 9 495 790 270 255 452 16.5 76,5 720 180.4 THOR 12 495 790 270 255 452 16.5 76,5 720 180.4 THOR 18 554 874 330 317 511 R 6,5 815 434,2 805 204.1 THOR 24...
Page 26 Connections EU models R32 refrigerant liquid R32 refrigerant gas Net weight [Kg] Condensate drain [mm] 1/4"(6.35 mm) 3/8"(9.52 mm) 23.5 THOR 9 1/4"(6.35 mm) 3/8"(9.52 mm) 23.7 THOR 12 1/4"(6.35 mm) 1/2"(12.7 mm) 33.5 THOR 18 3/8"(9.52 mm) 5/8"(15.9 mm) 43.9 THOR 24 26.4...
Page 27 60 cm 200 cm 30 cm 30 cm 60 cm 1-19 • Noise from the unit must not bother other people. • Make sure that the mount/wall/partition can bear the weight of the unit and does not vibrate. • Protected against extended periods of direct sunlight or rain. DO NOT install the unit in the following places: DO NOT install near an obstruction that could block air inlet and outlet DOT NOT install on a public road, crowded areas or where the noise of the unit can bother...
Page 28 INFORMATION If the unit is standing on the floor, it is advisable to purchase the dedicated Immergas floor-mount kit with the relative in- structions. If the unit is wall-mounted, it is advisable to purchase the dedicated Immergas wall-mount brackets kit with the relative in- structions.
Page 29 STEP 4: Signal and power supply cable connection Attention Before doing any electrical work, read the warnings at the beginning of this manual. Before performing any electrical work or cleaning, be sure to cut off the power supply to the units. When stripping the wires, be sure to clearly identify the “L”...
Page 30 1.3.4 CONNECTION OF COOLING PIPE When the refrigerant pipes are connected, do not let substances or gases other than the specified refrigerant get in. The pressure of other gases or substances reduces the capacity of the unit and can cause an abnormally high pressure in the cooling cycle. This can cause explosions and injuries.
Page 31 ATTENTION FOR THE USE OF R32 REFRIGERANT When using a flammable refrigerant, the device must be kept in a well-ventilated area where the size of the room corresponds to the area of the room, as specified for operation. The device must be installed, used and kept in a room larger than 4m².
Page 32 Step 2: Remove any burrs Burrs can affect the tightness of the connection of the refrigerant pipes. They must be completely removed. Hold the pipe with a downwards angle to avoid the burrs from falling into the pipe. Using a reamer or a deburring machine, remove all of the burrs from the cut section of the pipe. Step 3: Flare the ends of the pipes Correct flaring is essential for obtaining water-tightness.
Page 33 ATTENTION MINIMUM CURVATURE RADIUS: when refrigerant pipes are bent, make sure that the minimum bending radius is at least 10cm. Radius 10 cm ≥10cm Raggio 1-29 Step 4: Pipe Connection When connecting refrigerant pipes, be careful not to use an excessive torque or not to deform the pipes in any way. One must first connect the low pressure pipe, then the high pressure one.
Page 34 • Outdoor Unit Unscrew the valve cover on the side of the outdoor unit. Remove the protective caps from the ends of the valves. Align the flared end of the pipe with each valve and tighten the flared nut as tight as possible by hand. Using a spanner, grip the valve body.
Page 35: Additional Refrigerant Charge
KEY: Gas valve Refrigerant Liquid Valve 000000 000000 Service outlet 000000 000000 xxxxx xxxxx 000000 000000 xxxxx xxxxx 000000 000000 Flexible Conditioning Hose 0000 0000 Vacuum pump Digital manometric unit (Inte- grated vacuum switch) “VAC” actuator “LOW” actuator KEY: 10. Cock 11.
Page 36 1.3.7 CHECKING ELECTRICAL AND GAS LEAKAGE Electrical safety checks: • Check that the electrical system of the unit is safe and functioning correctly. • Check the earthing both visually and by measuring the resistance with a tester. • During test run, check for any electrical leakage using an electric probe and a multimeter to run a complete test. •...
Page 37: Performing The Test
1.3.8 PERFORMING THE TEST Conduct the Test Run for at least 30 minutes. Connect the power supply to the unit. Press the ON/OFF button on the remote control to switch it on. Press the MODE button to scroll the following functions, one at a time: •...
Page 38: General Warnings
INDOOR UNIT FUNCTIONS GENERAL WARNINGS Make sure to take adequate measures so that the unit is not used to house small animals. Animals that come into contact with elec- tric components could cause operating failures, smoke or fire. Inform the customer to keep the area around the unit clean. Children of 8 years or older and people with reduced physical, sensorial or mental capacities can use this device as long as they are under supervision or have been instructed and informed regarding the safe use of this device and the possible risks connected to it.
Page 39: Indoor Unit Display
INDOOR UNIT DISPLAY Meaning of display icons WLAN connection active Temperature display (in numerical format) Activation of certain Functions is displayed. Indicates, with indoor unit off, that the switch-on timer is active. Deactivation of certain functions is displayed Automatic defrost active. Antifreeze protection active: the indoor unit maintains the room air temper- ature at 8°C minimum.
Page 40: Display Errors
DISPLAY ERRORS When the indoor unit detects an acknowledged error, the LED flashes and the corresponding error code is displayed. Based on the type of appliance purchased, for possible error codes are listed in the following table: DISPLAY MEANING EH00/EH0A Indoor Unit EEprom fault EH08 Internal board-display communication fault...
Page 41: Operating Temperature
PH91 Evaporator freezing PC0F PFC circuit malfunction LC05 Frequency limitation for supply voltage LC03 Frequency limitation for supply current LC02 Frequency limitation for compressor flow temperature LC01 Frequency limitation for external heat exchanger temperature LC00 Frequency limitation for internal heat exchanger temperature LC06 Frequency limitation for PFC LC07...
Page 42 • AUTO-RESTART FUNCTION: in case of a power failure while the air conditioner is running, when restored, this would operate according to the previously defined settings. • ACTIVE CLEAN: this function, through alternated defrost cycles, removes dust and grease built-up on the heat exchanger of the indoor unit. •...
Page 43: Other Functions
NOTE: Do not move the vent by hand (See Fig. A). This would cause a synchronism failure of the vent. Should this happen, switch the unit off and unplug it for a few seconds, then switch it back on. This resets the vent. Asta del deflettore Fig.
Page 44: Instructions For Maintenance
The device’s warranty shall be rendered null and void if unapproved or unsuitable parts are used for maintenance or repairs. These will also compromise the product’s compliance, and the said product may no longer be valid and fail to meet the current regulations. In regard to the above, only use original Immergas spare parts when replacing components. ST.007729/008...
Page 45: Care And Maintenance
CARE AND MAINTENANCE ATTENTION: Always switch off the air conditioning system and disconnect power before cleaning and maintenance. ATTENTION: Use only a soft dry cloth to clean the unit. If the unit is particularly dirty, you may use a cloth soaked in warm water to clean it. •...
Page 46 ATTENTION: Before changing the filter and cleaning it, switch the unit off and disconnect power. When removing the filter, pay attention as the sharp metal edges could cut you. Do not clean the inside of the indoor unit with water. This could damage the insulation and cause electric shocks or short circuit.
Page 47: Troubleshooting
TROUBLESHOOTING ATTENTION: If ONE of the following conditions occurs, switch the unit off immediately! • The power cable is damaged or excessively hot. • There is a burning smell. • The unit emits strong or anomalous noise. • When the circuit breaker trips often or when there are blown fuses. •...
Page 48 Problem Possible causes Solution The set temperature may be higher than the Lower the temperature setting. room temperature. The heat exchanger on the indoor or outdoor Clean the concerned heat exchanger unit is soiled The air filter is dirty Remove the filter and clean it as instructed The air inlet or outlet of one of the units is Switch the unit off, remove the obstruction blocked...
Page 49: Technical Data
TECHNICAL DATA GOTHA TECHNICAL DATA GOTHA Heating performance Rated output power (min - max) Btu/h 10,000 (2,800-11.500) 13,000 (3,640-14,950) Rated output power (min - max) 2.93 (0.82-3.37) 3.81 (1.07-4.38) Rated absorbed power Rated COP Rated absorbed current 2.83 4.24 Operating temperature °C -20/24 -20/24...
Page 50 THOR TECHNICAL DATA THOR Heating performance 10.000 13.000 18.400 25.000 Rated output power Btu/h (min - max) (2.800-11.500) (3.650-14.950) (10.580-19.960) (5.300-28.000) Rated output power 2.93 (0.82-3.37) 3.81 (1.07-4.38) 5.39 (3.1-5.85) 7,33 (1,55-8,21) (min - max) Rated absorbed power 1027 1.433 1.949 Rated COP 3.71...
Page 51 ST.007729/008 UI-UE THOR 9-12-18-24 UI-UE GOTHA 9-12...
Page 52 Immergas S.p.A. 42041 Brescello (RE) - Italy Tel. 0522.689011 immergas.com This instruction booklet is made of ecological paper.
