Summary of Contents for Immergas UI THOR
- Page 1 SMART KIT Instructions and WI-FI warnings UI THOR UI GOTHA UI CONS UI CAS...
- Page 2 Thank you for purchasing this product. Before using the unit, carefully read this manual and keep it for future reference. - This manual provides a detailed description of the precautions that you must pay attention to during use. - Read this manual carefully before using the Smart kit to guarantee its proper operation.
- Page 3 INDEX 1. Safety precautions..............4 2. Technical specifications............6 3. Installation accessories............7 4. Download and installation of the App.........8 5. Installation of Wi-fi module..........10 6. User registration..............16 7. Preparation for network configuration......17 8.
- Page 4 1. SAFETY PRECAUTIONS. WARNING: • Read the safety precautions carefully before installing the unit. • Below are important safety guidelines to be complied with: Applicable operating system: IOS, Android (IOS 12, Android 11.0 or higher) NOTE: • Due to the variety of operating systems and their ver- sions and the possibility of particular and unpredictable circumstances occurring, compatibility with all devices cannot be guaranteed.
- Page 5 App screen might not be the same: be careful therefore not to get confused. NOTE: • Immergas will not be responsible for any problems and/or criticality caused by the Internet or Wi-fi router.
- Page 6 2. TECHNICAL SPECIFICATIONS. Model THOR - GOTHA - CON- SOLE - CASSETTE wi-fi kit (EU-OSK105). Standard Wi-fi IEEE 802.11 b/g/n Software Version V 11.34.7 External omni-directional Type of antenna antenna Wi-fi frequency 2.4G Maximum power <20 dBM transmitted Operating 0°C ~ 45°C temperature Operating humidity 10% ~ 85%...
- Page 7 3. INSTALLATION ACCESSORIES. Operations prior to installation. Check that the following components are included in the package. Description Q.ty Notes USB Wi-fi stick Use and installation manual O n l y f o r Connection cable CAS kit...
- Page 8 4. DOWNLOAD AND INSTALLATION OF THE APP. WARNING: • The following QR codes have been provid- ed to be able to download our APP called “CLIMAsmart”.
- Page 9 Android users. Scan the dedicated QR code or go to Google Play, search for the “CLIMAsmart” app and download it. IOS users. Scan the dedicated QR code or go to App Store, search for the “CLIMAsmart” app and download it. Android...
- Page 10 5. INSTALLATION OF WI-FI MODULE. 1) Remove the protective cap on the smart kit...
- Page 11 Installation for THOR - GOTHA indoor unit. 2) Open the front panel of the air conditioner, remove the screw from the cover of the display and insert the Smart kit in the specific slot. Close the panel. WARNING: This interface is ONLY compatible with the Smart kit supplied by the manufacturer.
- Page 12 Installation for CONS indoor unit. 1) Open the panel: the display box is located on the front frame. front frame Panel 2) Remove the 4 clips from the display box and open the cover. The installation slot of the Smart kit is in the display box.
- Page 13 3) Remove the protective cap on the Smart kit, install it in the slot of the display box and connect to the con- nection cable. Lastly close the cover of the display box. cover it with smart kit the cover of the connection cable display box Install the smart kit on the...
- Page 14 Installation for CAS indoor unit. 1) Remove the protective cap on the Smart kit and connect it with the connection cable. Connection cable Smart kit Smart kit assembly 2) After having fitted the Smart kit as indicated in point 1, attach the smart kit assembly to the installation base, then install it on the front panel.
- Page 15 3) Connect the wire of the smart kit assembly to CN 38 WIFI port of the main board. 4) After having connected the connection cable, apply the cover of the electrical connection box and then the grid. WARNING: This interface is ONLY compatible with the Smart kit supplied by the manufacturer.
- Page 16 6. USER REGISTRATION. • Make sure that the mobile device is connected to the wireless router and that the router is already connected to the Internet before performing user registration. • If you’ve forgotten the password, press “Password forgotten?” and follow the procedure indicated on the App.
- Page 17 7. PREPARATION FOR NETWORK CONFIG- URATION. • You must disconnect from any other network in the vicinity and make sure that the Android or IOS device connects to the Wi-Fi network you want to configure. • Make sure that the Wi-fi function of the Android or IOS device works properly and can automatically reconnect to the original Wi-Fi network.
- Page 18 Use an Android or IOS device to configure the network. Make sure that your mobile device is already connect- ed to the Wi-Fi network you want to use. Make sure that the air conditioner is properly powered. Nota Bene When the air conditioner enters AP mode, its remote control cannot control it.
- Page 19 8. NETWORK CONFIGURATION (AUTO- MATIC METHOD). Make sure that the air conditioner is in AP mode, as shown on the previous page. 2. Wait for the device 1. Press “Add device” 3. Select the name of search, then click to the home network you add it want to connect the...
- Page 20 4. Wait for it to connect 5. Configuration 6. The device has been to the network successful. You may now configured successfully. modify the default name You can now see the of the air conditioner. device on the main screen.
- Page 21 9. NETWORK CONFIGURATION (MANUAL METHOD). If automatic configuration, shown on the previous page, fails, perform manual configuration. 2. Select the name of 3. Press the ‘LED’ key 1. Manually select the the home network you on the remote control type of product want to connect the 7 straight times, within air conditioner to and...
- Page 22 5. The device has been 4. The air conditioner configured successfully, you displays a temporary Wi-Fi may now modify the name of network, called ‘net_ac_xxxx’ , the air conditioner. which you may connect to with your mobile phone, by entering the password ‘12345678’...
- Page 23 10. HOW TO USE THE APP. Make sure that the air conditioner is connected to the home Wi-Fi network (see previous paragraph). 2. Choose the air 3. The available 1. Login conditioner to be functions are controlled displayed on the air conditioner screen...
- Page 24 Operating mode. The available modes are: Cooling Dehumidification Ventilation Automatic Central heating 1. Cooling 2. Dehumidification 3. Ventilation 4. Automatic 5. Central heating...
- Page 25 11. SPECIAL FUNCTIONS. Weekly schedule. You may set the weekly schedule of the air conditioner so that it switches on and off automatically. 1. Press ‘Schedules’ to 2. List of schedules 3. Setting a single modify them schedule...
- Page 26 Sleep curve. It is possible to set a sleep curve that takes into account the temperature and speed of the fan during the night, limiting noise and increasing air-conditioning comfort. The sleep curve can only be activated in central heating and cooling mode.
- Page 27 ATTENTION: If the air conditioner is used/controlled via App, this overrides the remote control. If a command/modification is entered by remote control, it will be received by the air conditioner and then by the App; on the contrary, if the command/modification is sent by the App, the remote control will remain in the previous situation.
- Page 28 WARNINGS: Model of wireless modules: EU-OSK105 IC: 24951-MZNA21 The manufacturer Immergas declares that the device complies with Directive 2014/53/EU. Only use the device according to the instructions provided. The manufacturer shall not be held liable in case of modifications or interventions not authorised by the manufacturer himself.
- Page 29 NOTE: This appliance generates, uses and can irradiate radiofre- quency energy and, if it not installed and used according to the instructions, can cause harmful interference with radio communications. Nonetheless, there is no guarantee that interference does not occur in a particular installation. If this appliance causes harmful interference to radio or television reception, which can be determined by switching the appliance off and back on, the user is encouraged to try...
- Page 32 Immergas S.p.A. 42041 Brescello (RE) - Italy Tel. 0522.689011 Fax 0522.680617...
