Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small
parts, which may have come loose inside the carton during shipment. Identify and count all items and
compare with the PARTS LIST and/or HARDWARE LIST shown below.
Caution: Please read the instructions thoroughly before assembly.
1. We recommend that you assemble this product with the assistance of another person; this will make the
assembly easier, and will help eliminate damage to the product or injury to persons during assembly.
2. Please do not over tighten screws or bolts until the assembly is completed.
3. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your
newly purchased product correctly and efficently.
PARTS LIST
NO:
COMPONENT
A
HEADBOARD
B
FOOTBOARD
C1
C2
D
HEADBOARD RAIL
E
SIDE RAIL
F
SLAT
G
SUPPORT LEG
H
CAP RAIL
Assembly Instructions
ITEM: B909 -110 BALBOA 6/6-6/0 K HEADBOARD
B909 -120 BALBOA 6/6-6/0 K FOOTBOARD & SLATS
B909 -230 BALBOA 6/0 WK SIDE RAILS
SKETCH
Q'TY
1 PC
1 PC
1 PC
1 PC
1 PC
2 PCS
4 PCS
8 PCS
2 PCS
MADE IN VIETNAM
HARDWARE LIST
NO:
COMPONENT
1
ALLEN KEY
2
BOLT 5/16"*1-1/2"L
3
LOCK WASHER 5/16"
4
5
BOLT Ø5/16"*3-1/2"L
6
HEX NUT 5/16"
7
U WASHER 5/16" DIA
8
WRENCH KEY
9
SCREW 8*1"
10
ALLEN KEY
BOLT 1/4"*1-3/4"L
11
SKETCH
Q'TY
1 PC
8 PCS
8 PCS
8 PCS
8 PCS
8 PCS
8 PCS
1 PC
8 PCS
1 PC
8 PCS
PAGE : 1 OF 4
Advertisement
Related Manuals for New Classic Furniture BALBOA B909-110
Summary of Contents for New Classic Furniture BALBOA B909-110
- Page 1 Assembly Instructions ITEM: B909 -110 BALBOA 6/6-6/0 K HEADBOARD B909 -120 BALBOA 6/6-6/0 K FOOTBOARD & SLATS B909 -230 BALBOA 6/0 WK SIDE RAILS Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose inside the carton during shipment.
- Page 2 Assembly Instructions ITEM: B909 -110 BALBOA 6/6-6/0 K HEADBOARD B909 -120 BALBOA 6/6-6/0 K FOOTBOARD & SLATS B909 -230 BALBOA 6/0 WK SIDE RAILS STEP 1 STEP 1 *DO NOT TIGHTEN THE BOLTS *DO NOT TIGHTEN THE BOLTS STEP 2 *TIGHTEN ALL THE BOLTS BY USING ALLEN KEY (1) MADE IN VIETNAM PAGE : 2 OF 4...
- Page 3 Assembly Instructions ITEM: B909 -110 BALBOA 6/6-6/0 K HEADBOARD B909 -120 BALBOA 6/6-6/0 K FOOTBOARD & SLATS B909 -230 BALBOA 6/0 WK SIDE RAILS STEP 3 Assemble side rails (E) with Headboard (A) and Footboard (B) by using Open Wrench (8) with hardware 5,6,7.
- Page 4 Assembly Instructions ITEM: B909 -110 BALBOA 6/6-6/0 K HEADBOARD B909 -120 BALBOA 6/6-6/0 K FOOTBOARD & SLATS B909 -230 BALBOA 6/0 WK SIDE RAILS STEP 5 Assemble the slat (F) to the side rails (E) by using a screwdriver with hardware 9. STEP 5 Install the cap rail (H) on to the side rails (E) by using Allen Key (10) with hardware 11 MADE IN VIETNAM...
