New Classic Furniture B976-110 Assembly Instructions

Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,
which may have come loose inside the carton during shipment. Identify and count all items and compare with
the parts list and hardware list shown below.
PARTS LIST
NO DESCRIPTION
A
HEADBOARD
B FOOTBOARD
C INNER BOX SUPPORT
D SIDE RAIL
E SLAT
F CENTER SLAT
G SLAT SUPPORT
B
BACK
VIEW
C
STEP 1 :
Install the INNER BOX SUPPORT (C)
to the FOOTBOARD (B) by using
the ALLEN KEY (5) with hardware
(1) and (3)
Adjust height of the adjuster for
stability and levelling.
STEP 2 :
Remove the drawer handle and
re-install the handle on the outside.
Created date: 6/28/2023
Revised date: 7/10/2023
PAGE 1 OF 2
B976-110
B976-128
B976-238
SKETCH QTY
1 PC
1 PC
2 PCS
2 PCS
1 SET
2 PCS
6 PCS
3
1
5
B
0 1
inch
0 1 2 3
cm
Assembly Instructions
RADIANCE 6/6-6/0 K HEADBOARD
RADIANCE 6/6-6/0 K STORAGE FOOTBOARD & SLATS
RADIANCE 6/0 WK STG BED SIDE RAILS
NO
JCBC BOLT - M6 x 1
1
2 JCBC BOLT - M6 x 1
3 SPRING WASHER - M6
4 CSK SCREW - M4 x 1
5 ALLEN KEY - M4
E
D
D
2 3
4 5 6 7
HARDWARE LIST
DESCRIPTION
SKETCH
3
"
8
5
"
8
1
"
4
PLACE WOOD PARTS ON A
CLEAN NON-ABRASIVE SURFACE
A
STEP 4 :
Insert the SLAT (E)
into the SIDE RAIL (D)
from the side of the
HEADBOARD (A).
STEP 3 :
BACK
VIEW
4
8 9 10
QTY
2 PCS
6 PCS
8 PCS
24 PCS
1 PC
Hook the SIDE RAIL (D)
to the FOOTBOARD (B)
closely and push down
to fit it.
