Shop Manual
FOREWORD
This
shop manual contains the specification,
construction, operation, adjustment and service pro­
cedures of the Model 6024 diesel engine for
service mechanics engaged in servicing of the
Mitsubishi die­sel engines.
Please make the most of this shop manual to perform
correct servicing and wasteless operations.
Note that some of the contents of this shop manual are
subject to change owing to improvements, etc. that
may be introduced after publication of this shop
manual.
Mitsubishi 6D24 6D24T Engine Maintenance Service Kits
Includes: thermostat set, thermostat gaskets, valve cover gaskets,
oil filters, air filters, fuel filters, V-belts.
Replace thermostats and thermostat gaskets,
Adjust intake valve clearance and exhaust valve clearance, replace valve cover gaskets,
Replace filters,
Replace V-belts.
Mitsubishi 6D24 6D24T Engine Parts
Contact email: EngineParts@HeavyEquipmentRestorationParts.com
Phone: 269 673 1638
GROUP INDEX
GENERAL .................................... •
...................................... .
ENGINE
LUBRICATION
FUEL AND ENGINE CONTROL
ELECTRONICALLY
CONTROLLED FUEL SYSTEM
................................... .
COOLING
INTAKE AND EXHAUST
ENGINE ELECTRICAL
..................................... .
CLUTCH
SPECIAL EQUIPMENT
