- Page 1 Assembly Instructions BUNDLE - ATRANI 5PC FURNITURE SET SKU 1053 1x 3 SEAT SOFA 2x ARMCHAIRS 1x LOVESEAT 1x COFFEE TABLE See following pages for individual component assembly instructions...
- Page 2 Thank you for your purchase. If you have any questions pertaining to the assembly of this furniture piece, please contact the nearest World Market store. If you are not near a store, please call our customer service call center toll free at 877-967-5362 for assistance.
- Page 3 Component List LABEL PICTURE DESCRIPTION QTY. SEAT FRAME FRONT FRAME LEGS BACKREST MIDDLE LEGS BACK CUSHION SEAT CUSHION PAGE 2...
- Page 4 Hardware List LABEL DESCRIPTION QTY. Large Bolt M6x50 mm Small Bolt M6x30 mm [2pcs pre-attached to Backrest (D)] Small Metal bracket T4xW45xL125 mm Large Metal bracket T4xW45xL190 mm [pre-attached to Backrest (D)] Tool List LABEL DESCRIPTION QTY. Allen Key 4 x 110 x 30 mm PAGE 3...
- Page 5 Assemble on a clean non-marring surface (such as the product’s packing foam). Do not discard any packaging until the product has been fully assembled. In case of missing parts, please contact your nearest World Market store or call our customer service call center at 1-877-967-5362.
- Page 6 Assembly Steps Step 1 (H-1) Large Bolt (M6x50) x 6 (T-1) Allen Key IMPORTANT:Please make note of the different hardware sizes and ensure you are using the correct size hardware (bolts, screws, and washers) for each step. Using a second person to assist you, position the Front Frame (B) with the Seat Frame (A) as shown above. Align the through holes in the Seat Fame (A) with the receiving holes in the Front Frame (B).
- Page 7 Assembly Steps Step 3 (H-2) Small Bolt (M6x30) x 4 (T-1) Allen Key IMPORTANT:Please make note of the different hardware sizes and ensure you are using the correct size hardware (bolts, screws, and washers) for each step. Position Middle Legs (E) to the down of the assembly as shown above. Align the through holes in the Middle Legs (E) with the receiving holes in the Seat Frame (A).
- Page 8 Assembly Steps Step 5 (H-2) Small Bolt (M6x30) x 6 (T-1) Allen Key Position the Backrest (D) onto the assembly, ensuring the Large and Small Metal Brackets (H-3 and H-4) and the brackets on the Front Frame (B) nest into the mortises under the Backrest (D). Loosely secure with Small Bolts (H-2) using the provided Allen Key (T-1).
- Page 9 Assembly Steps Step 7 Place the Seat Cushion (G) onto the assembly as shown. Note: the Seat Cushion (G) is directional and should be oriented correctly. Step 8 ADJUSTABLE LEVELER Levelers are located on the bottom of the 2 MIDDLE LEGS (E) and may be used for additional adjustment if needed for uneven surfaces.
- Page 10 Thank you for your purchase. If you have any questions pertaining to the assembly of this furniture piece, please contact the nearest World Market store. If you are not near a store, please call our customer service call center toll free at 877-967-5362 for assistance.
- Page 11 Component List LABEL PICTURE DESCRIPTION QTY. SEAT FRAME FRONT FRAME LEGS BACKREST BACK CUSHION SEAT CUSHION PAGE 2...
- Page 12 Hardware List LABEL DESCRIPTION QTY. Large Bolt M6x50 Small Bolt M6x30 [2pcs pre-attached to Backrest (D)] Metal bracket T4xW45xL406 [pre-attached to Backrest (D)] Tool List LABEL DESCRIPTION QTY. Allen Key 4 x 110 x 30 mm PAGE 3...
- Page 13 Assemble on a clean non-marring surface (such as the product’s packing foam). Do not discard any packaging until the product has been fully assembled. In case of missing parts, please contact your nearest World Market store or call our customer service call center at 1-877-967-5362.
- Page 14 Assembly Steps Step 1 List hardware and tools needed in upper left corner, showing their description name, illustration and quantity needed for the assembly step. (H-1) Large Bolt (M6x50) x 3 (T-1) Allen Key IMPORTANT:Please make note of the different hardware sizes and ensure you are using the correct size hardware (bolts, screws, and washers) for...
- Page 15 Assembly Steps Step 3 (H-2) Small Bolt (M6x30) x 2 (H-3) Metal bracket T4xW45xL406 (T-1) Allen Key IMPORTANT:Please make note of the different hardware sizes and ensure you are using the correct size hardware (bolts, screws, and washers) for each step. Step 4 List hardware and tools needed in upper left corner, showing their description name, illustration and quantity needed for the assembly step.
- Page 16 Assembly Steps Step 5 PAGE 7...
- Page 17 Assembly Steps Step 7 Place Back Cushions (E) onto the assembly as shown. Note: that the Back Cushions (E) are directional and should beoriented correctly. Assembly is now complete and the product is ready for use. NOTE: Hardware may loosen over time. Periodically check that all connections remain tight and adjust as needed.
- Page 18 Thank you for your purchase. If you have any questions pertaining to the assembly of this furniture piece, please contact the nearest World Market store. If you are not near a store, please call our customer service call center toll free at 877-967-5362 for assistance.
- Page 19 Component List LABEL PICTURE DESCRIPTION QTY. SEAT FRAME FRONT FRAME LEGS BACKREST BACK CUSHION SEAT CUSHION PAGE 2...
- Page 20 Hardware List LABEL DESCRIPTION QTY. Large Bolt M6x50 mm Small Bolt M6x30 mm [2pcs pre-attached to Backrest (D)] Small Metal bracket T4xW45xL125 mm Large Metal bracket T4xW45xL190 mm [pre-attached to Backrest (D)] Tool List LABEL DESCRIPTION QTY. Allen Key 4 x 110 x 30 mm PAGE 3...
- Page 21 Assemble on a clean non-marring surface (such as the product’s packing foam). Do not discard any packaging until the product has been fully assembled. In case of missing parts, please contact your nearest World Market store or call our customer service call center at 1-877-967-5362.
- Page 22 Assembly Steps Step 1 (H-1) Large Bolt (M6x50) x 5 (T-1) Allen Key IMPORTANT:Please make note of the different hardware sizes and ensure you are using the correct size hardware (bolts, screws, and washers) for each step. Using a second person to assist you, position the Front Frame (B) with the Seat Frame (A) as shown above. Align the through holes in the Seat Fame (A) with the receiving holes in the Front Frame (B).
- Page 23 Assembly Steps Step 3 (H-2) Small Bolt (M6x30) x 3 (H-3) Small Metal Bracket T4xW45xL125 x 2 (H-4) Large Metal Bracket T4xW45xL190 (T-1) Allen Key IMPORTANT:Please make note of the different hardware sizes and ensure you are using the correct size hardware (bolts,screws, and washers) for each step.
- Page 24 Assembly Steps Step 5 Step 6 Place the Seat Cushion (F) onto the assembly as shown. Note: the Seat Cushion (F) is directional and should be oriented correctly. PAGE 7...
- Page 25 Assembly Steps Step 7 Place Back Cushions (E) onto the assembly as shown. Note: that the Back Cushions (E) are directional and should be oriented correctly. Assembly is now complete and the product is ready for use. NOTE: Hardware may loosen over time. Periodically check that all connections remain tight and adjust as needed.
- Page 26 Thank you for your purchase. If you have any questions pertaining to the assembly of this furniture piece, please contact the nearest World Market store. If you are not near a store, please call our customer service call center toll free at 877-967-5362 for assistance.
- Page 27 Component List LABEL PICTURE DESCRIPTION QTY. Table Top Legs Hardware List LABEL DESCRIPTION QTY. Bolt M6x55 Flat washers Ø6.5/16x1 Locking Washers Ø6.5/10x1 Tool List LABEL DESCRIPTION QTY. Allen Key 4 x 110 x 30 mm PAGE 2...
- Page 28 Assemble on a clean non-marring surface (such as the product’s packing foam). Do not discard any packaging until the product has been fully assembled. In case of missing parts, please contact your nearest World Market store or call our customer service call center at 1-877-967-5362.
- Page 29 Assembly Steps Step 1 (H-1) Bolts (M6x55) x 8 (H-2) Flat Washers x 8 (H-3) Locking Washers x 8 (T-1) Allen Key 4x110x30mm Using a second person to assist you, lay Table Top (A) upside down onto a padded, non-marring surface. Secure one Leg (B) to the Table Top (A) with the Bolts (H-1), Flat Washers (H-2) and Locking Washers (H-3) using the provided Allen Key (T-1), stacking the hardware in the order as shown.
- Page 30 Dab the stain with light, even pressure. DO NOT rub the stain when spot cleaning. NOTE: World Market outdoor cushions provide a firm seat experience on initial use. This is normal and by design–with time and continued use, the cushions will break in and become softer. Always store the cushions when they are not in use.
- Page 31 Customer Service Call Center, Toll Free at 877-967-5362. For valid warranty claims, World Market will repair or replace the product, or offer a full or par�al credit, in the sole discre�on of World Market. This LIMITED ONE-YEAR WARRANTY gives you specific legal rights and you may also have other rights which vary from state to state.
