SKU
PRODUCT
PRODUCT SHORT DESCRIPTION
PRODUCT DETAILED DESCRIPTION
PRODUCT FEATURES
SYSTEM REQUIREMENT
OPERATING SYSTEM
FORM FACTOR
DIMENSIONS
WEIGHT
UPC
PACKAGE CONTENT
PRODUCT WEBPAGE
PRODUCT NOTES
California Health & Safety Notice : The solder used in this product contains lead, a chemical known to the State of California to cause birth
defects and other reproductive harm. Please wash hands after handling internal components and circuit boards and avoid inhalation of fumes if
heating the solder.
The information presented in this document is for information purposes only. The information contained herein is subject to change and may be rendered inaccurate for many reasons, including, but not limited to product and specification
changes, new model and/or product releases, product differences between differing manufacturers, software changes, BIOS flashes, firmware upgrades, or the like. Diamond Multimedia assumes no obligation to update or otherwise correct or
revise this information. Diamond Multimedia makes no representations or warranties with respect to the contents hereof and assumes no responsibility for any inaccuracies, errors or omissions that may appear in this information. However,
Diamond Multimedia reserves the right to revise this information and to make changes from time to time to the content hereof without obligation of Diamond Multimedia to notify any person of such revisions or changes. Please see your Diamond
Multimedia sales representative for any questions regarding this product information.
Diamond, Diamond Multimedia and Stealth are registered trademarks of Diamond Multimedia.
ATI, Graphics by ATI, and Radeon are trademarks of ATI Technologies, Inc.
All other trademarks are property of their respective owners.
© 2009 Diamond Multimedia. All rights reserved.
DIAMOND MULTIMEDIA - SPECIFICATION SHEET
SKU
3870PE4512
BRAND
HD 3800
February 4, 2011 - 6:25 am
3870PE4512
DIAMOND AMD ATI Radeon™ HD 3870 PCIE 512MB GDDR4 Video Card
INTERFACE
GPU
CORE CLOCK
MEMORY CLOCK
MEMORY CONFIGURATION
MEMORY TYPE
MEMORY BANDWIDTH
MEMORY SIZE
MEMORY CONTROLLER INTERFACE
PORTS
DUAL LINK DVI
The Diamond HD 3870 is a magnificent beast. A 700 million-transistor processing powerhouse, a technology statement
and dream come true for enthusiast gamers hungry for the fastest GPU ever made. Featuring a 2nd generation unified
shader architecture, massive processing power and an unprecedented 512-bit memory interface, HD 3870 will deliver
astonishing performance and the richest feature-set yet for a big ultra-high definition gaming experience with all of the
bells and whistles turned up to the max. The HD 3870 is quite simply a ticket to the future of PC gaming.
GPU: ATI Radeon™ 3870
Bus Type: PCI-Express X16 (PCI Express 2.0)
Core Clock: 775 MHZ
Memory Size: 512MB
Memory Configuration: 16Mx32 GDDR4
Memory Interface: 256-Bit
Memory Speed: 1125 MHz
API Support: DirectX® 9.0 and 10.1, OpenGL
Display Formats: Two Dual Link DVI + HDTV-Out (HDMI Support Via Adapter)
EXTERNAL POWER REQUIREMENT
CPU
CPU SPEED
MEMORY
HARD DISK
SYSTEM BUS
SLOT
CHASSIS
MONITOR
INTERNET ACCESS
USB
CD DVD
POWER SUPPLY
WINXP WINXP64 WINVISTA32 WINVISTA64 MCE WINNT_4PS6 WIN98SE WINME WIN2000 WIN2003
Standard Profile Full-Height
[PRODUCT] : 11.75 X 9.5 X 3 [RETAIL BOX] : 11.75 X 9.5 X 3 [S BUILDER] : 11.5 X 7.25 X 2
[PRODUCT WEIGHT] : 2.5 [PRODUCT WITH CONTENT WEIGHT] : 3.5
RETAIL PACKAGE UPC : 757448005738
DIAMOND HD 3870 PCIE 512MB GDDR4 VIDEO
CARD
QUICK START GUIDE
INSTALL CD
http://www.diamondmm.com/3870PE4512.php
PCI Express x16
HD 3870
775 MHZ
1.125GHz
16Mx32
GDDR4
116.9 GB/sec
512MB
256-Bit
Dual DVI , HDTV-out
Hydravision 4
6 pin mollex
480MB available hard disk space
PCI Express x16
DOUBLE
Digital flat-panel (DFP) displays or DVI-I Compatilbe or
digital CRT display or High-resolution VGA monitor
YES
A 450 Watt or greater (650 for CrossFire™) power supply
recommended
COMPONENT HDTV ADAPTER
CROSSFIRE BRIDGE INTERCONNECT
2 DVI-TO-VGA ADAPTERS
20740 Plummer St. Chatsworth, CA 91311
Tel: (818) 534-1414 Fax: (818) 773-9619
ENG APVD - LK 2008-05-08
MRKTG APVD - LL 2007-11-29
Diamond Multimedia
http://www.diamondmm.com
