Diamond Multimedia Radeon HD 4600 Setup Sheet

DIAMOND MULTIMEDIA
SKU
SYSTEM BUILDER SKU
PRODUCT
PRODUCT SHORT
DESCRIPTION
PRODUCT DETAILED DESCRIPTION
PRODUCT FEATURES
SYSTEM REQUIREMENT
OPERATING SYSTEM
PRODUCT DIMENSIONS
RETAIL BOX DIMENSIONS
4670PE31GDT_setup_sheet.xls
4670PE31GDT
Diamond Radeon HD 4670 GDDR3 1GB Video Card
INTERFACE
GPU
CORE CLOCK
MEMORY CLOCK
MEMORY CONFIGURATION
MEMORY TYPE
MEMORY BANDWIDTH
MEMORY SIZE
MEMORY CONTROLLER INTERFACE
DUAL MONITOR
DUAL LINK DVI
Loaded with the latest features, ATI RadeonTM HD 4600 Series graphics cards deliver a level of gaming
performance previously only found in high-end graphics cards. Redefine the way you play HD games and enjoy
unprecedented levels of graphics realism powered by 320 stream processing units, up to 1GB of memory and
support for Microsoft DirectX®10.1 games. Upgrade your graphics card and watch Blu-ray movies and play HD
content with incredible visual fidelity1. These graphics cards do it all with break-through energy efficiency,
eliminating the need for an external power connection and making them easy to install.
Superscale unified shader architecture
PCI Express x16 2.0 support
320 stream processing units
Direct X 10.1 / Shader Model 4.1
ATI Crossfire X Multi-GPU Support for highly scalable performance
Up to four GPU support with an AMD 790FX based motherboard
High-speed 128-bit-HDR (High Dynamic Range) rendering
55nm process technology
ATI Avivo HD Video and Display Technology
Game Physics processing capability
Up to 24X Custom Filter Anti-Aliasing
Built-in HDMI with Multi-channel 7.1 surround audio
On board HDMI connector (with adapter)
Unified Video Decoder (UVD 2) for Blu-ray and HD DVD
ATI PowerPlay energy conserving technology
OpenGL 2.0 Support
EXTERNAL POWER REQUIREMENT
SYSTEM REQUIREMENT CPU
SYSTEM REQUIREMENT CPU SPEED
SYSTEM REQUIREMENT MEMORY
SYSTEM REQUIREMENT POWER SUPPLY
SYSTEM REQUIREMENT SPECIAL INSTRUCTIONS
SYSTEM REQUIREMENT HARD DISK
SYSTEM REQUIREMENT BUS
SYSTEM REQUIREMENT STANDARD SLOT
SOLUTION
SYSTEM REQUIREMENT CHASSIS
SYSTEM REQUIREMENT MONITOR
SYSTEM REQUIREMENT INTERNET ACCESS
SYSTEM REQUIREMENT USB
SYSTEM REQUIREMENT CD DVD
SYSTEM REQUIREMENT OS WINXP
SYSTEM REQUIREMENT OS WINXP64
SYSTEM REQUIREMENT OS WINVISTA32
SYSTEM REQUIREMENT OS WINVISTA64
6.6 X 4.4 X .7 inches
11.75 X 9.5 X 3
Page 1 of 2
Product Setup Sheet
DATE : September 5, 2008 - 5:08 pm
PCI Express x16
HD4670
750 Mhz
900 Mhz
64Mx16
GDDR3
32 GB/sec
1024MB
128-Bit
2-Dual-Link DVI, S-Video
Hydravision 4
6-pin molex adapter
Min. Intel 2.0 Celeron, Pentium Intel Duo, AMD 3800+ or
higher
2.0 Ghz or faster
1024MB
400 Watt or higher
None
480MB available hard disk space
PCI Express x16
SINGLE
N/A
Digital flat-panel (DFP) displays or DVI-I Compatible or
digital CRT display or High-resolution VGA monitor
N/A
NO
YES
YES
YES
YES
YES
