Diamond Multimedia ATI Radeon HD 4850 Specification Sheet

SKU
PRODUCT
PRODUCT SHORT DESCRIPTION
PRODUCT DETAILED DESCRIPTION
PRODUCT FEATURES
SYSTEM REQUIREMENT
OPERATING SYSTEM
FORM FACTOR
DIMENSIONS
WEIGHT
UPC
PACKAGE CONTENT
PRODUCT WEBPAGE
PRODUCT NOTES California Health & Safety Notice : The solder used in this product contains lead, a chemical known to the State of California to cause birth
defects and other reproductive harm. Please wash hands after handling internal components and circuit boards and avoid inhalation of fumes if
heating the solder.
The information presented in this document is for information purposes only. The information contained herein is subject to change and may be rendered inaccurate for many reasons, including, but not limited to product and specification
changes, new model and/or product releases, product differences between differing manufacturers, software changes, BIOS flashes, firmware upgrades, or the like. Diamond Multimedia assumes no obligation to update or otherwise correct or
revise this information. Diamond Multimedia makes no representations or warranties with respect to the contents hereof and assumes no responsibility for any inaccuracies, errors or omissions that may appear in this information. However,
Diamond Multimedia reserves the right to revise this information and to make changes from time to time to the content hereof without obligation of Diamond Multimedia to notify any person of such revisions or changes. Please see your Diamond
Multimedia sales representative for any questions regarding this product information.
Diamond, Diamond Multimedia and Stealth are registered trademarks of Diamond Multimedia.
ATI, Graphics by ATI, and Radeon are trademarks of ATI Technologies, Inc.
All other trademarks are property of their respective owners.
© 2009 Diamond Multimedia. All rights reserved.
DIAMOND MULTIMEDIA - SPECIFICATION SHEET
SKU 4850PE3512
BRAND HD 4800
February 4, 2011 - 6:24 am
4850PE3512
DIAMOND AMD ATI Radeon™ HD 4850 512MB GDDR3 Video Card
INTERFACE
GPU
CORE CLOCK
MEMORY CLOCK
MEMORY CONFIGURATION
MEMORY TYPE
MEMORY BANDWIDTH
MEMORY SIZE
MEMORY CONTROLLER INTERFACE
PORTS
DUAL LINK DVI
Redefine HD Gaming The ATI Radeon HD 4800 Series GPUs deliver a cinematic gaming experience with unprecedented
performance. The powerful new TeraScale graphics will propel you deep into your gameplay with seamless frame rates
and high resolutions. Enhanced anti-aliasing (AA) and anisotropic filtering create
striking graphics with unparalleled realism so you can max out the settings of the most demanding next-generation games
or revitalize your favorite titles. Play today while preparing for tomorrow with tessellation, support for DirectX® 10.1 and
scalable ATI CrossFireX™ technology.
GPU: Radeon™ HD4850
Bus Type: PCI-Express
Core Clock: 625 MHz
Memory Size: 512MB
Memory Configuration: 16Mx32 GDDR3
Memory Interface: 256-Bit
Memory Speed: 993 MHz
800 Stream Processors
Two Dual Link DVI + HDTV-Out (HDMI support VIA Adapter)
EXTERNAL POWER REQUIREMENT
CPU
CPU SPEED
MEMORY
HARD DISK
SYSTEM BUS
SLOT
CHASSIS
MONITOR
INTERNET ACCESS
USB
CD DVD
POWER SUPPLY
WINXP WINXP64 WINVISTA32 WINVISTA64 MCE
Standard Profile Full-Height
[PRODUCT] : 11.75 X 9.5 X 3 [RETAIL BOX] : 11.75 X 9.5 X 3 [S BUILDER] : 11.75 X 7.25 X 2
[PRODUCT WEIGHT] : 2.75 LBS [PRODUCT WITH CONTENT WEIGHT] : 3.55 LBS
RETAIL PACKAGE UPC : 757448006285
DIAMOND VIPER HD 4850 PCIE 512MB GDDR3
VIDEO CARD
QUICK START GUIDE
INSTALL CD
http://www.diamondmm.com/4850PE3512.php
PCI Express x16
HD 4850
625 Mhz
993 Mhz
16Mx32
GDDR3
147GB/sec
512MB
256-bit
2 Dual-Link DVI,Video Out [S-Video, Composite, HDTV]
Hydravision 4
6 pin
Min. Intel 2.0 Celeron, Pentium Intel Duo, AMD 3800+ or
higher
2.0 Ghz or faster
1024MB
400 MB
PCI Express x16
SINGLE
ATX
Digital flat-panel (DFP) displays or DVI-I Compatilbe or
digital CRT display or High-resolution VGA monitor
NO
NO
NO
450 Watt or greater power supply with 75 Watt 6-pin PCI
Express® power connector recommended.
S-VIDEO CABLE
CROSSFIRE BRIDGE INTERCONNECT
COMPONENT HDTV ADAPTER
DVI-TO-VGA ADAPTER
DIAMOND WARRANTY CARD
DVI-TO-HDMI ADAPTER
20740 Plummer St. Chatsworth, CA 91311
Tel: (818) 534-1414 Fax: (818) 773-9619
ENG APVD - LK 2008-06-11
MRKTG APVD - LL 2008-06-19
Diamond Multimedia
http://www.diamondmm.com
