Diamond Multimedia SKU 4870X2PE52G Specification Sheet

SKU
PRODUCT
PRODUCT SHORT DESCRIPTION
PRODUCT DETAILED DESCRIPTION
PRODUCT FEATURES
SYSTEM REQUIREMENT
OPERATING SYSTEM
FORM FACTOR
DIMENSIONS
WEIGHT
UPC
PACKAGE CONTENT
PRODUCT WEBPAGE
PRODUCT NOTES California Health & Safety Notice : The solder used in this product contains lead, a chemical known to the State of California to cause birth
defects and other reproductive harm. Please wash hands after handling internal components and circuit boards and avoid inhalation of fumes if
heating the solder.
Diamond, Diamond Multimedia and Stealth are registered trademarks of Diamond Multimedia.
ATI, Graphics by ATI, and Radeon are trademarks of ATI Technologies, Inc.
All other trademarks are property of their respective owners.
© 2009 Diamond Multimedia. All rights reserved.
DIAMOND MULTIMEDIA - SPECIFICATION SHEET
SKU 4870X2PE52G
BRAND HD 4800
May 4, 2009 - 4:13 pm
4870X2PE52G
DIAMOND ATI Radeon™ HD 4870 X2 PCIE 2048MB GDDR5 Video Card
INTERFACE
GPU
CORE CLOCK
MEMORY CLOCK
MEMORY CONFIGURATION
MEMORY TYPE
MEMORY BANDWIDTH
MEMORY SIZE
MEMORY CONTROLLER INTERFACE
PORTS
DUAL LINK DVI
ATI Avivo™ HD Video & Media
The ATI Radeon HD 4000 Series of GPUs allow you to experience the power of HD with graphics processing designed for
how you work and play. The Diamond Radeon™ HD 4870 X2 delivers outstanding performance at a great price. Advance
to the next generation of HD game performance and life-like realism thanks to DirectX® 10.1 capabilities and
plug-and-play ATI CrossFireX™ multi-GPU upgradeability. Watch the latest Blu-ray and HD-DVD videos in full 1080p HD
and upscale beyond - without placing huge demands on your CPU. Enjoy break-through efficiency with more processing
performance per watt and energy-saving features to help save you money.
GPU: Radeon™ HD4870 X2
Bus Type: PCI-Express
Core Clock: 750 MHZ x 2
Memory Size: 2048MB
Memory Configuration: 64Mx32 GDDR5
Memory Interface: 256-Bit X 2
Memory Speed: 900 MHz x 2
Two Dual Link DVI + HDTV-Out (HDMI support VIA Adapter)
EXTERNAL POWER REQUIREMENT
CPU
CPU SPEED
MEMORY
HARD DISK
SYSTEM BUS
SLOT
CHASSIS
MONITOR
INTERNET ACCESS
USB
CD DVD
POWER SUPPLY
MCE WINXP WINXP64 WINVISTA32 WINVISTA64
Standard Profile Full-Height
[PRODUCT] : 11.75 X 9.5 X 3 [RETAIL BOX] : 11.75 X 9.5 X 3 [S BUILDER] : 11.75 X 7.25 X 2
[PRODUCT WEIGHT] : 2.75 LBS [PRODUCT WITH CONTENT WEIGHT] : 3.55 LBS
RETAIL PACKAGE UPC : 757448006490
DIAMOND ATI RADEON HD 4870X2 PCIE 2048MB
GDDR5 VIDEO CARD
QUICK START GUIDE
INSTALL CD
http://www.diamondmm.com/4870X2PE52G.php
PCI Express x16
HD 4870 X2
750 MHZ x 2
900 MHz x 2
64Mx32
GDDR5
180.6 GB/sec
2048MB
256-Bit x 2
2 Dual-Link DVI,Video Out [S-Video, Composite, HDTV]
Hydravision 4
6 pin & 8 pin Molex
Min. Intel 2.0 Celeron, Pentium Intel Duo, AMD 3800+ or
higher
2.0 Ghz or faster
1024MB
480MB available hard disk space
PCI Express x16
DOUBLE
N/A
Digital flat-panel (DFP) displays or DVI-I Compatilbe or
digital CRT display or High-resolution VGA monitor
N/A
NO
YES
550 Watt or greater power supply with 75 Watt 6-pin and
8-pin PCI Express® power connector recommended.
S-VIDEO CABLE
CROSSFIRE BRIDGE INTERCONNECT
COMPONENT HDTV ADAPTER
DVI-TO-VGA ADAPTER
DVI-TO-HDMI ADAPTER
Diamond Multimedia 9650 DeSoto Ave
Tel: (818) 534-1414 Fax: (818) 773-9619
ENG APVD - LK 2008-07-03
MRKTG APVD - LL 2008-05-31
Chatsworth, CA 91311
