- Page 1 REFRIGERATOR INSTRUCTION MANUAL Model No.: GLR18TMBEER GLR18TMBKER GLR18TMRDER GLR18TMWEER GLR18TMTEER To ensure proper use of this appliance and your safety, please read the instruction manual completely before operating this appliance.
- Page 2 Please follow the operating instructions and safety notices in the manual. If any trouble arise, do not fix it yourself or hand it to the after sales service center which has not been authorized. Please contact Galanz customer service at 1-800-562-0738.
- Page 3 PRODUCT OVERVIEW 1. Ice maker 2. Ice bucket 3. Freezer shelf 4. Water dispenser 5. Refrigerator shelf 6. Deli box 7. Crisper cover 8. Crisper 9. Freezer door bin 10. Dairy box 11. Upper door bin 12 . Gallon door bin 13.
- Page 4 SAFETY WARNINGS For ensure your personal safety, please follow the points below: 1. The circuitry for refrigerator must be isolated. The area of cross section of wire must be larger than 0.75mm . The power plug should have its own socket, the socket must be ground as adapter may cause the socket to overheat.
- Page 5 NOTICE: When gas leaks from its container, don't pull the plug, out or in, for it may arouse sparks and fire calamities. Don't splash water on the rear of the appliance, for it may cause malfunction or electric shock. Don't stor inflammabe materials such as ether, benzene, LP gas and glue etc in the refrighterator.
- Page 6 INSTALLING THE HANDLES Take out the handle accessories bag: handle base (2 pcs), handle cover (2 pcs), screw(6pcs). Prepare a cross screwdriver. Handle Handle cover Screw 3.Fixed the handle base with 3 pcs screws. 4. Assemble the handle cover. (1) Buckle up the left side of handle first. (2) The buckle up the right side fastener of handle.
- Page 7 OPERATION PLACEMENT OF FOOD There should always be some space between items inside for air circulation. Food should be kept in sealed package to avoid becoming dry or with odour. Hot food should be cooled down before placing into the appliance.
- Page 8 ICE MAKER (Optional Accessory for Some Models) After turning on your refrigerator, the ice will start to be made between 12 and 24 hours. Power Button The ice maker produces 3.5 lbs ice per day, depending on the temperature of the freezer, the times in which the door opens, and other using conditions (amount of food in the freezer, etc).
- Page 9 3. Use the screws to fix the bottom of ice maker into the side wall of the box. CONNECT WATER SUPPLY (For Models with Ice Maker) If you need the ice maker function and have purchased and installed the ice maker module, you will also need to connect the water supply. What you need 1.
- Page 10 1. Place end of water supply line into sink or bucket. Turn On water supply and flush supply line until water is clear. Turn OFF water supply at shut off valve. 2. Remove the plastic flexible cap from the water valve inlet. 3.
- Page 11 DEFROST Defrost of refrigerator will be executed automatically during product running, so it is no requirement for manual defrost. The defrost water flows into the vaporization plate and will be vaporized by the heat of compressor. So its drain tube must be cleaned. Do not use mechanical devices or other means to accelerate the Warning defrosting process, other than those recommended by the manufacturer...
- Page 12 TROUBLESHOOTING TIPS The refrigerator does not work It may not be connected to the power supply(plug, power cut or fuse); Voltage is too low. The refrigerator does not work efficiently as expected It may be caused by heavy frost, or by warm temperature setting,or by frequently door operating.
- Page 13 The follow cases are not malfunction Moisture may form dew on the outside of the product during the humid season, just get it wiped. The flow of refrigerant through the pipeline coil can cause a bicker. It is normal that the sides of product get warm as a result of the cooling pipeline working. The frame of the appliance will be warm during working by the defrost pipeline inside it.
- Page 14 Product Warranty This warranty applies to products sold by Galanz Americas in the U.S. This warranty is in lieu of any other warranty and expressly applies to the individual product only. Galanz product is warrantied for one year following purchase or date of delivery, which ever is later for defects in material and workmanship.
