- Page 1 ETL-ES-Oasis-Damp-WH25 OWNER'S MANUAL MANUAL DEL USUARIO Oasis Please write model number here for future reference: Por favor, incluya el número del modelo aquí para futura referencia: Net Weight: Peso Neto:...
- Page 2 ETL-ES-Oasis-Damp-WH25 SAFETY TIPS OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY, MOUNT TO OUTLET BOX MARKED 'ACCEPTABLE FOR FAN SUPPORT OF 35 LBS (15.9 KG) OR LESS' AND USE MOUNTING SCREWS PROVIDED WITH THE OUTLET BOX AND/OR SUPPORT DIRECTLY FROM BUILDING STRUCTURE. MOST OUTLET BOXES COMMONLY USED FOR THE SUPPORT OF LUMINARIES ARE NOT ACCEPTABLE FOR FAN SUPPORT AND MAY NEED TO BE REPLACED.
- Page 3 ETL-ES-Oasis-Damp-WH25 CONSEJOS DE SEGURIDAD HAGA LO SIGUIENTE: LEA Y GUARDE ESTAS INSTRUCCIONES ADVERTENCIA: PARA REDUCIR EL RIESGO DE INCENDIO, DESCARGA ELÉCTRICA O HERIDAS GRAVES PERSONALES, MONTE EN UNA CAJA DE EMBUTIR ROTULADA 'ACCEPTABLE FOR FAN SUPPORT OF 35 LBS (15.9 KG) OR LESS' UTILIZANDO LOS TORNILLOS DE MONTAJE INCLUIDOS CON LA CAJA DE EMBUTIR Y/O MONTE DIRECTAMENTE EN LA ESTRUCTURA DEL EDIFICIO LA MAYORÍA DE LAS CAJAS DE EMBUTIR UTILIZADAS NORMALMENTE CON ARTEFACTOS DE ILUMINACIÓN NO SON ADECUADAS PARA VENTILADORES Y DEBERÍAN SER...
- Page 4 ETL-ES-Oasis-Damp-WH25 FEATURES CARACTERÍSTICAS DOWNROD INSTALLATION INSTALACIÓN CON VARILLA VERTICAL Note: For pitched ceiling installation, please refer to westinghouselighting. com for specially designed canopy kit options. Nota: Para instalación en techos inclinados,visite westinghouselight- ing.com para obtener opciones sobre equipos de dosel especialmente For normal ceilings diseñados.
- Page 5 ETL-ES-Oasis-Damp-WH25 PREPARING FOR INSTALLATION ANTES DE LA INSTALACIÓN Use metal outlet box suitable for fan support (must support 35 lbs). Before attaching fan to outlet box, ensure the outlet box is securely fastened by at least two points to a structural ceiling member (a loose box will cause the fan to wobble).
- Page 6 ETL-ES-Oasis-Damp-WH25 MOUNTING BRACKET INSTALLATION INSTALACIÓN CON SOPORTE DE MONTAJE Remove the screws from the two mating holes (2) on the canopy. Loosen (do not remove) the screws in the mating slots (1) on the canopy. Rotate the mounting bracket and remove from the canopy.
- Page 7 ETL-ES-Oasis-Damp-WH25 MOUNTING BRACKET INSTALLATION INSTALACIÓN CON SOPORTE DE MONTAJE Install mounting bracket to outlet box in ceiling using the screws and washers provided with the outlet box. Instale el soporte de montaje a la caja de embutir del techo con la tornillería suministrada con la caja de embutir.
- Page 8 ETL-ES-Oasis-Damp-WH25 DOWNROD PREPARATION PREPARACION DE LA VARILLA VERTICAL Remove clamp pin (2) and cross pin (1) from down rod. Loosen set screws in down rod ball (3) until ball moves easily up and down the down rod. Do not remove groundwire (4) from ball.
- Page 9 ETL-ES-Oasis-Damp-WH25 DOWNROD INSTALLATION INSTALACION DE LA VARILLA VERTICAL Re-install cross pin into down rod and slide down rod ball up until cross pin Insert the down rod or extended down rod through the canopy and coupling fits firmly into ball. Tighten set screws in ball. Note: For the extended down cover.
- Page 10 ETL-ES-Oasis-Damp-WH25 NORMAL DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL NORMAL Choose a MOUNTING OPTION, either Normal Downrod Option using the included downrod, or Extended Downrod Option using a longer downrod (purchased separately). Insert motor wires through the selected downrod and insert the downrod into the downrod coupling. Make sure to align the hole in the downrod with the hole in the downrod coupling.
- Page 11 ETL-ES-Oasis-Damp-WH25 BLADE INSTALLATION INSTALACIÓN DE LAS ALETAS Check the motor for plastic shipping stabilizer tabs (1), and remove them if they are present. Attach blade assembly to motor using the noise-dampening motor gaskets and motor screws (2) provided. Tighten screws ecurely. NOTE: Some models do not utilize motor gaskets, washers, or stabilizer tabs.
- Page 12 ETL-ES-Oasis-Damp-WH25 MOUNTING WIRING OPTIONS OPCIÓN DE CABLEADO MONTAJE Carefully lift fan assembly onto mounting bracket. Rotate fan until notch on downrod ball (1) engages the ridge on the mounting bracket (2). This will allow for hands free wiring. Levante con cuidado el conjunto del ventilador hasta el soporte de mon- After hanging fan onto the mounting bracket, make sure plug connector taje.
- Page 13 ETL-ES-Oasis-Damp-WH25 WIRING OPTIONS OPCIÓN DE CABLEADO OPCIÓN DE CABLEADO PARA CONTROL REMOTO REMOTE CONTROL WIRING OPTION While fan is hanging on bracket, plug 4-pole connector from the fan into Mientras el ventilador cuelga del soporte, enchufe el conector de 4 polos del the 6-pole plug connector from the remote receiver.
- Page 14 ETL-ES-Oasis-Damp-WH25 SECURE TO CEILING ASEGURE EL VENTILADOR AL TECHO For downrod fans, slide the canopy up to the mounting bracket. Para ventiladores con varilla vertical, deslice el dosel hacia arriba hasta el soporte de montaje. The canopy has two mating slots (1) and two mating holes (2). Position both slots on canopy directly under and in line with two screws in the mounting bracket (3). Lift the canopy, allowing the two screws to slide into the mating slots.
- Page 15 ETL-ES-Oasis-Damp-WH25 HOW TO OPERATE YOUR CEILING FAN INSTRUCCIONES PARA OPERAR SU VENTILADOR DE TECHO Mount the transmitter holder onto the wall using screws provided. Place the transmitter into the holder. Monte el soporte para el transmisor a la pared usando los tornillos incluidos. Coloque el transmisor en el soporte.
- Page 16 ETL-ES-Oasis-Damp-WH25 HOW TO OPERATE YOUR CEILING FAN INSTRUCCIONES PARA OPERAR SU VENTILADOR DE TECHO Remote Control Operation The remote buttons function as follows: Symbol from the transmitter - press and release reflects the fan ON/OFF function. Symbol from the transmitter-Speed up button, continuously press & release the button, controls the fan speeds from the lowest/1 speed to the highest/6 speed.
- Page 17 ETL-ES-Oasis-Damp-WH25 HOW TO OPERATE YOUR CEILING FAN INSTRUCCIONES PARA OPERAR SU VENTILADOR DE TECHO Restore electrical power to the outlet box by turning on the electricity at the main fuse box. To make the fan operational, open battery door by pressing and sliding down the battery door.
- Page 18 ETL-ES-Oasis-Damp-WH25 HOW TO OPERATE YOUR CEILING FAN INSTRUCCIONES PARA OPERAR SU VENTILADOR DE TECHO Restaure la energía eléctrica a la caja de embutir encendiendo la electricidad en la caja de fusibles principal. Para que el ventilador funcione, abra la puerta de la batería presionando y deslizándola hacia abajo.
- Page 19 ETL-ES-Oasis-Damp-WH25 Appendix for alternate installation options EXTENDED DOWNROD OPTION (see page # 20 to page #21) Apéndice para opciones de instalación alternativas OPCIÓN CON VARILLA VERTICAL MÁS LARGA (consulte a la página # 20 a la página #21)
- Page 20 ETL-ES-Oasis-Damp-WH25 EXTENDED DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL MÁS LARGA Slide downrod ball (1) off of downrod and remove pin (2). Loosen downrod ball (1) from downrod (2) by removing set screw (3). Deslice la bola de la varilla vertical (1) hasta separarla de la varilla vertical y quite el pasador (2).
- Page 21 ETL-ES-Oasis-Damp-WH25 EXTENDED DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL MÁS LARGA Re-install pin into extended downrod, and slide downrod ball up to the top of the downrod. Re-install set screw to secure ball to downrod. Note: Some extended downrods have a pre-drilled set-screw hole. If a pre-drilled hole is present in the extended downrod, tighten the set screw into the pre-drilled hole in the extended downrod.
- Page 22 ETL-ES-Oasis-Damp-WH25 OPERATION AND MAINTENANCE Operation Turn on the power and check operation of fan. Speed settings for warm or cool weather depend on factors such as room size, ceiling height, number of fans and so on. The slide switch controls direction, forward or reverse.
- Page 23 ETL-ES-Oasis-Damp-WH25 OPERACIÓN Y MANTENIMIENTO Operación Encienda el ventilador y verifique su funcionamiento. Las velocidades para clima cálido o frío dependen de factores como el tamaño de la habitación, la altura del ventilador, el número de ventiladores, etc. El interruptor deslizante controla la dirección, hacia adelante o hacia atrás.
- Page 24 ETL-ES-Oasis-Damp-WH25 TROUBLESHOOTING If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, GUIDE please check this Trouble Shooting Chart. If a problem cannot be remedied, please consult with your qualified electrician and do not attempt any electrical repairs yourself.
- Page 25 ETL-ES-Oasis-Damp-WH25 GUÍA PARA SOLUCIONAR Si tiene dificultades para hacer funcionar su nuevo ventilador, podría ser a causa del armado, instalación o cableado incorrectos. En algunos casos, estos errores de PROBLEMAS instalación podrían ser confundidos con defectos. Si experiencia algun fallo, consulte esta guía para solucionar problemas.
- Page 26 GARANTÍA Este ventilador de Westinghouse Lighting se ofrece con una garantía limitada de por vida para el propietario original frente a defectos de material y de mano de obra. Esta garantía sustituye cualquier otra garantía expresa o implícita.
- Page 27 ETL-ES-Oasis-Damp-WH25 PARTS LIST LISTA DE REPUESTOS ... Description ... Mounting Bracket ... Blade .
- Page 28 ETL-ES-Oasis-Damp-WH25 Westinghouse Lighting, Philadelphia, PA 19154-1029, U.S.A. www.westinghouselighting.com and Westinghouse are trademarks of Westinghouse Electric Corporation. Used under license by Westinghouse Lighting. All Rights Reserved. Made in China...
