Ericsson E1 Quick Start Manual
Hide thumbs Also See for E1:

Advertisement

Quick Links

Quick start guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the E1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ericsson E1

  • Page 1 Quick start guide...
  • Page 4 What's included Air Mouse Remote USB-C U.S. HDMI USB-C to Remote Control Power Supply Power Cable Video Cable USB-A Adapter Charging Cable...
  • Page 5 Air Mouse Remote Mouse Mode Indicator (Blue Light) Charging Indicator (Red Light) Power On/Off Activate Voice Control (Short Press) Enable/Disable Mouse Home (Long Press) Back (Short Press) Switch Apps Quit App (Long Press) Volume - Volume +...
  • Page 6 Turn your E1 upside down Bottom Cameras Microphones USB-C ports HDMI port Power Button Ethernet port(s) (if you have a router unit, it has two Ethernet ports)
  • Page 7 Connect the HDMI cable to your TV...
  • Page 8 Connect the Power Supply Connect Power Supply cable to USB-C port on E1 Connect Power cable to Power Supply Plug into wall outlet...
  • Page 9 Connect via Ethernet (optional) If you would rather connect via Wi-Fi, you may do so using the on-screen setup once your device is connected to your TV.
  • Page 10 Use your E1 as a Wireless Access Point (optional) If your E1 is a router model, you may use it as a Wireless Access Point to connect other Wi-Fi devices. Connect the WAN port to your modem.
  • Page 11 Power on Briefly press Power button. Wait for button to turn green.
  • Page 12 Turn your E1 right side up Bottom...
  • Page 13 Placement HDMI 1 HDMI 2 HDMI 3 Position E1 right side up with cameras facing forward. Ensure the cameras have an unobstructed view of the room. Power on your TV, then select the HDMI input connected to your E1...
  • Page 14 Success Setup screen should appear on your TV. Press "OK" on the Air Mouse Remote to begin. Follow the instructions on your screen. Welcome to E1 Start...
  • Page 15 Charging your Air Mouse Remote Connect Remote Charging cable to Remote Connect Remote Charging cable to USB-C to USB-A adapter Connect USB-C Adapter to USB-C port on E1...
  • Page 16 Charging a Game Controller (Game controller not included) Connect Game Controller cable to Game Controller Connect Game Controller cable to USB-C to USB-A adapter Connect USB-C Adapter to USB-C port on E1...
  • Page 17 Remote with my E1? not a picture? The Air Mouse Remote is pre-paired to the E1. If you notice the Mouse Mode Indicator The input/source on your TV might not be flash slowly, [Blue Light on the remote] set up correctly. Not to worry, there's a quick pairing has been lost.
  • Page 18 Do not cover Keep the vents of your E1 open. To prevent overheating, do not cover or place objects on top.
  • Page 21 Regulatory Information Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
