- Page 1 HW-AV-LTE-M-FL CLSS Pathway Pro Installation and Operations Manual LS10412-000FL-E 00057355 Rev. A | May 2025...
- Page 2 Firelite | HW-AV-LTE-M-FL FIRE ALARM & EMERGENCY COMMUNICATION SYSTEM LIMITATIONS Audible warning devices such as bells, horns, strobes, speakers While a life safety system may lower insurance rates, it is not a and displays may not alert people if these devices are located on the substitute for life and property insurance! other side of closed or partly open doors or are located on another floor of a building.
-
Page 3: Installation Precautions
FAAST®, NOTIFIER®, ONYX®, ONYXWorks®, SWIFT®, VeriFire®, Verify that wire sizes are adequate for all initiating and indicating a are all registered trademarks of Honeywell International Inc. device loops. Most devices cannot tolerate more than a 10% I.R. drop Microsoft® and Windows® are registered trademarks of the Microsoft from the specified device voltage. -
Page 4: Software Downloads
• Brief description of content you think should be improved or corrected • Your suggestion for how to correct/improve documentation Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services. -
Page 5: Table Of Contents
1.2 Safety Instructions Section 2: Product Description 2.1 Main Features 2.2 Specifications Section 3: Mounting and Wiring the communicator for Listed Honeywell Firelite Addressable FACP 3.1 Wiring the Communicator 3.2 Mounting to the Listed Fire Alarm Panels 3.3 Mounting the Antenna 3.4 Programming the Alarm Panel... -
Page 6: Section 1: About This Document
Firelite | HW-AV-LTE-M-FL SECTION 1: ABOUT THIS DOCUMENT This document was prepared and wholly owned by Honeywell. It is intended to provide trained personnel with the installation of the HW-AV-LTE-M-FL. Honeywell reserve the right to edit and revise this manual without notice. -
Page 7: Section 2: Product Description
Firelite | HW-AV-LTE-M-FL SECTION 2: PRODUCT DESCRIPTION HW-AV-LTE-M-FL includes: • HW-AV-LTE-M • EXT-HW-485 extension board • GSM Antenna with 3 feet cable • Mounting Plate • Antenna mounting bracket The HW-AV-LTE-M-FL is a digital cellular communicator. It represents the latest communication technology for the security industry. -
Page 8: Specifications
Firelite | HW-AV-LTE-M-FL 2.2 SPECIFICATIONS Table 2.1 Specifications Characteristics Technical Specifications Supply Voltage 24V – Powered directly from the ribbon cable of the Fire Alarm Control Panel; Standby: 80mA Consumption Transmission: 85mA Frequency LTE CAT-M1 700/850/1700/1900/2100 MHz GSM Providers AT&T, Verizon, or other available networks in the area Dimensions 2.48”... -
Page 9: Section 3: Mounting And Wiring The Communicator For Listed Honeywell Firelite Addressable Facp
The communicator must be connected to J6 on the panel with a 10-pin ribbon cable (not included in the HW-AV-LTE- M-FL). Figure 3-1: Wiring Diagram for Listed Firelite FACPs 3.1.1 10 PIN RIBBON CABLE (INCLUDED WITH LISTED HONEYWELL FIRELITE SERIES) Vendor is to mark the cable with the following: vendor identification (logo/lettering), part number, current revision, and date of manufacture. -
Page 10: Mounting To The Listed Fire Alarm Panels
Firelite | HW-AV-LTE-M-FL 3.2 MOUNTING TO THE LISTED FIRE ALARM PANELS 01. Mount the communicator board onto the alarm panel. 02. Tighten the screws to secure the board. 03. Mount and connect the antenna by following the instructions in 3.3 Mounting the Antenna Figure 3-2: Mounting HW-AV-LTE-M-FL to the Listed Fire Alarm Panel Installation and Operations Manual | Rev. -
Page 11: Mounting The Antenna
Firelite | HW-AV-LTE-M-FL 3.3 MOUNTING THE ANTENNA 01. Route the antenna outside of the enclosure. 02. Attach the antenna to the top wall of the enclosure. 03. Secure the antenna by tightening the nuts from below, as shown in Figure 3-3: Antenna and antenna bracket 04. -
Page 12: Programming The Alarm Panel
Firelite | HW-AV-LTE-M-FL 3.4 PROGRAMMING THE ALARM PANEL 01. Press the “Menu” button on the mainboard. The “ESC” button is for going back to a previous menu and exit programming mode. 02. Press 2 to select Programming Mode and a screen will prompt for a password. 03. -
Page 13: Communicator Led Indications
Firelite | HW-AV-LTE-M-FL 3.5 COMMUNICATOR LED INDICATIONS LED Status Indication Action The unit is not Verify the wiring, refer to the connected to the panel. wiring diagram. The LED is Off The power from the Measure the AUX output of the panel is out. -
Page 14: Rj45 Connector Led Indications
Firelite | HW-AV-LTE-M-FL 3.6 RJ45 CONNECTOR LED INDICATIONS Yellow LED RJ45 Indication Action Connector Verify the wiring, refer to The LAN cable is not the wiring diagram. The LED is Off plugged into the Measure the AUX output communicator of the panel Replace the unit The LED is Constantly... -
Page 15: Manufacturer Warranties And Limitation Of Liability
Firelite | HW-AV-LTE-M-FL MANUFACTURER WARRANTIES AND LIMITATION OF LIABILITY Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan. - Page 16 12 Clintonville Rd 140 Waterside Rd Northford, CT 06472 Leicester LE5 1TN, UK (203) 484-7161 +44 (0) 203 4091779...
