Page 1 Honeywell Connected Life Safety Services CLSS Gateway HON-CGW-MBB Installation and User Manual LS10248-000HW-E ECN: 00055952 REV. K | May 2025...
Page 2 CLSS Gateway | Honeywell Connected Life Safety Services FIRE ALARM & EMERGENCY COMMUNICATION SYSTEM LIMITATIONS connection of alarm transmission wiring, communications, While a life safety system may lower insurance rates, it is not a signaling, and/or power. If detectors are not so located, a...
Page 4 CLSS Gateway | Honeywell Connected Life Safety Services SOFTWARE DOWNLOADS In order to supply the latest features and functionality in fire alarm and life safety technology to our customers, we make frequent upgrades to the embedded software in our products. To ensure that you are installing and programming the latest features, we strongly recommend that you download the most current version of software for each product prior to commissioning any system.
Page 5 CLSS Gateway | Honeywell Connected Life Safety Services TABLE OF CONTENTS Fire Alarm & Emergency Communication System Limitations Installation Precautions Software Downloads Documentation Feedback Table of Contents Section 1: General Information 1.1 About This Manual 1.1.1 Using This Manual 1.1.2 Usages 1.2 Information Sources...
Page 6 CLSS Gateway | Honeywell Connected Life Safety Services 4.3.3 Installing A Dual SIM Cellular Module Section 5: Configurations 5.1 Commissioning the Gateway 5.1.1 The Commissioning Steps 5.1.2 Exporting Panel's Topology Data 5.1.3 To Configure via the Wireless Connection 5.2 Verifying the Gateway Connections 5.3 Panel Brand and Connection Settings...
Page 7 CLSS Gateway | Honeywell Connected Life Safety Services 7.9 Agency Listings and Approvals 7.9.1 Agency Restrictions and Limitations 7.10 Standards 7.10.1 Compliance 7.10.2 Installation 7.11 Compatible Equipment 7.12 Modbus Feature Activation 7.12.1 To Purchase the Modbus Support 7.12.2 To Activate the Modbus Support 7.13 Installation and Configurations...
Page 8 CLSS Gateway | Honeywell Connected Life Safety Services 7.24.2 Software Configuration 7.25 Connecting the Moxa MGate MB3180 Interface 7.26 System Trouble 7.27 Exception Responses 7.28 CLSS Gateway Active Event Code 7.29 Device Types 7.30 System Troubles Register Map Section 8: The BACnet Feature 8.1 Agency Listings...
Page 9 CLSS Gateway | Honeywell Connected Life Safety Services C.2 Supported Panels C.3 ESSER Panels C.3.1 Connection Options C.3.2 Minimum Required Versions C.3.3 To Make a Remote Access Connection on RS-232 C.3.4 To Make a WINMAG Connection on RS-232 C.3.5 IQ8(French version) Panel connection Diagram using RS232 C.3.6 To Make a WINMAG Connection Using an SEI 2 Card...
Page 10 CLSS Gateway | Honeywell Connected Life Safety Services C.7.5 Power Connection C.7.6 Power Connection C.8 Gent Panels C.8.1 Connection Options C.8.2 Compact Series Panels C.8.3 Power Connection C.8.4 To Use a USB Connection C.8.5 Power Connection C.8.6 Vigilon Series Panels C.8.7 Power Connection...
Page 11 CLSS Gateway | Honeywell Connected Life Safety Services C.16.5 Programming for Annunciator (ANN-PRI) C.16.6 To Program for Annunciator C.17 VESDA® Detectors C.17.1 Connection Options C.17.2 Minimum Required Versions C.17.3 To Use an Ethernet Connection C.17.4 Power Connection Appendix D: Compatible Cellular Modules D.1 Operation...
Page 12 • The Connected Life Safety Services mobile App may also be referred as the CLSS App • The CLSS Site Manager may also be referred as the Cloud • The term CLSS Gateway may refer to HON-CGW-MBB and CGW-MB, unless otherwise specified 1.2 INFORMATION SOURCES Honeywell offers suitable information sources based on informational requirements.
Page 13 CLSS Gateway | Honeywell Connected Life Safety Services For This Product Refer to... Purpose... Gent Vigilon Panels: Installation Instructions - Vigilon Compact Panel Based Fire Detection and COMPACT-24-N Installation Alarm System P/N: 4188-1026 Installation Instructions - Vigilon Compact Plus Panel Based Fire Detection...
Page 14 CLSS Gateway | Honeywell Connected Life Safety Services For This Product Refer to... Purpose... Software VeriFire® Tools Product Installation Guide P/N: 51690 Installation On-line Help VeriFire® Tools Help Files CLSS-Enabled LTE Commercial Fire Alarm Communicator: Install and get...
Page 15 CLSS Gateway | Honeywell Connected Life Safety Services Abbreviation Description Universal Asynchronous Receiver/Transmitter A physical connection that converts and provides serial data for the panel and parallel data for the UART gateway. Universal Serial Bus 1.4 APPROVALS S35608 FCC ID: PV3CGWMB Compliance Statements: This device complies with Part 15 of the FCC Rules.
Page 16 CLSS Gateway | Honeywell Connected Life Safety Services FDNY COA# 2020-TMCOAP-000121-AMND COA# 2020-TMCOAP-000122-AMND COA# 2021-TMCOAP-001761-CERT COA# 2021-TMCOAP-006279-AMND 1.5 WARNINGS AND CAUTIONS IN THIS MANUAL WARNING: These instructions contain procedures to follow to avoid injury and damage to equipment. It is assumed that the user of this manual has been suitably trained and is familiar with the relevant regulations.
Page 17 CLSS Gateway | Honeywell Connected Life Safety Services SECTION 2: OVERVIEW CLSS Gateway is an embedded and intelligent gateway for connected buildings. It enables system maintenance providers as well as end users to remotely manage connected fire detection systems. The gateway also supports them to ensure compliance.
Page 18 CLSS Gateway | Honeywell Connected Life Safety Services 2.3.1 CONNECTING INTERFACES Figure 2-2: The LED Indicators on the Gateway uses numbered labels to show the location of the interfaces for connections. This manual uses these numbered labels at various places for your convenience.
Page 19 CLSS Gateway | Honeywell Connected Life Safety Services 2.3.2 LED INDICATORS The LED indicators on the gateway board use different colors to identify the operational status of the gateway. To know the location of the LED indicators on the gateway board, refer to Figure 2-1: Printed Circuit Board: Layout .
Page 20 CLSS Gateway | Honeywell Connected Life Safety Services ON The gateway is downloading the firmware from the CLSSSite Manager. FLASHINGSLOW (flashes once per 1 second) The gateway is connected with CLSS Site Manager. FLASHINGFAST (flashes once per 0.2 second) The gateway is connected with Internet, but not connected with the CLSS Site Manager.
Page 21 CLSS Gateway | Honeywell Connected Life Safety Services 2.4 CLSS GATEWAY PARTS Part Number Description HON-CGW-MBB CLSS Gateway with enclosure CGW-MB CLSS Gateway board CGW-BB CLSS Gateway enclosure CLSS Gateway kit. It includes a 30” NUP cable and a 50160636-001 NOTIFIER lock and key set.
Page 22 • Incorrect operation, spurious alarms, or both • Theft or damage to the contents of the system • Capture and modification or deletion of data causing possible liability to the installation Site and Honeywell 3.2.2 USER ACCESS AND PASSWORDS Observe the following good practices: •...
Page 23 Ensure that your local representative: • Has the up-to-date contact details, and • Periodically visits the Honeywell web site for up-to-date product information • Regularly updates the software/firmware of the devices to the latest available version to get important security updates 3.2.5 VIRUSES AND OTHER MALICIOUS SOFTWARE AGENTS...
Page 24 CLSS Gateway | Honeywell Connected Life Safety Services Reigon URL/End-Points https://honprodeast.rrmsalarm.com https://honprodwest.rrmsalarm.com US Alarm Transmission https://honrtprodeast.firesignals.us https://honrtprodwest.firesignals.us 3.2.6.1 Best Practices 3.2.6.1.1 Network Security Open protocols, unencrypted connections, and unauthenticated sites are risks. Ensure the following: • Required firewalls and VPN connections are in place •...
Page 25 SECTION 4: INSTALLATION You can use a fixed gateway in the fire detection system. CAUTION: This section refers to the fixed gateway P/N: HON-CGW-MBB. For instructions on mounting the portable gateway, P/N: CGW-MB, refer to the NBB-2 installation document LS10250-000NF-E CAUTION: The gateway must be installed indoors in a dry location.
Page 26 CLSS Gateway | Honeywell Connected Life Safety Services Confirm that the placement of the backbox allows the door to swing open freely. Mark and pre-drill the hole for the top mounting bolt (see"Mounting the Backbox" below). Figure 4-2: Mounting the Backbox Remove the backbox.
Page 27 CLSS Gateway | Honeywell Connected Life Safety Services 4.3 GATEWAY BOARD CONNECTION OPTIONS The gateway board can be connected with a cellular module, wireless aerials, the CLSS Site Manager, a configuration computer, a panel, a mobile device, and an external power supply. Figure 4-3: Gateway Connections - Top Side illustrates the connection options at the top side of the gateway board.
Page 28 CLSS Gateway | Honeywell Connected Life Safety Services 4.3.2.2 Before Installing a Cellular Module • If installing on an existing operational gateway, inform the operator and local authority that the gateway will be temporarily out of service. • Disconnect power to the gateway. 4.3.2.3 Precautions for Service Quality • Carefully select the installation location of the CLSS Gateway.
Page 29 CLSS Gateway | Honeywell Connected Life Safety Services On the top edge of the gateway, plug the cellular module onto the 40-pin expansion slot (see Figure 4-6: Installing the Cellular Module ). Do not use the screw on the top edge of the Cellular module. It will adversely affect the radio performance. Refer to the Do Not Use This Screw shown in Figure 4-4: Gateway Connection Options - Bottom Side .
Page 30 Module you can log into the CLSS Site Manager or CLSS Mobile App. After you log into the CLSS, navigate to the specific customer/site to view the CLSS Gateway Diagnostics tab. Honeywell recommends that the signal strength rating should be a 3 (Good) or above for a consistent good connection.
Page 31 CLSS Gateway | Honeywell Connected Life Safety Services 4.3.2.8 Installing the External Aerials for Single Sim Cellular Module (CCM-ATT-HON, CCM-VZ-HON,CCM-EU) In a low LTE signal area, using an external aerial may boost the signals. When installing an aerial, ensure that: • The aerial is within its granted FCC directional gain limitations...
Page 32 CLSS Gateway | Honeywell Connected Life Safety Services 4.3.3 INSTALLING A DUAL SIM CELLULAR MODULE The CLSS Dual SIM 4G LTE Cellular Module for the CLSS Gateway provides global connectivity and ensures stable network performance even in harsh signal conditions. It features a dual SIM design, and a high-performance antenna included with the module for greater range and reliability.
Page 33 CLSS Gateway | Honeywell Connected Life Safety Services 4.3.3.2 CLSS Dual SIM 4G LTE Cellular Module Installation steps NOTE: Please ensure that the CLSS Gateway firmware version is 4.6.0.80 or higher for the Gateway to detect the new CLSS Dual SIM 4G LTE Cellular Module. If the current CLSS Gateway firmware version is older, please upgrade to version 4.6.0.80 or higher via the local web page or over-the-air (OTA) via the Wi-Fi or Ethernet interface, if available.
Page 34 CLSS Gateway | Honeywell Connected Life Safety Services Figure 4-16: Installing the CCM2 cell module Figure 4-17: Installing Primary Antenna with SMA cable 4.3.3.3 Commissioning the CLSS Gateway with Cellular module Check that the Cellular module LED is solid green. This indicates that the module is connected to the cell tower.
Page 35 CLSS Gateway | Honeywell Connected Life Safety Services 4.3.3.4 Troubleshooting 01. Cellular module LED a. Solid Green: Cellular module is connected to cell tower. b. OFF: CLSS Gateway not powered or cellular module is not connected to the Gateway. c. Blinking Red: Cellular module attempting to connect to cell tower.
Page 36 CLSS Gateway | Honeywell Connected Life Safety Services Description Kit Includes mmcx to sma cable130mm CCD095174250D000130 SMA Bulkhead Female to SMA PLUG GOLD Male CCD01120T551D002000 cable tag/Nylon Cable Clips Wall Hanging CCM2-ANTKIT-EXT2 Diversity/Secondary Antenna Kit (5 pcs) Indoor Antenna TG.55.8113...
Page 37 The maximum length of cable and antenna placement acceptable should be determined considering the signal strength rating seen in the Gateway Cellular Module after the install.Honeywell recommends that the signal strength rating should be Good or Excellent for a consistent reliable cellular connection. Maximum loss should be 3 dB.
Page 38 In the mobile device, download the Connected Life Safety Services App from Play Store or App Store. Install the App. From the Honeywell on-boarding email, note down the login credentials. On the mobile device, log into the CLSS App. Installation and User Manual | REV. K...
Page 39 CLSS Gateway | Honeywell Connected Life Safety Services On the App’s dashboard, at the right bottom, tap the More icon (see Figure 5-1: CLSS App Dashboard ). Figure 5-1: CLSS App Dashboard Tap Gateway Configuration. Follow the on-screen instructions for mobile connectivity.
Page 40 If the LED is indicating differently, refer to 2.3.2 LED Indicators section to know the operational status. If necessary, refer to the Section 6: Post-Installation Activities section to fix the problem or contact Honeywell Technical Support. Figure 5-3: Connection Indicators...
Page 41 CLSS Gateway | Honeywell Connected Life Safety Services LED Indicator State Meaning The gateway is in the configuration mode Flashing fast The gateway is getting the inventory data Flashing slow The gateway is communicating with the panel Flashing slow The gateway is communicating with CLSS Site Manager...
Page 42 CLSS Gateway | Honeywell Connected Life Safety Services Run the BACnet Import Generator tool. Follow the below process to register the BACnet Import Generator: Create an Input folder and an Output folder. NOTE: The Input folder will store Vigilon configuration settings. The Output folder will store the GENTGW.ini, GentComm.ini, and BacnetImport.dat files.
Page 43 CLSS Gateway | Honeywell Connected Life Safety Services 5.3.3 TO CONFIGURE THE PANEL’S CONNECTION SETTINGS CLSS gateway details are provided through the Gateway Configuration Tool, a web page-based configuration tool running on the gateway. On the CLSS Gateway board, find the S6 button. Connect the Ethernet cable to Eth0 and the Laptop to enable web configuration.
Page 44 The CLSS Gateway receives events from a listed Fire Alarm Control Unit and transmits events using cellular, wireless, or Ethernet to Honeywell's Network Operations Center (NOC). All signals from the CLSS Gateway are delivered to Honeywell's NOC, which routes the events to the appropriate central monitoring station over an IP network.
Page 45 NOTE: Using the credentials given, you can log onto the CLSS Site Manager available on https://fire.honeywell.com enable this feature. Honeywell recommends Chrome browser for using the CLSS Site Manager. Log onto the CLSS Site Manager. Click on the profile icon at the top right and click External Accounts.
Page 46 CLSS Gateway | Honeywell Connected Life Safety Services Click the FEATURE ACTIVATION icon at the left navigation bar. Select Installed Gateways and then go to the INSTALLED GATEWAYS section. NOTE: To view only those gateways not yet activated, select Show only Gateways without activations at the right side.
Page 47 CLSS Gateway | Honeywell Connected Life Safety Services 5.4.4 DUAL PATH COMMUNICATION FOR ALARM TRANSMISSION While configuring the central station communication, you can choose a single path or two paths for alarm transmissions. Reporting options are: LTE cellular only, IP only, IP Primary with LTE cellular backup, or LTE Cellular Primary with IP backup.
Page 48 CLSS Gateway | Honeywell Connected Life Safety Services 5.4.4.5 To Specify the Test Time Interval Go to your Customer > Site > Building in CLSS Site Manager. Click at the left side for feature activation. Find and click the required gateway from the FIXED GATEWAYS page.
Page 49 CLSS Gateway | Honeywell Connected Life Safety Services SECTION 6: POST-INSTALLATION ACTIVITIES The system maintenance provider is responsible for the maintenance and upkeep of the CLSS Gateway. The maintenance involves avoiding potential issues, making regular backups, restoring data when required, collecting data for troubleshooting, and other activities.
Page 50 CLSS Gateway | Honeywell Connected Life Safety Services Enter the OC of the gateway in the Search OC field to find the gateway to update. Scroll across to find the gateways to update. Click Update. 6.1.2 TO UPGRADE AFTER COMMISSIONING THE GATEWAY Log onto the CLSS Site Manager.
Page 51 Issues that may occur during the gateway’s operation can be resolved on your own using the tables below or by contacting Honeywell Technical Support. The issues can be either LED-indicated issues or other issues. Installation and User Manual | REV. K...
Page 52 Reconnect all the cables. All other LEDs are OFF Ensure that the gateway board is getting its 24V DC power. If the above steps do not fix the issue, contact Honeywell Technical Support. DL2: Trouble LED-Indicated Issues ON and SOLID Amber It is a critical issue.
Page 53 CLSS Gateway | Honeywell Connected Life Safety Services 6.2.2 TO TROUBLESHOOT OTHER ISSUES If there are issues, which are not shown by the LEDs, refer to the below table to determine their possible fixes. Table 6.2 Events-Related Issues Issue Description Possible Causes Possible Fixes The gateway is dissociated.
Page 54 CLSS Gateway | Honeywell Connected Life Safety Services Issue Description Possible Causes Possible Fixes There is a need to reset the An unusual situation requires reverting Contact the Honeywell Tech Support for a guided gateway board to its factory to factory default settings.
Page 55 CLSS Gateway | Honeywell Connected Life Safety Services SECTION 7: MODBUS COMMUNICATIONS The CLSS Gateway can use a third-party client to monitor the nodes inside a Modbus LAN network, and send alarm and event data of these nodes for the CLSS users. NOTE: The Modbus interface provides supplementary data to the third party client.
Page 56 CLSS Gateway | Honeywell Connected Life Safety Services 7.5.2 IP RESTRICTIONS FOR THE GATEWAY • Assign a static IP address. NOTE: Dynamic Host Configuration Protocol (DHCP) is supported, but not recommended. Before using DHCP with LAN for Intranet connection, consult the network administrator of the Site.
Page 57 CLSS Gateway | Honeywell Connected Life Safety Services 7.7 SYSTEM ARCHITECTURE An Internet or Intranet IP network connection is needed for the architectures described here. Figure 7-1: Single Panel Architecture Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 58 CLSS Gateway | Honeywell Connected Life Safety Services 7.7.1 NETWORK OF PANELS Below illustration shows a sample topology. Refer to the Appendix C: Connecting to the Panels section for panel-specific connection details. Figure 7-2: NFN Network Architecture Installation and User Manual | REV. K...
Page 59 CLSS Gateway | Honeywell Connected Life Safety Services 7.7.2 REDUNDANCY A redundant gateway is a second gateway, which communicates with a Modbus client. CAUTION: The First and Second gateways must have different node numbers and different ip addresses. An Example Figure 7-3: Redundant CLSS Gateways Installation and User Manual | REV.
Page 60 CLSS Gateway | Honeywell Connected Life Safety Services 7.8 NFN LEGACY MODBUS GATEWAY A panel’s network might already be using a Modbus gateway in its network. You can add the CLSS Gateway to the network or replace the legacy Modbus gateway with the CLSS Gateway.
Page 61 CLSS Gateway | Honeywell Connected Life Safety Services 7.9 AGENCY LISTINGS AND APPROVALS • UL/ULC Listed: S35608 • CSFM: 7300-1637:0504 • FDNY: COA#000121, COA#000122 7.9.1 AGENCY RESTRICTIONS AND LIMITATIONS CLSS Gateway is UL 864 and ULC-S527 listed for supplementary use only. 7.10 STANDARDS 7.10.1 COMPLIANCE This product has been investigated to, and found to be in compliance with, the following standards: Underwriters Laboratories •...
Page 62 CLSS Gateway | Honeywell Connected Life Safety Services Type Equipment • NFN-GW-EM-3 • PC NFN Gateways: • NFN-GW-PC-F Gateways • NFN-GW-PC-W • NFN-GW-PC-HNMF • NFN-GW-PC-HNSF • NFN-GW-PC-HNW Unmonitored but network compatible. • Legacy Gateway • NFN-GW-PC-HNSF • DVC • NFN-GW-PC-HNW •...
Page 63 CLSS Gateway | Honeywell Connected Life Safety Services Click PURCHASE at the top right side. Figure 7-5: Purchasing the Modbus Support Scroll down to find Modbus Support in the Features tab. Enter the number of support required in the Modbus Support field.
Page 64 CLSS Gateway | Honeywell Connected Life Safety Services Tap Fixed Gateways. Select the site of the gateway. Find and tap the OC of the gateway. Tap ADD ACTIVATION. Tap Modbus Support under the One Time Activations. Tap ACTIVATE. Wait for the activation successful message.
Page 65 CLSS Gateway | Honeywell Connected Life Safety Services 7.15 TO CONNECT WITH THE MODBUS CLIENT At the CLSS Gateway side, connect an Ethernet cable to the Ethernet Port 1. At the Modbus client side, connect the other end of the Ethernet cable to the system running the Modbus client.
Page 66 CLSS Gateway | Honeywell Connected Life Safety Services In the Chrome browser, enter the following URL: https://192.168.10.190:9443/config/index.html Do the following if any security warning is shown. Otherwise, go to step 7. Click the Advanced link below the error message. Agree to proceed.
Page 67 CLSS Gateway | Honeywell Connected Life Safety Services Field Description Displays the unit ID that the CLSS Gateway uses in the Modbus network. This is a configurable property of the nodes. By default, the Modbus Unit ID for a monitored node is set to be the same as the NFN Node ID.
Page 68 CLSS Gateway | Honeywell Connected Life Safety Services Field Description 300 detectors, and • 1 - 15 modules with 12 channels Special • 16 - 40 modules with 3 channels • 41 - 300 modules with 2 channels MODBUS TOOLS Go to Modbus Tools in Modbus Settings.
Page 69 CLSS Gateway | Honeywell Connected Life Safety Services • The Unit ID should match the node number of the node, which is being addressed. For example, a Unit ID of 127 addresses node 127. • The CLSS Gateway communicates on standard Modbus IP port 502.
Page 70 CLSS Gateway | Honeywell Connected Life Safety Services 7.19.2.1 For NOTIFIER UL Table 7.6 Device Commands Command Value Holding Register Acknowledge 0x0100 Use Device/Module Holding Disable 0x0200 Register Enable 0x0400 Activate* 0x0800 Address Deactivate* 0x1000 * Activate and Deactivate work only for output-controlled modules like control and relay.
Page 71 CLSS Gateway | Honeywell Connected Life Safety Services 7.19.2.2 Generic Commands List Table 7.10 Device Commands Gamewell- AM-MA Commands Value Notifier EN Holding Register Series AM-MA Commands Value Gamewell-FCI Notifier EN Holding Register Series Enable 0x0400 Disable 0x0500 Use Device/Module Holding Acknowledge Trouble...
Page 72 CLSS Gateway | Honeywell Connected Life Safety Services NOTE: The first response to an analog point poll is zero. This response is an initialization confirmation from the gateway. • Upon receiving the initialization confirmation, the client can begin polling the analog points. The client should wait 5 seconds after the initialization request to insure that the CLSS Gateway has had enough time to get the analog values and load the registers.
Page 73 CLSS Gateway | Honeywell Connected Life Safety Services 7.21 REGISTER MAPPING 7.21.1 REGISTER MAPPING OVERVIEW The CLSS Gateway uses 16-bit registers. One Modbus Input register and one Modbus Holding Register are allocated for each device address. These registers represent a contiguous address mapping of all devices and points.
Page 74 CLSS Gateway | Honeywell Connected Life Safety Services Table 7.13 Point Status Holding Register: Bit Definitions Upper Byte Lower Byte Bit No. 15 2 1 0 Ack Fire Prealarm Trouble InActive Active Enable Disable Name Block Alarm When individual upper byte bits are set to 1, the following definitions apply: Ack Block (Bit 15): All events on this point, other than fire alarm, are acknowledged.
Page 75 CLSS Gateway | Honeywell Connected Life Safety Services NOTE: If the point is not present in the panel programming, all bits in the byte will contain a value of 1 or FFFFH. There are 6000 point device type holding registers. Each register address consists of two bytes representing a detector or module.
Page 76 CLSS Gateway | Honeywell Connected Life Safety Services If the zone or panel circuit is not present in the panel programming, all bits in the lower byte will contain a ‘1’ or the value ‘FFH’, but the upper byte will contain a ‘0’.
Page 77 CLSS Gateway | Honeywell Connected Life Safety Services Panel Max. Panel Circuits Points NFS2-640 Not Supported NFS-3030 NFS2-3030 Not Supported 7.21.1.4 Channel Status Holding Registers Each channel status holding register is arranged into an Upper Byte and Lower Byte as described in the Table 7.21 Channel Status Holding Register: Bit Definitions : •...
Page 78 CLSS Gateway | Honeywell Connected Life Safety Services Start Address End Address Address 439001 442600 L6M1 - L6M300 442601 446200 L7M1 - L7M300 446201 449800 L8M1 - L8M300 449801 453400 L9M1 - L9M300 453401 457000 L10M1 - L10M300 Table 7.23 Input Register Addresses for Normal Mapping...
Page 79 CLSS Gateway | Honeywell Connected Life Safety Services • Channel Device Type Input Registers NOTE: If the channel is not present in the panel programming, all bits in the byte will contain a value of 1 or FFFFH. There are 57000 channel device type input registers for normal mapping. 7750 device type input registers for special mapping.
Page 80 CLSS Gateway | Honeywell Connected Life Safety Services Specifically, the lower byte contains the actual active event for this bell circuit. An active state is defined in this gateway as any Fire, Security, Critical Process, Medical, Mass Notification, or Supervisory alarm state.
Page 81 CLSS Gateway | Honeywell Connected Life Safety Services • Silence: The fire alarm control panel is silenced when this bit is set to 1. • Reset: Not used. Table 7.33 Panel Status Holding Register Bit Definitions Upper Byte Lower Byte Bit No.
Page 82 CLSS Gateway | Honeywell Connected Life Safety Services Counters Loop Detectors Loop Modules Loop Detectors Loop Modules Loop Disables Lx 414104 414109 414115 414120 Loop tests Lx 414105 414110 414116 414121 Active NONAS Lx 414111 414122 Loop 3...
Page 83 CLSS Gateway | Honeywell Connected Life Safety Services Start Address End Address Description Node Status: 1 = On Line 0 = Off Line 320001 320015 The CLSS Gateway tracks status of network nodes under Modbus feature monitoring. 360016 360016 Gateway major version number...
Page 84 CLSS Gateway | Honeywell Connected Life Safety Services 7.23 TROUBLESHOOTING 7.23.1 WHAT ARE SOME BASIC GUIDELINES WHEN INSTALLING A CLSS GATEWAY? • Polling should be done slowly to start. • Use Modscan® to debug the system rather than a more complicated client. Verify that registers are being updated as events happen on the NFN network/panel.
Page 85 CLSS Gateway | Honeywell Connected Life Safety Services 7.23.8 WHY DO I GET ALL ZEROS WHEN I READ AN ANALOG VALUE? There are several reasons a zero reading from an FMM-4-20 Analog Input Module is received: • The first read for an analog value from the gateway initializes the polling routine in the gateway to retrieve analog values from the NFN network.
Page 86 CLSS Gateway | Honeywell Connected Life Safety Services Run the MGate Manager installation software (MGM_Setup_Verx.x_Build_xxxxxxxx.exe) found on the Software CD shipped with the MGate MB3180. Wait for the installation to complete. Run MGate Manager. Power up the MB3180. Ensure that the...
Page 87 CLSS Gateway | Honeywell Connected Life Safety Services 7.25 CONNECTING THE MOXA MGATE MB3180 INTERFACE NOTE: The configuration used must have the approval of the AHJ (Authority Having Jurisdiction). Connect the RTU master to the Serial port (RS-232, RS-485, or RS-422) of MB3180. Connect the MB3180 to the CLSS Gateway.
Page 88 CLSS Gateway | Honeywell Connected Life Safety Services 7.26 SYSTEM TROUBLE For information about system trouble information stored in holding registers, refer to Panel and System Troubles Holding Registers 7.27 EXCEPTION RESPONSES If a Modbus master device sends an invalid command or attempts to read an invalid holding register, an exception response is generated.
Page 89 CLSS Gateway | Honeywell Connected Life Safety Services Modbus Event Register Value Security Alarm (Property) Critical Process (Property) Mass Notification Supervisory, High Priority Supervisory Signal (Guard’s Tour) Supervisory Signal (Equipment) Mass Notification Supervisory, Low Priority Disabled Alarm (AFP2800 Panel Only)
Page 90 CLSS Gateway | Honeywell Connected Life Safety Services Device Type Value Device Type Value Smoke Ion Tracking 0201H Wireless Smoke Multi 0610H Duct Smoke Ion Latching 0202H Wireless Smoke Acclimate 0611H Duct Smoke Ion Tracking 0203H CO Alarm 0700H Smoke Photo Latching...
Page 91 CLSS Gateway | Honeywell Connected Life Safety Services Device Type Value Device Type Value Telephone Page 0040H Instant Release 1030H Weather 0055H Alarms Pending 1031H Control Notification Appli- Wireless Weather 0056H 1032H ance Circuit Positive Alarm Sequence Inhibit Input 0060H...
Page 92 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name ANNUN. 9 NO ANSWER ANNUN.13 NO ANSWER ANNUN.10 TROUBLE ANNUN.14 TROUBLE ANNUN.10 NO ANSWER ANNUN.14 NO ANSWER ANNUN.11 TROUBLE ANNUN.15 TROUBLE 460003 ANNUN.11 NO ANSWER ANNUN.15 NO ANSWER...
Page 93 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name ANNUN.33 TROUBLE ANNUN.37 TROUBLE ANNUN.33 NO ANSWER ANNUN.37 NO ANSWER ANNUN.34 TROUBLE ANNUN.38 TROUBLE ANNUN.34 NO ANSWER ANNUN.38 NO ANSWER 460008 ANNUN.35 TROUBLE ANNUN.39 TROUBLE ANNUN.35 NO ANSWER...
Page 94 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name STYLE 6 POS. LOOP 3 PRINTER SUPERVISORY STYLE 6 POS. LOOP 4 BUZZER SUPERVISORY STYLE 6 POS. LOOP 5 CRT SUPERVISORY STYLE 6 POS. LOOP 6...
Page 95 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name ANNUN. 73 TROUBLE ANNUN. 77 TROUBLE ANNUN. 73 NO ANSWER ANNUN. 77 NO ANSWER ANNUN. 74 TROUBLE ANNUN. 78 TROUBLE ANNUN. 74 NO ANSWER ANNUN. 78 NO ANSWER 460018 ANNUN.
Page 96 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name ANNUN. 113 TROUBLE ANNUN. 117 TROUBLE ANNUN. 113 NO ANSWER ANNUN. 117 NO ANSWER ANNUN. 114 TROUBLE ANNUN. 118 TROUBLE ANNUN. 114 NO ANSWER ANNUN. 118 NO ANSWER 460023 ANNUN.
Page 97 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name REMOTE DISPLAY 25 TROUBLE REMOTE DISPLAY 29 TROUBLE REMOTE DISPLAY 25 NO ANSWER REMOTE DISPLAY 29 NO ANSWER REMOTE DISPLAY 26 TROUBLE REMOTE DISPLAY 30 TROUBLE...
Page 98 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name LOOP CONTINUITY TEST FAIL LOOP 1 LOOP CONTINUITY TEST FAIL LOOP 9 LOOP CONTINUITY TEST FAIL LOOP 2 LOOP CONTINUITY TEST FAIL LOOP 10 LOOP CONTINUITY TEST FAIL LOOP 3...
Page 99 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name DIGIN Trouble ANALOG OUTPUT A TROUBLE FFT TROUBLE ANALOG OUTPUT B TROUBLE REMOTE MIC Trouble ANALOG OUTPUT C TROUBLE DAP Port A Failure ANALOG OUTPUT D TROUBLE...
Page 100 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name DSBUS 2 AC FAIL DSBUS 2 LOW BATT DSBUS 3 AC FAIL DSBUS 3 LOW BATT DSBUS 4 AC FAIL DSBUS 4 LOW BATT DSBUS 1 HIGH BATT...
Page 101 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name LOOP CARD 9 COMM LOSS PMB 4 COMM LOSS LOOP CARD 10 COMM LOSS PMB 5 COMM LOSS CHANGE MASTER USER PASSWORD Recovery Partition Application Active...
Page 102 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name Access Granted 2 LCD80 Supervisory 3 Access Granted 3 LCD80 Supervisory 4 Access Granted 4 LCD80 Supervisory 5 Access Granted 5 LCD80 Supervisory 6 460051...
Page 103 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name Speaker Circuit Open 5 Auxiliary Trouble 60 Speaker Circuit Open 6 Tornado Alert Speaker Circuit Open 7 SLC! Disconnect Speaker Circuit Open 8 SLC2 Disconnect...
Page 104 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name INCOMPATIBLE LOOP1 DEVICE AND LIB INCOMPATIBLE LOOP9 DEVICE AND LIB INCOMPATIBLE LOOP10 DEVICE AND INCOMPATIBLE LOOP2 DEVICE AND LIB ID2NET PARTIAL OPEN/SHORT CIRCUIT INCOMPATIBLE LOOP3 DEVICE AND LIB...
Page 105 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name POWER SUPPLY DATABASE INCOMPATIBLE 3 LOOP NO DATABASE 6 POWER SUPPLY DATABASE INCOMPATIBLE 4 LOOP NO DATABASE 7 POWER SUPPLY DATABASE INCOMPATIBLE 5...
Page 106 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 2 RELAY VOLTAGE FAULT 13 AIO ADDR 3 RELAY VOLTAGE FAULT 5 AIO ADDR 2 RELAY VOLTAGE FAULT 14 AIO ADDR 3 RELAY VOLTAGE FAULT 6 ...
Page 107 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 6 RELAY VOLTAGE FAULT 13 AIO ADDR 7 RELAY VOLTAGE FAULT 5 AIO ADDR 6 RELAY VOLTAGE FAULT 14 AIO ADDR 7 RELAY VOLTAGE FAULT 6 ...
Page 108 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 10 RELAY VOLTAGE FAULT 13 AIO ADDR 1 ISOLATED VOLTAGE FAULT 5 AIO ADDR 10 RELAY VOLTAGE FAULT 14 AIO ADDR 1 ISOLATED VOLTAGE FAULT 6 ...
Page 109 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 4 ISOLATED VOLTAGE FAULT 13 AIO ADDR 5 ISOLATED VOLTAGE FAULT 5 AIO ADDR 4 ISOLATED VOLTAGE FAULT 14 AIO ADDR 5 ISOLATED VOLTAGE FAULT 6 ...
Page 110 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 8 ISOLATED VOLTAGE FAULT 13 AIO ADDR 9 ISOLATED VOLTAGE FAULT 5 AIO ADDR 8 ISOLATED VOLTAGE FAULT 14 AIO ADDR 9 ISOLATED VOLTAGE FAULT 6 ...
Page 111 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 2 HARDWARE FAILURE 13 AIO ADDR 3 HARDWARE FAILURE 5 AIO ADDR 2 HARDWARE FAILURE 14 AIO ADDR 3 HARDWARE FAILURE 6 ...
Page 112 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 6 HARDWARE FAILURE 13 AIO ADDR 7 HARDWARE FAILURE 5 AIO ADDR 6 HARDWARE FAILURE 14 AIO ADDR 7 HARDWARE FAILURE 6...
Page 113 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 9 HARDWARE FAILURE 13 AIO ADDR 10 HARDWARE FAILURE 5 AIO ADDR 9 HARDWARE FAILURE 14 AIO ADDR 10 HARDWARE FAILURE 6 ...
Page 114 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 3 EXTRA DEVICE 13 AIO ADDR 4 EXTRA DEVICE 5 AIO ADDR 3 EXTRA DEVICE 14 AIO ADDR 4 EXTRA DEVICE 6 ...
Page 115 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 7 EXTRA DEVICE 13 AIO ADDR 8 EXTRA DEVICE 5 AIO ADDR 7 EXTRA DEVICE 14 AIO ADDR 8 EXTRA DEVICE 6 ...
Page 116 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 1 MUNICIPAL FAULT 13 AIO ADDR 2 MUNICIPAL FAULT 5 AIO ADDR 1 MUNICIPAL FAULT 14 AIO ADDR 2 MUNICIPAL FAULT 6 ...
Page 117 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 5 MUNICIPAL FAULT 13 AIO ADDR 6 MUNICIPAL FAULT 5 AIO ADDR 5 MUNICIPAL FAULT 14 AIO ADDR 6 MUNICIPAL FAULT 6 ...
Page 118 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 9 MUNICIPAL FAULT 13 AIO ADDR 10 MUNICIPAL FAULT 5 AIO ADDR 9 MUNICIPAL FAULT 14 AIO ADDR 10 MUNICIPAL FAULT 6 ...
Page 119 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 3 BUZZER SUPERVISORY 13 AIO ADDR 4 BUZZER SUPERVISORY 5 AIO ADDR 3 BUZZER SUPERVISORY 14 AIO ADDR 4 BUZZER SUPERVISORY 6 ...
Page 120 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 7 BUZZER SUPERVISORY 13 AIO ADDR 8 BUZZER SUPERVISORY 5 AIO ADDR 7 BUZZER SUPERVISORY 14 AIO ADDR 8 BUZZER SUPERVISORY 6 ...
Page 121 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name 460128 AIO ADDR 2 HARDWARE MISMATCH 0 AIO ADDR 2 HARDWARE MISMATCH 8 AIO ADDR 2 HARDWARE MISMATCH 1 AIO ADDR 2 HARDWARE MISMATCH 9 ...
Page 122 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 5 HARDWARE MISMATCH 13 AIO ADDR 6 HARDWARE MISMATCH 5 AIO ADDR 5 HARDWARE MISMATCH 14 AIO ADDR 6 HARDWARE MISMATCH 6 ...
Page 123 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 10 HARDWARE MISMATCH 0 AIO ADDR 10 HARDWARE MISMATCH 8 460136 AIO ADDR 10 HARDWARE MISMATCH 1 AIO ADDR 10 HARDWARE MISMATCH 9 ...
Page 124 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 3 DUPLICATE ADDRESS 13 AIO ADDR 4 DUPLICATE ADDRESS 5 AIO ADDR 3 DUPLICATE ADDRESS 14 AIO ADDR 4 DUPLICATE ADDRESS 6 ...
Page 125 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 8 DUPLICATE ADDRESS 0 AIO ADDR 8 DUPLICATE ADDRESS 8 460144 AIO ADDR 8 DUPLICATE ADDRESS 1 AIO ADDR 8 DUPLICATE ADDRESS 9 ...
Page 126 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name POWER SUPPLY DATABASE LOGIC ZONE LICENSE EXCEEDED INCOMPATIBLE (LSB is PMB address 1- NETWORK DISPLAY LICENSE NOT PRESENT Reserved CLIP LICENSE NOT PRESENT Reserved CUSTOM ACTION LICENSE EXCEEDED...
Page 127 CLSS Gateway | Honeywell Connected Life Safety Services Register System Trouble Name System Trouble Name AIO ADDR 4 HARDWARE MISMATCH (LSB is 0 for AIO ADDR 2 HARDWARE FAILURE (LSB is router, 1-15 for peripheral) 0 for router, 1-15 for peripheral)
Page 128 CLSS Gateway | Honeywell Connected Life Safety Services SECTION 8: THE BACNET FEATURE The BACnet feature of the CLSS Gateway provides communications between a panel(s) network and a BACnet client, which is using the BACnet communication protocol. The CLSS Gateway acts like any other node on a panel network. It can communicate with a single panel or network of panels directly or through a network control module.
Page 129 CLSS Gateway | Honeywell Connected Life Safety Services CAUTION: Improper installation, maintenance, and lack of routine testing could result in system malfunction. 8.3 COMPATIBLE EQUIPMENT The CLSS Gateway is compatible with the following equipment: Table 8.1 CLSS-Compatible Equipment List Type Equipment Honeywell Panels NOTIFIER Panels •...
Page 130 CLSS Gateway | Honeywell Connected Life Safety Services 8.4 CLSS GATEWAY PARTS Part Number Description HON-CGW-MBB CLSS Gateway with enclosure CGW-MB CLSS Gateway board CGW-BB CLSS Gateway enclosure CLSS Gateway kit. It includes a 30” NUP cable and a 50160636-001 NOTIFIER lock and key set.
Page 131 CLSS Gateway | Honeywell Connected Life Safety Services 8.7.2 IP REQUIREMENTS 8.7.2.1 IP Port Settings The following IP ports must be available to the CLSS Gateway: Ports Range Type Direction Purpose DNS Resolution: UDP and The optional web portal feature in the CLSS Gateway must Output resolve “www.evanceservices.com”...
Page 132 CLSS Gateway | Honeywell Connected Life Safety Services Figure 8-1: Single Panel Connecting to BACnet via CLSS Gateway Refer to 8.3 Compatible Equipment for supported panels and annunciators. Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 133 CLSS Gateway | Honeywell Connected Life Safety Services 8.7.4 MULTI-PANEL NETWORK ARCHITECTURE The CLSS Gateway can connect to a NUP, RS232, USB, or TTL port available on a panel and interact with that panel's network. Figure 8-2: Gateway Connected with Multiple Panels 8.8 BACNET FEATURE ACTIVATION...
Page 134 CLSS Gateway | Honeywell Connected Life Safety Services 8.8.1 TO PURCHASE THE BACNET SUPPORT Log onto CLSS Site Manager. Click on your account name and select Manage Access. Figure 8-3: Selecting Manage Access Click Features on the Manage Access page. Click Gateway under the Features section.
Page 135 CLSS Gateway | Honeywell Connected Life Safety Services 8.8.2 TO ACTIVATE THE BACNET SUPPORT NOTE: - The gateway must be already installed. If not, install the fixed gateway. - All the network settings should be configured while installing. Tap Perform Feature Activation on the CLSS App’s welcome message.
Page 136 CLSS Gateway | Honeywell Connected Life Safety Services 8.10 TO CONNECT WITH THE BACNET CLIENT At the CLSS Gateway side, connect an Ethernet cable to the Ethernet Port 1. Connect the other end of the Ethernet cable to the IP network. Connect the system running the BACnet client to the same IP network.
Page 137 CLSS Gateway | Honeywell Connected Life Safety Services NOTE: The web configuration is available only on Eth0. Open the Configuration Computer connected to the Eth0 port of the gateway. NOTE: The static IP of the Eth0 port is 192.168.10.190. In the Chrome browser, enter the following URL: https://192.168.10.190:9443/config/index.html Do the following if any security warning is shown.
Page 138 CLSS Gateway | Honeywell Connected Life Safety Services Figure 8-6: Gateway Settings for BACnet Assign the Eth1 port with a static IP address for the BACnet connection. Connect the Ethernet cable between the Eth1 port of CLSS gateway and its LAN device.
Page 139 CLSS Gateway | Honeywell Connected Life Safety Services Find and click BACnet Settings in the Gateway Settings section as shown in"BACnet Gateway Settings Screen" below. Figure 8-7: BACnet Gateway Settings Screen Specify the required values as in the following table: Table 8.3...
Page 140 CLSS Gateway | Honeywell Connected Life Safety Services Fields Action Select Yes to view both online as well as offline nodes. Show all nodes(Yes/No) Select No to view only the online and monitored nodes. Select Yes from the Monitoring column in the table. The client will show the Monitoring(Yes/No) selected nodes.
Page 141 CLSS Gateway | Honeywell Connected Life Safety Services Ensure that the replacing CLSS Gateway has correct object addresses and the old object mappings of Legacy Gateway are removed. Refer to the 8.13 BACnet PIC Statement section for the CLSS Gateway object addressing details.
Page 142 CLSS Gateway | Honeywell Connected Life Safety Services 8.13 BACNET PIC STATEMENT 8.13.1 PROTOCOL IMPLEMENTATION CONFORMANCE STATEMENT (NORMATIVE) 8.13.1.1 BACnet Protocol Revision: 14 Product Description This product presents Fire Panel and Annunciator nodes (operating as part of a Fire Panel network or stand-alone) and their associated objects as BACnet objects. Event notification for Alarms, Troubles, and other states are sent to registered BACnet client workstations.
Page 143 CLSS Gateway | Honeywell Connected Life Safety Services BACnet Enumeration BACnet LifeSafetyState Fire Panel State IssQuiet Normal IssPreAlarm PreAlarm Fire Alarm, Security Alarm (Life/Property), IssAlarm Critical Process Alarm, (Life/Property), Medical Emergency, IB Smash Glass, Panic Alarm Present Value Security Trouble, Fire Trouble, Non-Fire Trouble,...
Page 144 CLSS Gateway | Honeywell Connected Life Safety Services BACnet Event BACnet Fire Panel State Transition Bit Mode toOffNormal Event toFault Enable toNormal Proprietary REAL % Alarm Property REAL Drift Compensation Percent (ONYX Series Panels Only)
Page 145 CLSS Gateway | Honeywell Connected Life Safety Services BACnet Boolean Status Fire Panel State Flag 0,0,0,0 Normal Fire Alarm, Security Alarm (Life/Property), Critical Process Alarm (Life/Property), Medical 1,0,0,0 InAlarm Emergency, PreAlarm, IB Smash Glass, Panic Alarm 0,1,0,0 Fault...
Page 146 CLSS Gateway | Honeywell Connected Life Safety Services Supported - Binary Value Object BACnet BACnet Event State Fire Panel State Enumeration bpv_InActive Trouble, Device Disabled, Normal Present Value Bpv_Active EsNormal Normal Event State EsFault Trouble, Device Disabled EsOffNormal...
Page 147 CLSS Gateway | Honeywell Connected Life Safety Services MS/TP SLAVE (Clause 9), baud rate(s) Point-To-Point, EIA 232 (Clause 10), baud rate(s) Point-To-Point, modem, (Clause 10), baud rate(s) LonTalk, (Clause 11), medium Other B.10.1 Device Address Binding Is static device binding supported? (This is currently necessary for two-way communication with MS/TP slaves and certain other devices.)
Page 148 CLSS Gateway | Honeywell Connected Life Safety Services 8.13.1.2 Equations for Object IDs (Instance Numbers) Standard Addressing – Device Object Instance Number (Default): NOTE: NOTIFIER panels use this addressing method. In the CLSS BACNET-GW, each node has 15,000 object IDs available to it. For each node, multiply its node number by 15,000 and add the offset calculated below based on what type of point it is.
Page 149 CLSS Gateway | Honeywell Connected Life Safety Services Panel Circuits (BINARY_OUTPUT) (Panel# x 10) + (circuit# - 1) + 650 Bell Circuits or NAC Circuits (BINARY_OUTPUT) (BELL_CIRCUIT# + 790) Zones (MULTI_STATE_INPUT or LIFE_SAFETY_ZONE) ZONE (1-2000) => (ZONE# + 10000) Logic Zones (MULTI_STATE_INPUT or LIFE_SAFETY_ZONE) LZONE (1-2000) =>...
Page 150 CLSS Gateway | Honeywell Connected Life Safety Services System Trouble Object Count Address Point Type ANNUN 1-32 37-68 MSI/LSP DBUS 1-4 69-72 MSI/LSP PRIMARY AMP 1-4 73-76 MSI/LSP BACKUP AMP 1-4 77-80 MSI/LSP BACKUP AMP MSI/LSP MSI/LSP POTS MSI/LSP POTS1...
Page 151 CLSS Gateway | Honeywell Connected Life Safety Services APPENDIX A: GATEWAY OPERATING CONDITIONS Table A.1 Operational Requirements Power Requirements Working voltage range 18V - 30V DC For HON-CGW-DACT: 180mA (maximum) Current For HON-CGW-MBB: 140mA (maximum) NOTE: The power requirement varies with the number of interfaces used.
Page 152 CLSS Gateway | Honeywell Connected Life Safety Services APPENDIX B: MODULATIONS AND POWER USED Radio devices operating on the below frequencies should not be installed next to each other. Target Power that Meets Spectrum Mask and EVM Compliance Table B.1 Table B.1 Wireless Power Specifications...
Page 153 CLSS Gateway | Honeywell Connected Life Safety Services APPENDIX C: CONNECTING TO THE PANELS C.1 GATEWAY BOARD CONNECTIONS The gateway board can connect with a cellular module, wireless aerials, the CLSS Site Manager, a configuration computer, a panel, a mobile device, and an external power supply.
Page 154 CLSS Gateway | Honeywell Connected Life Safety Services C.1.1 CONNECTING TO A FIRE ALARM PANEL The panel sends data from all its devices to the connected CLSS Gateway. The data transmission is based on the connection type and the panel compatibility. While the gateway is working do not remove connections to the gateway, CLSS Site Manager, and the panel.
Page 155 CLSS Gateway | Honeywell Connected Life Safety Services C.3 ESSER PANELS A remote access connection on RS-232 provides inventory synchronization. A WINMAG connection on RS-232 or on RS-485 provides active events. You can have either the remote access connection or the WINMAG connection or both.
Page 156 CLSS Gateway | Honeywell Connected Life Safety Services For FlexES Panels Connect as below: Figure C-3: RS-232 Connection on a FlexES Panel Tools 8000 Settings for FlexES Panels Select the Serial Interfaces tab in Tools 8000. Go to the Serial Interface 3 section.
Page 157 CLSS Gateway | Honeywell Connected Life Safety Services For IQ8 Panels Using an RS-232 cable, you can connect to the RS-232 port on the panel's serial interface. Figure C-4: RS-232 Connection on an IQ8 Panel Tools 8000 Settings for IQ8 Panels Double click on Serial Interface in Tools 8000.
Page 158 CLSS Gateway | Honeywell Connected Life Safety Services C.3.4 TO MAKE A WINMAG CONNECTION ON RS-232 Using an RS-232 cable the CLSS Gateway and the panel are connected. The RS-232 port in the gateway board is labeled as 6 in the "Gateway Connection Options - Bottom Side" on page 142.
Page 159 CLSS Gateway | Honeywell Connected Life Safety Services Tools 8000 Settings for ESCOM Panels Select the Serial Interfaces tab on Tools 8000. Click in use. Go to the Serial Interface 1 section in the Serial Interface dialog. Select RS 232 from the Type of Interface list.
Page 160 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-6: Wiring Diagram: RS232 Connection for an IQ8 Panel C.3.5.1 Power Connection For FlexES Panels Using a power cable, the gateway can connect to the 24V DC power supply module of the FlexES panel.
Page 161 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-7: FlexES Panel Power Connectors Tools 8000 Settings for FlexES Panels Select the Serial Interfaces tab in Tools 8000. Go to the Serial Interface 1 section. Select WINMANG from the Device in use list.
Page 162 CLSS Gateway | Honeywell Connected Life Safety Services For IQ8 Panels Using an SEI2 CardConnect to the RS-485 (784871) module in the panel as below: In the RXD port of the panel’s SEI-2 card: • Connect the In+ wire to the RXD+ pin.
Page 163 CLSS Gateway | Honeywell Connected Life Safety Services On the Gateway Side • Ensure that the RS-232 cable is connected in the RS-232 port of the gateway. • Switch the S7 Switch next to the RS-232 port towards NUP_IN. Figure C-9: The S7 Switch On the Panel Side •...
Page 164 CLSS Gateway | Honeywell Connected Life Safety Services C.3.9 TO MAKE A WINMAG CONNECTION ON RS-485 Using an RS-485 cable the CLSS Gateway and the panel are connected. The RS-485 ports in the gateway board are labeled as 3 and 4 in the "Gateway Connection Options - Bottom Side" on page 142.
Page 165 CLSS Gateway | Honeywell Connected Life Safety Services Tools 8000 Settings for FlexES Panels Select the Serial Interfaces tab on Tools 8000. Go to the Serial Interface 1 section. Select WINMANG from the Device in use list. Click OK. Go to the Serial Interface 3 section.
Page 166 CLSS Gateway | Honeywell Connected Life Safety Services CMSI 8000 Settings for CMSI Panel • Add the UAE settings on the panel and enable them as shown in Figure C-13: CMSI Panel Settings . Figure C-13: CMSI Panel Settings Installation and User Manual | REV. K...
Page 167 CLSS Gateway | Honeywell Connected Life Safety Services C.4 FARENHYT PANELS C.4.1 CONNECTION OPTIONS The gateway operates only with the Farenhyt fire alarm control panels listed in the table below: Table C.2 Farenhyt Panel Connection Options Fire Alarm Panel RS-485 UART/TTL RS-232 USB Modes Panel firmware version: 6.05.03...
Page 168 CLSS Gateway | Honeywell Connected Life Safety Services C.4.4 POWER CONNECTION On the Gateway Side In the power supply port (labeled 7 in the Figure C-2: Gateway Connection Options - Bottom Side ): • Connect the Red wire to the +24V pin.
Page 169 CLSS Gateway | Honeywell Connected Life Safety Services C.4.5 PROGRAMMING FOR ANNUNCIATOR (ANN-PRI) Programming enables the panel to recognize the CLSS gateway and the annunciator. CAUTION: Before programming, ensure that the ANN-PRI communication cable is connected with the panel. C.4.6 TO PROGRAM FOR ANNUNCIATOR Using the keypad on the panel, you select options on the screens.
Page 170 CLSS Gateway | Honeywell Connected Life Safety Services C.5 FIRE-LITE® PANELS C.5.1 CONNECTION OPTIONS The gateway operates only with the Fire-Lite fire alarm control panels as listed in the table below: Table C.3 Fire-Lite Panel Connection Options Fire Alarm Panel RS485 UART/TTL RS232 USB...
Page 171 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-15: Fire-Lite Panel: RS485 Connections C.5.4 PROGRAMMING FOR ANNUNCIATOR (ANN-PRI) Programming enables the panel to recognize the CLSS gateway and the annunciator. Before programming, ensure that the ANN-PRI communication cable is connected with the panel.
Page 172 CLSS Gateway | Honeywell Connected Life Safety Services Enter the panel's password in the PROGRAMMING screen. The default password is: 00000000 Press the down arrow button to select 2 = POINT PRGORAM. Select 3 = FUTURE USE and then select 3 = ANNUNCIATORS.
Page 173 CLSS Gateway | Honeywell Connected Life Safety Services C.6 FIREWARDEN PANELS C.6.1 CONNECTION OPTIONS The gateway operates only with the FireWarden fire alarm control panels listed in the table below: Table C.4 FireWarden Panel Connection Options Fire Alarm Panel RS-485 UART/TTL RS-232 USB Models...
Page 174 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-16: FireWarden Panel: RS-485 Connections C.6.5 PROGRAMMING FOR ANNUNCIATOR (ANN-PRI) Programming enables the panel to recognize the CLSS gateway and the annunciator. Before programming, ensure that the ANN-PRI communication cable is connected with the panel.
Page 175 CLSS Gateway | Honeywell Connected Life Safety Services On the panel, press the Enter button on the keypad. View the panel screen options. On the keypad, press 2 to select 2 = PROGRAMMING MODE. Enter the panel's password in the PROGRAMMING screen.
Page 176 CLSS Gateway | Honeywell Connected Life Safety Services CAUTION: Ensure that only the ANN-s/pg is connected and not the clss gateway. only one of these two can be connected. both of them must not be connected together. C.6.9 POWER CONNECTION On the Gateway Side •...
Page 177 CLSS Gateway | Honeywell Connected Life Safety Services C.7 GAMEWELL-FCI PANELS C.7.1 CONNECTION OPTIONS Each variant of the Gamewell-FCI panel offers various connection options. The gateway operates only with the Gamewell-FCI fire alarm control panels listed in the table below: Table C.5 Gamewell-FCI Panel Connection Options...
Page 178 CLSS Gateway | Honeywell Connected Life Safety Services E3 Series Panel At the TB3 terminal of the panel, • Connect the +ve wire to the TB3-1 pin. • Connect the -ve wire to the TB3-2 pin. At the TB6 terminal of the panel, •...
Page 179 CLSS Gateway | Honeywell Connected Life Safety Services TB6 and RS-232 Connections The pin connections are as below: S3 Series Panel At the TB3 terminal of the panel, • Connect the +ve wire to the TB3-1 pin. • Connect the -ve wire to the TB3-2 pin.
Page 180 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-20: S3 Series: Gateway Connections TB5 and RS-232 Connections The pin connections are as below: Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 181 CLSS Gateway | Honeywell Connected Life Safety Services C.8 GENT PANELS C.8.1 CONNECTION OPTIONS The gateway operates only with the Gent fire alarm control panels listed in the table below: Table C.6 Gent Panel Connection Options Fire Alarm Panel RS-485 UART/TTL RS-232 USB Models...
Page 182 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-21: COMPACT Panels: RS-232 Connections on the PB6 Terminal C.8.3 POWER CONNECTION On the Gateway Side • Ensure that the RS-232 cable is connected with the RS-232 port of the gateway. • Ensure that the S7 switch next to the RS-232 port is switched towards NUP_IN.
Page 183 CLSS Gateway | Honeywell Connected Life Safety Services C.8.4 TO USE A USB CONNECTION On the Gateway Side • Connect the USB-C side of the cable to the USB port of the gateway. • The USB port is labeled as 8 in the figure Figure C-2: Gateway Connection Options - Bottom Side .
Page 184 CLSS Gateway | Honeywell Connected Life Safety Services To Use a UART/TTL Connection On the Gateway Side • Connect the male UART/TTL cable to the Rx (Red), Gnd (Silver), and Tx (White) UART/TTL terminals of the gateway. The UART/TTL port is labeled as 5 in Figure C-2: Gateway Connection Options - Bottom Side .
Page 185 CLSS Gateway | Honeywell Connected Life Safety Services On the Panel Side • Inside the panel enclosure, find the backplane PCB board. • Insert the I/O card into the P2 Card 15. • Insert the I/O card into P8 Card 6 ...
Page 186 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-26: Vigilon Terminal Card Connection Details For the P2 Card 15-Connected I/O Card: • In the panel, find the RS-485/RS-232 (P4) connectors on the main control board. • Connect the RS-232 cable to the Tx (Brown), Rx (White), and 0V (Green) terminals of the RS-485/RS-232 (P4) connectors.
Page 187 CLSS Gateway | Honeywell Connected Life Safety Services C.8.8.1 To Use a USB Connection On the Gateway Side • Connect the USB-C side of the cable to the USB port of the gateway. • The USB port is labeled as 8 in the figure Figure C-2: Gateway Connection Options - Bottom Side .
Page 188 CLSS Gateway | Honeywell Connected Life Safety Services C.9 MORLEY-IAS PANELS C.9.1 CONNECTION OPTIONS The gateway operates only with the Morley-IAS fire alarm control panels listed in the table below: Table C.7 Morley-IAS European Panel Connection Options Fire Alarm Panel RS-485 UART/TTL RS-232 USB...
Page 189 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-28: The S7 Switch On the Panel Side In the SK4 or SK5 terminal, • Connect the RS-232 cable for the non-resettable internal power. C.11 MORLEY MAX PANELS C.11.1 CONNECTION OPTIONS The gateway operates with the MA Series fire alarm control panels listed in the table below: Table C.8...
Page 190 CLSS Gateway | Honeywell Connected Life Safety Services SW5 is a slide switch and the settings RS232 / RS485 are clearly marked on the board itself. To switch RS232 <--> RS485 • Switch off the control unit • Disconnect from CNS-4, CNS-5, CNS-6 the device acting as External Equipment •...
Page 191 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-31: Terminals of AW80US0 v01 Figure C-32: Terminals of AW80US0 v02 Figure C-33: 4-Way Dip Switch Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 192 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-34: Slide Switch Figure C-35: Slide Switch Detail Figure C-36: Panel Side RS232 and Power Cable Connection Panel side RS232 lines will be connected to CNS-4(TX), CNS-5(GND), and CNS-6(RX) on AW80US0 board. Power line +ve (CNU-9) and GND- (CNU-10).
Page 193 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-37: Gateway Board with RS232 Connection Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 194 CLSS Gateway | Honeywell Connected Life Safety Services In the panel HMI, please select the below option to enable the serial communication over TPP. On the Gateway Side Connect to an RS-232 port of the gateway board On the Panel Side •...
Page 195 CLSS Gateway | Honeywell Connected Life Safety Services To Upload Panel Configuration File to Cloud Before installing the gateway, configuration file of the panel set up needs to be uploaded to cloud. Steps involved in uploading the configuration file: • Connect the USB drive into the panel as shown in Figure C-39: USB Drive Connected in Panel to Retrieve Configuration File Figure C-39: USB Drive Connected in Panel to Retrieve Configuration File •...
Page 196 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-41: Morley - IAS Tool Figure C-42: Config File Import into Morley IAS Tool • Now export the file into CSV format as shown in Figure C-43: Configuration File Export into CSV Format Installation and User Manual | REV.
Page 197 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-43: Configuration File Export into CSV Format • Select the required folder and export the file as shown in Figure C-44: Configuration File Export Figure C-44: Configuration File Export Installation and User Manual | REV. K...
Page 198 CLSS Gateway | Honeywell Connected Life Safety Services • Now from the configuration export folder shows all the details of the panel set up with devices attached to it. Select the XML format of the configuration file and upload that to CLSS as shown in Figure C-45: Configuration File Upload to CLSS...
Page 199 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-47: Standard Protocol Selection for Morley MAX Series Panel Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 200 CLSS Gateway | Honeywell Connected Life Safety Services C.12 NOTIFIER® UL C.12.1 CONNECTION OPTIONS The gateway operates only with the NOTIFIER fire alarm control panels listed in the table below: Table C.9 NOTIFIER UL Panel Connection Options Fire Alarm Panel RS-485 UART/TTL NUP USB...
Page 201 CLSS Gateway | Honeywell Connected Life Safety Services Direct Connection with the Panel Figure C-48: Stand-alone Panel: NUP Connection Connection through an NCM Card Using required network cards the gateway can connect to a Standard-speed Network of Panels or High-speed Network of Panels.
Page 202 CLSS Gateway | Honeywell Connected Life Safety Services Standard-speed Network of Panels Add an additional standard NCM card to the panel for the gateway connection. NOTE: For the standard-speed network, each device should have its NCM card on the panel with an available port.
Page 203 CLSS Gateway | Honeywell Connected Life Safety Services High-speed Network of Panels Connect the NUP cable into an open NUP port of the HS-NCM card on the panel. If no NUP port is available, an additional HS- NCM card must be added and connected.
Page 204 CLSS Gateway | Honeywell Connected Life Safety Services Connection through a DVC Card Connect the NUP port of the gateway and the DVC with a NUP cable. Then, connect the NUP port of the DVC and the panel. Figure C-51: Gateway Connection to Panel via DVC Installation and User Manual | REV.
Page 205 CLSS Gateway | Honeywell Connected Life Safety Services N16 or NFS2-3030: Disconnection Messages Disconnection Between the Gateway and the DVC Panel Message [GW_NODE_NUMBER] OFF NETWORK [DVC_NODE_NUMBER] COMMUNICATION LOSTOR Central Station Message [FIRE PANEL_NODE_NUMBER] COMMUNICATION LOST NETWORK MODULE COMMUNICATION LOST Panel Message...
Page 206 CLSS Gateway | Honeywell Connected Life Safety Services C.12.3 POWER CONNECTION NOTE: The external power supply must be dedicated and not shared with any other devices. NOTE: The panel’s power supply to the gateway must be within +24V DC power. On the Gateway Side Stand-alone Panel: •...
Page 207 CLSS Gateway | Honeywell Connected Life Safety Services C.13 NOTIFIER® EUROPEAN PANELS (EN) C.13.1 CONNECTION OPTIONS The gateway operates only with the NOTIFIER fire alarm control panels listed in the table below: Table C.10 NOTIFIER European Panel Connection Options Ethernet Fire Alarm Panel M odels RS- 485...
Page 208 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-53: Pearl Panel Setting and Connection with CLSS Gateway ID3000 Panel In the SK1 terminal at the communication card on the panel: • Connect the White wire to the RxD+ pin. • Connect the Green wire to the Gnd pin.
Page 209 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-54: ID3K Panel Setting and Connection with CLSS Gateway C.13.3 TO USE AN RS-485 CONNECTION Some NOTIFIER panel variants use an RS-485 connection with the CLSS Gateway. Only a standalone panel can have an RS-485 connection. On the Gateway Side •...
Page 210 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-55: The S7 Switch On the Panel Side Pearl Panels: At the TB7 terminal of the panel’s board: • Connect the +ve wire to the +ve pin. • Connect the -ve wire to the -ve pin.
Page 211 CLSS Gateway | Honeywell Connected Life Safety Services C.14 NOTIFIER INSPIRE EN Gateway to panel connection details Import Device Configuration Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 212 CLSS Gateway | Honeywell Connected Life Safety Services Automatic upload through Inspire EN "CLSS Configuration Tool" Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 213 CLSS Gateway | Honeywell Connected Life Safety Services Extracting the configuration manually, saving it in PC and then performing a manual upload of zip file. Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 214 CLSS Gateway | Honeywell Connected Life Safety Services C.15 AM SERIES PANELS C.15.1 CONNECTION OPTIONS The gateway operates only with the AM Series fire alarm control panels listed in the table below: Table C.11 AM Series Panel Connection Options Fire Alarm Panel Models RS-485 UART/TTL RS-232 USB...
Page 215 CLSS Gateway | Honeywell Connected Life Safety Services Note – CNS 7, 8 and 9 can also be used for RS232/RS485 connection. Panel side RS232 lines will be connected on to CNS– 4/CNS -7(TX), CNS-5/ CNS-8(GND) and CNS-6/ CNS-9(RX) on AW80US0 board.
Page 216 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-57: AM CL Series Block Diagram Figure C-58: CNS Connectors on AW80US0 Board for AM-CL series panels Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 217 CLSS Gateway | Honeywell Connected Life Safety Services NOTE: Pin 4 and 6 or 7 and 9 can be used in AW80US0 board for RS485 connection Figure C-59: AM_CL series RS485 Connection Diagram NOTE: Pin 4,5,6 or 7,8,9 can be used in AW80US0 for RS232 connection Figure C-60: AM_CL series panels Connection Diagram using RS232 Installation and User Manual | REV.
Page 218 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-61: AM8200N and AM8100 panels Connection Diagram using RS485 Figure C-62: CNS Connector on AW80US0 Board of Panel with RS-232 Connection AM CL Series Panel Figure C-63: CNS Connector on AW80US0 Board of Panel with RS-485 AM CL Series Panels Installation and User Manual | REV.
Page 219 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-64: CNS Connector on AM70PC0 Board of Panel with RS-485 Connection AM8200N/AM8100 Series Panel Communication Valid both for RS-232 and RS0485: Baud Rate (Fixed): 38400 Number of Bits (Fixed): 8 Stops Bits (Fixed): 1...
Page 220 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-66: Gateway Board with RS-232 Connection Figure C-67: Gateway RS-232 and Power Connection Detail Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 221 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-68: Gateway Board with RS-485 Connection Enabling the Serial Communication in Panel Go to panel programming manu, SIB to be installed. Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 222 CLSS Gateway | Honeywell Connected Life Safety Services C.15.4 TO UPLOAD PANEL CONFIGURATION FILE TO CLOUD Before installing the gateway, configuration file of the panel set up needs to be uploaded to cloud. Steps involved in uploading the configuration file: • Connect the USB drive into panel as shown in Figure C-69: USB Drive Connected in Panel to Retrieve Configuration File •...
Page 223 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-71: Switch Position to Retrieve Configuration File in AM8200N/Am8100 Series Panel • At this stage panel will display message – “Export configuraiton done” message in its UI. • Now press press over text to quit this window in panel UI, at this step configuration file in .BIN format is copyied into the USB drive.
Page 224 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-72: AM CL Series Tool Figure C-73: AM8200N/AM8100 Series Tool Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 225 CLSS Gateway | Honeywell Connected Life Safety Services Figure C-74: Config File Import into AM CL Series Tool Figure C-75: Config File Import into AM8200N Tool Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 226 CLSS Gateway | Honeywell Connected Life Safety Services • Now export the file into CSV format as shown in Figure C-76: Configuration File Export Into CSV Format Figure C-76: Configuration File Export Into CSV Format • Now from the configuration export folder shows all the details of the panel set up with devices attached to it. Select the XML...
Page 227 CLSS Gateway | Honeywell Connected Life Safety Services C.15.5 PANEL FIRMWARE UPGRADE METHOD • Connect the USB drive into panel which has the required panel firmware in it. • Locate the dip switch in the panel and move the SWITCH 4 to upwards position...
Page 228 CLSS Gateway | Honeywell Connected Life Safety Services • Choose firmware upgrade option from panel utility menu option. Figure C-80: Panel Firmware Upgrade Menu Option Installation and User Manual | REV. K Thursday, May 1, 2025...
Page 229 CLSS Gateway | Honeywell Connected Life Safety Services C.16 TRIGA PANELS C.16.1 CONNECTION OPTIONS The gateway operates only with the Triga fire alarm control panels listed in the table below: Table C.13 Triga Panel Connection Options Fire Alarm Panel RS-485 UART/TTL RS-232 USB Models...
Page 230 CLSS Gateway | Honeywell Connected Life Safety Services On the Panel Side In the power board of the panel: • Connect the Red wire to the +ve pin. • Connect the Black wire to the -ve pin. Figure C-81: Triga Panel: RS-485 Connections C.16.5 PROGRAMMING FOR ANNUNCIATOR (ANN-PRI)
Page 231 CLSS Gateway | Honeywell Connected Life Safety Services C.16.6 TO PROGRAM FOR ANNUNCIATOR Using the keypad on the panel, you select options on the screens. On the panel, press the Enter button on the keypad. View the panel screen options. On the keypad, press 7 to select 7 = PROGRAMMING MODE.
Page 232 CLSS Gateway | Honeywell Connected Life Safety Services C.17 VESDA® DETECTORS C.17.1 CONNECTION OPTIONS The gateway operates with VESDA detectors and sends alarm data to users. C.17.2 MINIMUM REQUIRED VERSIONS • For VESDA-E: All VESDA-E detector versions • For the CLSS Gateway: 3.3.4.12 C.17.3 TO USE AN ETHERNET CONNECTION Using an Ethernet cable the CLSS Gateway and the VESDA detectors are connected.
Page 233 CLSS Gateway | Honeywell Connected Life Safety Services APPENDIX D: COMPATIBLE CELLULAR MODULES The cellular modules offer value-added services for mobile devices connected with the CLSS Gateway. Figure D-1: A Cellular Module To know about installing this device onto the gateway, refer to "Installing A Single SIM Cellular Module (CCM-ATT-HON, CCM-VZ- HON,CCM-EU)"...
Page 234 CLSS Gateway | Honeywell Connected Life Safety Services Brand Name Verizon Cellular Module AT&T Cellular Module EU - Cellular Module Module Name CCM-VZ-HON CCM-ATT-HON CCM-EU Model LE910-SV1 LE910B1-NA LE910-EU1 • B3 (1800) 2G bands (MHz) • B8 (900) Replaceable SIM Card D.3 STANDARDS AND CODES...
Page 235 Events are reported to the Central Station using Contact ID* format. *Refer: Document LS10378-351HW-E Honeywell Contact IDs for events and their descriptions. The AES device is connected to CLSS Gateway using Eth0 (J3 connector) Interface. The communication data is encrypted using TLS 1.3 protocol.
Page 236 CLSS Gateway | Honeywell Connected Life Safety Services E.3 CONNECTING TO THE AES COMMUNICATOR Connect the AES communicator (Model # 7077) to the gateway as shown in Figure E-2: CLSS Gateway-AES Communicator Connections . Figure E-2: CLSS Gateway-AES Communicator Connections Installation and User Manual | REV. K...
Page 237 CLSS Gateway | Honeywell Connected Life Safety Services E.4 RECOMMENDED CYBERSECURITY PRACTICES Cybersecurity risk. FAILURE TO COMPLY WITH THE RECOMMENDED SECURITY PRACTICES IS A CYBERSECURITY RISK TO YOUR SYSTEM. It is recommended that the CLSS Gateway is directly connected to the AES communicator using an Ethernet cable, Do not use any Ethernet router or Ethernet switch for this connection.
Page 238 CLSS Gateway | Honeywell Connected Life Safety Services E.6 GENERATING CENTRAL STATION REPORT USING SITE MANAGER Generate central station reports from the CLSS Site Manager by uploading the configuration file to site manager as follows: Log onto the CLSS Site Manager. Click All Customers and select the customer name from the list (see Figure E-5: Site Manager - All Customers List ).
Page 239 CLSS Gateway | Honeywell Connected Life Safety Services APPENDIX F: LAN-CONNECTED CLSS HORIZON The LAN-Connected CLSS Horizon is a monitoring-only workstation, which allows multiple users to monitor their buildings, one or more networks, and life-safety systems. LCH supports Control command also.
Page 240 CLSS Gateway | Honeywell Connected Life Safety Services F.3 IP REQUIREMENTS F.3.1 IP PORT SETTINGS The following IP ports must be available for the CLSS Gateway: Table F.1 Required IP Ports Port Type Direction Purpose UDP and TCP DNS Resolution Web Based Configuration SNTP In/Out...
Page 241 CLSS Gateway | Honeywell Connected Life Safety Services Type Equipment Unmonitored but network compatible. • Legacy Gateway • NFN-GW-PC-HNSF • DVC • NFN-GW-PC-HNW • NCA-2 • NFN-GW-PC-HNW-2 Other Products • NCD • NFN-GW-PC-W • NFN-GW-EM-3 • NWS-3 • NFN-GW-PC-F • PC NFN Gateways •...
Page 242 CLSS Gateway | Honeywell Connected Life Safety Services F.6 CONFIGURATION SETTINGS You can configure the Ethernet settings either using the CLSS App or the CLSS Gateway Configuration Tool. F.6.1 TO CONFIGURE USING THE CLSS APP You install a fixed gateway when the gateway is not connected to the Internet.
Page 243 CLSS Gateway | Honeywell Connected Life Safety Services Select the Use the following ip address and enter: IP Address: 192.168.10.100 Subnet mask: 255.255.255.0 Default gateway: 192.168.10.1 Click “OK”. On the gateway board, find the S6 button. To find the S6 button, refer to Figure 2-1: Printed Circuit Board: Layout .
Page 244 CLSS Gateway | Honeywell Connected Life Safety Services Scroll down to Network Settings, and in the TIME SYNC SETTINGS section, click on the Enable Timesync checkbox, provide the Time Server details, and then click SAVE. Scroll down, and in the WLAN SETTINGS dialog, specify the wireless settings values, and then click SAVE.
Page 245 CLSS Gateway | Honeywell Connected Life Safety Services F.7 TO CONFIGURE THE GATEWAY IN CLSS HORIZON Log into the CLSS Horizon application. Go to System and then Networks on the menu bar. Provide the CLSS Gateway details and click OK. Installation and User Manual | REV. K...
Page 246 CLSS Gateway | Honeywell Connected Life Safety Services MANUFACTURER WARRANTIES AND LIMITATION OF LIABILITY Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan.
