AEG HYBRID SOLAR INVERTERS
USER MANUAL
VERSION: PD202311 V2-23
INVERTER SERIES:
AS-ICH02-2/HV
AS-ICH02-5000-2/HV | AS-ICH02-6500-2/HV |
AS-ICH02-8000-2/HV | AS-ICH02-10000-2/HV
HYBRID INVERTER, THREE-PHASE, 2 MPPT

Advertisement

loading
Need help?

Need help?

Do you have a question about the AS-ICH02-2/HV Series and is the answer not in the manual?

Questions and answers

Related Manuals for AEG AS-ICH02-2/HV Series

Summary of Contents for AEG AS-ICH02-2/HV Series

  • Page 1 AEG HYBRID SOLAR INVERTERS USER MANUAL VERSION: PD202311 V2-23 INVERTER SERIES: AS-ICH02-2/HV AS-ICH02-5000-2/HV | AS-ICH02-6500-2/HV | AS-ICH02-8000-2/HV | AS-ICH02-10000-2/HV HYBRID INVERTER, THREE-PHASE, 2 MPPT...
  • Page 2 Trademarks AEG is a registered trademark used under license from AB Electrolux (publ). AEG solar products are manufactured by Solar Solutions AG under license from AB Electrolux (publ). NOTICE The information in this user manual is subject to change due to product updates or other reasons.
  • Page 3 4.2 Deliverables ..............................................20 4.3 Storage ................................................21 5 Installation ������������������������������������������������������������������������������������������������������������������������������������22 5. 1 Installation Requirements ......................................22 5.2 Inverter Installation ..........................................25 5.2. 1 Moving the Inverter ........................................25 5.2.2 Installing the Inverter .......................................25 6 Electrical Connection ���������������������������������������������������������������������������������������������������������������27 PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 4 9. 1 Power OFF the Inverter ........................................52 9.2 Removing the Inverter ........................................52 9.3 Disposing of the Inverter.......................................52 9.4 Troubleshooting ............................................53 9.5 Routine Maintenance ........................................62 10 Technical Parameters ������������������������������������������������������������������������������������������������������������� 62 10. 1 Technical Parameters ..........................................62 PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 5 • AS-ICH02-10000-2/HV • AS-ICH02-6500-2/HV 1�2 Target Audience This manual applies to trained and knowledgeable technical professionals only. The technical personnel has to be familiar with the product, local standards, and electric systems. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 6 Highlights key information and supplements other text. It may include skills and methods to solve product-related problems. 1�4 Updates The latest document contains all the updates made in earlier issues. PD202308 AEG HYBRID INVERTER ICH02-2/HV USER MANUAL V1-23 EN First manual version PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 7 • Measure the DC cables with a multimeter to avoid reverse polarity connection. Also, the voltage should be under the permissible range. • Do not connect one PV string to more than one inverter at the same time. Otherwise, it may cause damage to the inverter. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 8 PE cable. to avoid being burnt. Do not dispose of the inverter as household waste.Discard the product CE marking in compliance with local laws and regulations, or send it back to the manufacturer. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 9 • Personnel who install or maintain the equipment must be strictly trained, learn about safety precautions and correct operations. • Only qualified professionals or trained personnel are allowed to install, operate, maintain, and replace the equipment or parts. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 10 • Restrictions of Hazardous Substances Directive 2011/65/EU and (EU) 2015/863 (RoHS) • Waste Electrical and Electronic Equipment 2012/19/EU • Registration, Evaluation, Authorization and Restriction of Chemicals (EC) No 1907/2006 (REACH) You can download the EU Declaration of Conformity on https://www.aeg-solar.com/service/ downloads PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 11 • 6500: the rated power is 6.5kW. • 8000: the rated power is 8kW. • 10000: the rated power is 10kW. Number of MPPT • 2= 2 MPPT System voltage • HV=1500 VDC (high voltage system) PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 12 • Normal household loads can be supported when the inverter is in back-up mode. Accepted loads as below: • Inductive loads: 1.5P non-inverter air conditioner • Capacitive loads: total power ≤ 0.6 times of the inverter’s rated output power. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 13 Self Consumption System (Hybrid Scenarios) Smart meter AC circuit breaker Inverter Utility Utility grid meter AC circuit PV string breaker Battery breaker Household loads Battery SPDT (Single Pole, Double Throw) switch BACK-UP loads PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 14 • AS-ICH02-8000-2/HV and AS-ICH02-10000-2/HV: the nominal current≥32A and the nominal voltage≥400V. AC circuit Depend on the actual using load. breaker Smart meter Included in the deliverables of the inverter. AS-IAM2-3000 Recommended model: PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 15 8. Determine whether to 9. Press "Set" to confirm. model based on the actual battery perform meter detection 10. Press "Exit" to finish. connected to the inverter. based on actual needs. 7. Press "Next". PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 16 When the total power consumption of the load exceeds the power consumption quota in a short period of time, battery discharge can be used to reduce the power exceeding the quota. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 17 3.3. 1 Inverter operation mode Off-grid mode Waiting mode Self-check mode Grid-Tied mode Fault mode PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 18 Fault mode If a fault is detected, the inverter enters the fault mode. When the fault is cleared, it enters the wait mode. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 19 In off-grid mode, the loads connected to the DO port can be turned off if the overload at the BACK-UP is detected or the battery SOC value is lower than the battery off-grid protection setting. Circuit breaker Inverter Household loads PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 20 • WiFi: supports 2.4GHz frequency band. Set the router to 2.4GHz or 2.4GHz/5GHz coexistence mode. The maximum length of a WiFi network name is 40 bytes. • LAN (optional): connects the inverter to the router via LAN communication and then to the server. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 21 • Long press for at least 3 seconds to factory reset the WiFi module. Indicators Indicates working status of the inverter. PE terminal Connects the grounding cable. Mounting Plate Used to install the inverter. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 22 BLINK 1 = Supplying energy to grid / zeroing. ENERGY BLINK 2 = Supplying energy to grid / selling. OFF = The grid is not connected or the system is not working. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 23 FAULT OFF = No fault. 3.5.4 Nameplate The nameplate is for reference only. AEG trademark, product type, and product model Technical parameters Safety symbols and certification marks Contact information and serial number PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 24 • The number of expansion bolts, screws, and AC cable terminals are various depending on different inverters. The actual accessories may differ. WARNING Connect the DC cables with the delivered terminals. The manufacturer shall not be liable for the damage if other terminals are used. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 25 4. The inverters must be stacked with caution to prevent them from falling. 5. If the inverter has been long term stored, it should be checked by professionals before being put into use. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 26 EMI filter. • Install the inverter at least 30m far away from the wireless equipment. Keep out Children No Touch Children No Touch of children reach ≥300mm ≥200mm ≥200mm ≥300mm ≥500mm PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 27 Installation Angle Requirements • Install the inverter vertically or at a maximum back tilt of 15 degrees. • Do not install the inverter upside down, forward tilt, back forward tilt, or horizontally. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 28 Goggles Safety shoes Safety gloves Dust mask crimping tool Diagonal pliers Wire stripper Hammer drill Heat gun Vacuum cleaner M3/M5 Marker Level Heat shrink tube Rubber hammer Torque wrench Multimeter Cable tie PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 29 Step 4 (Optional) Secure the DC switch with the DC switch lock, ensuring that the DC switch is "OFF" during installation. Step 5 Install the inverter on the mounting plate. Step 6 Tighten the nuts to secure the mounting plate and the inverter. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 30 1.2~2N·m PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 31 • All electrical connections should be performed by qualified professionals. • Cable colors in this document are for reference only. The cable specifications shall meet local laws and regulations. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 32 The following diagram is applicable to areas in Australia, New Zealand, South Africa, etc. Main panel Inverter BACK-UP loads Battery Do not wire in this position if N and PE cables are connected together. Smart Utility meter string grid Household loads PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 33 • The internal relay will automatically disconnect the N wire and PE cable when the inverter is in ON-GRID mode. Inverter Main Panel BACK-UP loads Battery Smart Utility meter string grid Household loads PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 34 PE cable. • Prepare PE cables with the recommended specification: Type: single-core outdoor copper cable Conductor cross-sectional area: 4-6mm L=L1+(1~2)mm Copper, 4-6mm 1.5~2N·m PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 35 • Ensure the DC cables are connected tightly, securely and correctly. • Measure the DC cables using a multimeter to avoid reverse polarity connection. Also, the voltage should be under the permissible range. PV2+ PV1+ PV1- PV2- Click PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 36 Stäubli MC4 PV connector 7 - 8mm Φ: 4-5mm 7 - 8mm ≤S≤6mm Click Click ≤1000V PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 37 Vaconn PV connector 2.5mm ≤S≤4mm Click Click ≤1000V PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 38 • Ensure the DC cables are connected tightly, securely and correctly. • Measure the DC cables using a multimeter to avoid reverse polarity connection. Also, the voltage should be under the permissible range. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 39 15mm Φ: 5.5-8mm 15mm Φ: 5.5-8mm ≤S≤6mm PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 40 RCDs can be connected to the outside of the inverter for protection when the DC component of the leakage current exceeds the limit value. The following RCDs are for reference: Inverter Model RCD Type (ON-GRID) RCD Type (BACK-UP) AS-ICH02-5000-2/HV AS-ICH02-6500-2/HV 300mA 30mA AS-ICH02-8000-2/HV AS-ICH02-10000-2/HV PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 41 • Ensure that the cables are connected securely. Otherwise it will cause damage to the inverter due to overheat during its operation. • Connect the ON-GRID cable before BACK-UP cable when connecting the AC cables. Type I 7-9mm 20-25mm Φ: 13-18mm Copper, 4mm ≤S≤6mm 0.6~0.8N·m PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 42 Type II 7-9mm 20-25mm Φ: 13-18mm Copper, 4mm ≤S≤6mm PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 43 Type III 7-9mm 20-25mm Steps to remove the AC cover for reference: Type I Type II Type III PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 44 LG battery enable signal DRM 2/6 or DI_2 LG_EN- DRM 3/7 or DI_3 13/14 DRED* or RCR DRM 4/8 or DI_4 15/16 COM/DRM0 or Load control REF_1 dry contact REFGEN or REF_2 PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 45 • Enable the DRED function or remote shutdown function via SolarGo app after cable connections. REF_1) (PIN 7 PIN 8 REF_2 100% PIN 6 DI 4 PIN 5 DI 3 PIN 4 DI 2 PIN 3 DI 1 Example: 6~8mm 0.12~0.8mm RS485 1.5N·m PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 46 DRED or RCR 1.5N·m Remote Shutdown 1.5N·m Battery Enable 1.5N·m PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 47 Load Control Dry Contact 1.5N·m PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 48 2: DRM2/6 3: DRM3/7 4: DRM4/8 5: REFGEN 6: COM/DRMO 0.8N·m 5: REFGEN Remote Shutdown 6: COM/DRMO 0.8N·m Enable the DRED function or remote shutdown function via SolarGo app after cable connections. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 49 100m. RJ45 connector with the following definition can be connected for BMS communication: Smart Color meter Orange and White Orange To Smart Meter Green and 485_B1 White Blue Blue and White Green 485_A1 Brown and 485_B1 White Brown 485_A1 PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 50 • The BMS communication cable is 3m long as a default and can be extended to a maximum of 5m. The communication cable connecting the inverter and the battery cannot be longer than 5m. RJ45 connector with the following definition can be connected for BMS communication: PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 51 Color Orange and White 485_A Orange 485_B Green and White 485_A Blue Blue and White Green 485_B Brown and White Brown Battery Smart meter To battery To smart meter To EMS device PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 52 NOTICE Refer to the delivered communication module user manual to get more introduction to the module. For more detailed information, visit www.aeg-solar.com PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 53 Step 2 Turn on the DC switch between the inverter and the battery. Step 3 (optional) Turn on the DC switch between the inverter and the PV string. Step 4 Turn on the DC switch of the inverter. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 54 BLINK 4 = WiFi server problem. OFF = WiFi is not active. ON = A fault has occurred. BLINK 1 = Back-up output overload / reduce load. FAULT OFF = No fault. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 55 SolarPortal is an monitoring platform used to communicate with the inverter via WiFi, LAN, 4G or GPRS. Commonly used functions: 1. Manage the organization or User information; 2. Add and monitor the power plant information; 3. Equipment maintenance. SolarPortal https://www�pvsolarportal�com/home/login PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 56 9�3 Disposing of the Inverter If the inverter cannot work anymore, dispose of it according to the local disposal requirements for electrical equipment waste. The inverter cannot be disposed of together with household waste. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 57 3. Check whether the AC circuit breaker and the output cables are connected securely and correctly if the problem persists. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 58 3. Check whether the AC circuit breaker and the output cables are connected securely and correctly if the problem persists. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 59 • Modify the overfrequency protection threshold or disable the overfrequency protection function after obtaining the consent of the local power company if the grid frequency is within the permissible range. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 60 • Contact the local power company if the of the local grid grid frequency exceeds the permissible standard. range. • Contact the dealer or the after-sales service if the grid frequency is within the permissible range. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 61 Large DC of AC 2. If the problem occurs frequently and the default range. current L2 PV station cannot work properly, contact the dealer or the after-sales service. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 62 Anti Reverse Abnormal after solving the problem. power Failure fluctuation of load 2. If the problem occurs frequently and the PV station cannot work properly, contact the dealer or the after-sales service. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 63 Disconnect the AC output switch and DC The internal Flash input switch, then connect them 5 minutes Flash Fault storage is abnormal. later. Contact the dealer or the after-sales service if the problem persists. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 64 PV Continuous configuration is input switch, then connect them 5 minutes Hardware not proper. later. Contact the dealer or the after-sales Overcurrent 2. The hardware is service if the problem persists. damaged. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 65 2. The hardware is service if the problem persists. damaged. String1 PV String The PV string Reversed Check whether the PV1 and PV2 strings are is connected connected reversely. String2 PV String reversely. Reversed PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 66 Start-up Voltage (V) Number of Battery Input Max. Continuous Charging Current Max. Continuous Discharging Current (A) Max. Charge Power (W) 7,500 8,450 9,600 10,000 Max. Discharge Power (W) 7,500 8,450 9,600 10,000 PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 67 5,000 6,500 8,000 10,000 Utility Grid (VA) Max. Apparent Power Output to 5,500 7, 1 50 8,800 11,000 Utility Grid (VA) Nominal Apparent Power from 10,000 13,000 15,000 15,000 Utility Grid (VA) PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 68 Max. Output Fault Current (Peak 45@2μs 45@2μs 45@2μs 45@2μs and Duration) (A) Inrush Current (Peak and Duration) 45@2μs 45@2μs 45@2μs 45@2μs Maximum Output Overcurrent Protection (A) Nominal Output Voltage (V) 400/380 400/380 400/380 400/380 PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 69 4000 Natural Natural Natural Natural Cooling Method Convection Convection Convection Convection User Interface LED, APP LED, APP LED, APP LED, APP Communication with BMS RS485, CAN RS485, CAN RS485, CAN RS485, CAN PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 70 Active Q Drift with Positive Feedback. / *6: CAN communication is configured default. If RS485 communication is used, please replace the corresponding communication line. / *7: No Back-up Output. / *8: Not all certifications & standards listed, check the official website for details. PD202311 AEG HYBRID INVERTER AS-ICH02-2/HV USER MANUAL V2-23...
  • Page 71 CONTACTS Solar Solutions AG Riedweg 3 6418 Rothenburg, Switzerland service@solarsolutions.ag www.aeg-solar.com AEG is a registered trademark used under license from AB Electrolux (publ)
