- Page 1 GSM gate controller GV17 Installation manual (FW:2.03) December, 2020 www.trikdis.com UAB Trikdis Draugystės str. 17, LT-51229 Kaunas, Lithuania +370 37 408 040 info@trikdis.lt...
-
Page 2: Table Of Contents
............................... 6 INDICATION OF OPERATION GV17 ......................6 GATE CONTROLLER STANDARD PACKING LIST 2 WIRING SCHEMATICS FOR THE GSM GATE CONTROLLER GV17 ..................7 ..................................7 ASTENING ........................7 CHEMATIC FOR CONNECTING THE POWER SUPPLY ............................7 CHEMATICS FOR CONNECTING INPUTS ........................... -
Page 3: Safety Precautions
GSM gate controller GV17 Safety precautions The GSM gate controller should only be installed and maintained by qualified personnel. Please read this manual carefully prior to installation in order to avoid mistakes that can lead to malfunction or even damage to the equipment. -
Page 4: Description
990 user telephone numbers. A user control schedule and counter for how many times a specific user can control the system can be set for the GV17. The GSM controller can send SMS messages informing when inputs and outputs are activated and restored (the text of the SMS messages is customizable). -
Page 5: Controller Elements
GSM gate controller GV17 Parameter Description Output 1, relay, 1 A 30 V DC, 0,5 A 125 V AC Unsent events memory Up to 60 events Event log memory Up to 5000 events Users who receive messages and have permission to control... -
Page 6: Led Indication Of Operation
6. Instruction manual for the automatic gate to which the GSM gate controller is about to be connected. Order the necessary components separately from your local retailer. 1.5 GSM gate controller GV17 standard packing list GSM gate controller GV17 1 pc. -
Page 7: Wiring Schematics For The Gsm Gate Controller Gv17
2.3 Schematics for connecting inputs The GV17 has four inputs IN (two of which are universal and can operate either as inputs or outputs) for the connection of various alarm sensors. These inputs can operate in NC, NO, EOL modes. Connect the inputs according to the set input type (NC, NO, EOL) as is shown in the schematics bellow: www.trikdis.com... -
Page 8: Schematic For Connecting The Relay
GV17‘s 1IN input. The state of the GV17‘s 1IN input gives precise information about the state of the gates (when the gates are closed and when they are open). Configuring the GV17 with the gate state indication is described in chapter 5.9 “Settings for gate state indication”. -
Page 9: Schematic For Connecting The E485 "Ethernet" Module
5 OUT relay output for 3 (three) seconds. The controller can be installed without any additional configuration if such operation mode is acceptable. 1. A nano-SIM card must be inserted into the GV17. Turn off PIN code requests for the card before inserting it into the controller. -
Page 10: Control Using Protegus Cloud
4.3 Control using Protegus Cloud With Protegus users will be able to control GV17 remotely. They will also be able to see the system state and receive all system event messages. 1. Download and launch the Protegus app or use the browser version of Protegus at www.protegus.eu/login. - Page 11 6. After clicking on a PGM button, the GV17 output is turned on. (Example: PGM3 – output turned off; PGM4 – output turned on, the PGM operation mode Level is set; PGM5 – output turned on, the PGM operation mode Pulse is set).
-
Page 12: Adding A Widget On Your Phone
GSM gate controller GV17 4.4 Adding a Widget on your phone The gate control Widget can be placed on your phone‘s home screen. The GV17 must be registered to Protegus. Log in to Protegus on your phone. Close the Protegus window. - Page 13 GSM gate controller GV17 Find Protegus in the settings bar. 2. Select Protegus. 3. Select Protegus (Switch). www.trikdis.com December, 2020...
- Page 14 GSM gate controller GV17 4. Choose GV17 PGM Output 5. 5. Press ADD WIDGET. 6. An icon will appear on the phone‘s screen. Return to the home screen. Press the icon. www.trikdis.com December, 2020...
-
Page 15: Adding Users On Your Phone
GSM gate controller GV17 A circle that shows when the PGM is turned on will appear on the screen. 7. When the GV17 is connected to the automatic gate with gate state indication, the icon will show the state of the open/closed gates. - Page 16 GSM gate controller GV17 2. Press Users. 3. Press Add user. 4. Access is allowed must be checked. 5. Enter the user's e-mail address. 6. Enter the user's phone number. 7. Check the PGM output 5 to be controlled by the user.
-
Page 17: Control With Sms Messages
GSM gate controller GV17 9. A new user appears in the user list. 10. Click Save to update the list of users on the controller. 11. Click the Return to Main Menu button. 4.6 Control with SMS messages Control the relay output OUT5 with these SMS commands:... - Page 18 GSM gate controller GV17 Once the first number is added to the GV17’s user phone list, the controller will react only to phone calls from the numbers on the list. The controller will ignore calls from other numbers. 3. Give administrator rights to another user You can give administrator rights to other people.
-
Page 19: Setting Parameters Using Trikdisconfig Software
Change Protegus Cloud login password. E.g.: CONNECT 123456 Code=123456 5 Setting parameters using TrikdisConfig software With TrikdisConfig you can change the GV17 controller’s settings (if default settings are not enough) according to the program window descriptions below. 1. Download the configuration software TrikdisConfig from www.trikdis.com/lt/ (enter “TrikdisConfig” in the search field) and install it. -
Page 20: Trikdisconfig Status Bar
Access level (shown after access code is approved) When the button Read [F4] is clicked, the program will read and show the settings currently saved on the GV17. With TrikdisConfig, adjust the required settings according to the program window descriptions below. -
Page 21: In/Out" Window
GSM gate controller GV17 Settings group “General” Object ID – enter account number (4 symbol hexadecimal number, 0-9, A-F. Do not use FFFE, FFFF Object ID.), provided by the central monitoring station. Object name – every event will be sent with the object name. - Page 22 GSM gate controller GV17 Inactive –input will be inactive for specified time after first activation. Enter 0 if you want to turn this function off. Delay - input (zone) reaction time, ms. CMS – if box is ticked, the message will be sent to CMS (Central Monitoring Station) and to Protegus.
-
Page 23: Modules" Window
GV17 controller. The module will be able to transfer data to Protegus and CMS (central monitoring station) via the Internet. Using a module (W485 or E485) with GV17: 1) does not use mobile internet, it is also possible to disable GV17 GPRS data transmission;... - Page 24 SMS. If the field is not checked and there is a WiFi network, then the call and SMS messages are not used. If the field is unchecked and there is no WiFi network, then GV17 can manage call and SMS messages. GV17 will send SMS messages to the user.
-
Page 25: Ip Reporting" Window
SMS messages will be sent to the response center’s SMS receiver: 1) as soon as the GV17 is enabled for the first time; 2) after loss of TCP/IP or UDP/IP connection in the main and backup channels. -
Page 26: User List" Window
En - check the box for the user to be activated. GRE - check the box to send an SMS message to the GV17 user. Scheduler – select the schedule number by which the user will be allowed to control the controller. - Page 27 GSM gate controller GV17 Administrator settings (numbers from 1A to 7A) ID – administrator number. Enabled – boxed is ticked, user is allowed to control outputs OUT. Name – specify administrator’s name. E-mail address – specify administrator’s e-mail address.
-
Page 28: Events Log" Window
Click the button Read Log. The Events Log will be read from the controller’s memory. The Events log provides information about the controller’s actions and its internal events. 5.8 Restore default settings To restore the default settings of the GV17 controller you need to click the Restore button in the TrikdisConfig program window. www.trikdis.com December, 2020... -
Page 29: Settings For Gate State Indication
5.9 Settings for gate state indication Protegus app and Widget can show the current state of the gates (closed or open). For this to work, the GV17‘s input IN1 must be connected to the automatic gate‘s state output as shown in chapter 2.5 “Schematic for connecting an automatic gate opener to the GV17”. -
Page 30: Setting Parameters Remotely
3. Launch the configuration program TrikdisConfig and in the field Unique ID of the Remote access section enter the IMEI number of your GV17 (the IMEI number is given on the stickers that can be found on the lower part of the device’s case and on the packaging). - Page 31 GSM gate controller GV17 5. Click the button Start update [F12]. 6. Wait for the update to finish. www.trikdis.com December, 2020...
