DYNATEK DFCM-7 User Manual

Fi controller

Download this manual

2801197

REV. 7-05-05

User Manual

2002-2005 Yamaha Road Star

Warrior

Part Number DFCM-7

Congratulations on your purchase of this Dynatek product.

Please take a moment to read these instructions completely before

installing the FI controller. The installation will only take a few minutes,

but proper setup for your specific bike will take longer

Parts List

FI Controller

Installation Guide

Wire tap

Wire ties

Velcro

Strip

Alcohol Swab

www.dynaonline.com

Dynatek • 164 S. Valencia St. Glendora CA 91741

800.928.3962

Need help?

Do you have a question about the DFCM-7 and is the answer not in the manual?

Page 1 FI controller. The installation will only take a few minutes, but proper setup for your specific bike will take longer Parts List FI Controller Installation Guide Wire tap Wire ties Velcro Strip ® Alcohol Swab www.dynaonline.com Dynatek • 164 S. Valencia St. Glendora CA 91741 800.928.3962...
Page 2 STEP 2 Mount the FI Controller in the proper location. STEP 3 Remove the fuel tank. Route the wiring harness from the FI Controller under the tank and through the frame. Part# DFCM-7...
Page 3 Injector harness STEP 5 Plug the FI Controller connector into the stock injector harness. STEP 6 The Throttle Position Sensor (TPS) is located on the right side of the throttle body, behind the airbox. Unplug this connector. TPS Connector Part# DFCM-7...
Page 4 On the TPS harness, locate the yellow wire. Using the supplied wire tap, tap into that wire. Make sure that the tap is on the wire securely. Connect the grey wire from the FI Controller harness to this connector. Reinstall the tank and seat. Part# DFCM-7...
Page 5: Troubleshooting
To add fuel, turn the potentiometer clockwise. To subtract fuel, turn the potentiometer counterclockwise. With the potentiometer pointed straight up at the thick tick mark (towards the Dynatek logo), that is 0% adjustment. Fully counterclockwise is -20%, and fully clockwise is +20%. Adjusting the potentiometer...
