RAIMONDI EXPLOIT Use And Maintenance Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
www.raimondispa.com
EN
EXPLOIT - BOLT - MISTRAL
USE AND MAINTENANCE INSTRUCTION MANUAL
TRANSLATION OF ORIGINAL INSTRUCTIONS IN ITALIAN

Advertisement

loading
Need help?

Need help?

Do you have a question about the EXPLOIT and is the answer not in the manual?

Questions and answers

Related Manuals for RAIMONDI EXPLOIT

Summary of Contents for RAIMONDI EXPLOIT

  • Page 1 EXPLOIT - BOLT - MISTRAL USE AND MAINTENANCE INSTRUCTION MANUAL TRANSLATION OF ORIGINAL INSTRUCTIONS IN ITALIAN...
  • Page 2 10.1 EXPLOIT ___________________________________________________________________________________ 25 10.2 BOLT _____________________________________________________________________________________ 27 10.3 MISTRAL ___________________________________________________________________________________ 29 The images of the products are for illustrative purposes, therefore they may not be perfectly representative of the product characteristics. Page 2/32 Mod. EXPLOIT - BOLT - MISTRAL_REV01_11/2022...
  • Page 3 UNDER ITS OWN RESPONSIBILITY THAT THE MACHINE: Type: BRIDGE SAWS FOR BRICKS AND TILES Model: EXPLOIT - BOLT - MISTRAL Function: CUTTING OF STONE MATERIAL AND BRICKS COMPLIES WITH ALL RELEVANT PROVISIONS OF THE FOLLOWING EU COMMUNITY DIRECTIVES: Machines 2006/42/EC...
  • Page 4 Environmental conditions other than those specified can cause serious damage to the machine and in particular to the electrical equipment. 2.2 responsibility Raimondi S.p.A. is not in any case responsible for anomalies in operation or general faults, caused by the unauthorised use of the machine or by interventions and/or changes made by external persons not authorised by Raimondi S.p.A.
  • Page 5 Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 2.4 register your machine Raimondi S.p.A. machines are guaranteed for a period of 12 months from the date of purchase. By registering your machine you will receive a quick and effective assistance service.
  • Page 6 18 December 2006 concerning the Registration, Evaluation, Authorisation and Restriction of Chemicals. With reference to the Directives in question, Raimondi S.p.A. declares that the products marketed by it have been pre-registered by our suppliers as of 1 December 2008.
  • Page 7 ChAPTER 3 www.raimondispa.com Via dei Tipografi 11, 41122 Modena (MO) - Italy Safe use of the product Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 SAFE USE OF ThE prODUCT 3.1 Environmental conditions THE MACHINE MUST BE STORED AND INSTALLED ON A STABLE, FLAT AND NOT INCLINED SURFACE THE MACHINE MUST BE POSITIONED IN AN AREA PROTECTED FROM THE RAIN.
  • Page 8 11. Never start the machine before having warned and removed all the personnel near it. 12. Before starting the machine, the operator must check for any visible defects on the machine. In this case, immediately notify RAIMONDI S.p.A. or the nearest Assistance Centre of any evident breakage.
  • Page 9 ChAPTER 3 www.raimondispa.com Via dei Tipografi 11, 41122 Modena (MO) - Italy Safe use of the product Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 27. Above an altitude of 1000m it is necessary to take into account possible variations in the parameters of dielectric stiffness and cut off capacity of the devices.
  • Page 10 10. Use of the machine with tools not provided by the manufacturer. 3.8 reasonably foreseeable misuses, it is forbidden: 1. Tampering with the machine or its safety devices; 2. Tampering with fixed guards; 3. Bypassing the safety devices; 4. Climbing onto the machine. Page 10/32 Mod. EXPLOIT - BOLT - MISTRAL_REV01_11/2022...
  • Page 11 Depending on the machine model, the use of sector disks may be allowed or prohibited, refer to the following table and the information on the machine plate. THE USE OF TOOLS OTHER THAN THOSE INDICATED IS PROHIBITED. MACHINE MODEL 50Hz/60Hz EXPLOIT 34 Kg 32 l Not permitted 45 mm 60 mm...
  • Page 12 Support surface: surface on which the material rests to be cut. Page 12/32 Mod. EXPLOIT - BOLT - MISTRAL_REV01_11/2022...
  • Page 13 An additional protective device is the plug of the power supply, which in case of danger must be disconnected immediately. RAIMONDI S.P.A. WILL NOT BE HELD RESPONSIBLE FOR DAMAGE DUE TO EJECTION CAUSED BY POOR MAINTENANCE OF THE PROTECTION DEVICES, THEIR TAMPERING OR INCORRECT OPERATOR POSTURE (SEE “SECTION 4.3”).
  • Page 14 2.20 1.93 The test documents and instrument certificates are deposited with Raimondi S.p.A. at the disposal of the supervisory authorities. The analysis of the measurement uncertainty is reported in detail on the test documents. The uncertainty factors considered relevant are systematic errors due to the acquisition system (less than 4%) and errors due to random fluctuations in the physical parameters involved, calculated with a coefficient of variation on at least 3 measures.
  • Page 15 ChAPTER 5 www.raimondispa.com Via dei Tipografi 11, 41122 Modena (MO) - Italy Product usage Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 prODUCT USAGE 5.1 packaging handling Transport by forklift truck with adequate capacity (>200 Kg), inserting the forks in the appropriate seats of the pallet. 5.2 Machine handling BEFORE EACH MOVEMENT CHECK THAT THE MOTOR UNIT IS CORRECTLY SECURED.
  • Page 16 After plugging the drain hole with the drain plug, pour cold, clean water into the tank until it reaches a level that covers 2 cm (0.8”) the recirculation pump by 2 cm (25/32"). Page 16/32 Mod. EXPLOIT - BOLT - MISTRAL_REV01_11/2022...
  • Page 17 ChAPTER 5 www.raimondispa.com Via dei Tipografi 11, 41122 Modena (MO) - Italy Product usage Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 5.5 power supply For the correct operation of the machine and the safety of the operators, the user is obliged to: ENSURE THAT THE SYSTEM TO WHICH THE MACHINE IS CONNECTED IS EQUIPPED WITH AN ADEQUATE AND EFFICIENT EQUIPOTENTIAL PROTECTION CIRCUIT (GROUND);...
  • Page 18 IS WITHIN THE TOLERANCE OF THE MACHINE. For a successful cutting, the disc must be suitable for the material to be cut and correctly dressed. For proper dressing, perform repeated cuts on the disc-dressing stone (D). Page 18/32 Mod. EXPLOIT - BOLT - MISTRAL_REV01_11/2022...
  • Page 19 ChAPTER 6 www.raimondispa.com Via dei Tipografi 11, 41122 Modena (MO) - Italy Execution of cuts Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 6.2 preliminary adjustments Depending on the model there may be adjustments to be made before cutting. FEED LIMIT SWITCh ADJUSTMENT Some models are equipped with a stop under the slide bar to limit the stroke of the motor unit.
  • Page 20 Some models can be equipped as standard or as optional with the hand wheel feeder, this is particularly useful to reduce the work effort and make the feeding speed more constant. If the hand wheel is present, rotate it manually to advance the cutting unit. Page 20/32 Mod. EXPLOIT - BOLT - MISTRAL_REV01_11/2022...
  • Page 21 ChAPTER 6 www.raimondispa.com Via dei Tipografi 11, 41122 Modena (MO) - Italy Execution of cuts Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 6.4 Jolly 45˚ cut BEFORE MAKING CUTS MAKE SURE THAT THE TILT LOCKING HANDLES OR KNOBS (G) AND DISC LIFT (H) ARE SCREWED FULLY AND THAT THE ABRASIVE DISC DOES NOT STRIKE PARTS OF THE MACHINE IF PRESENT, ADJUST THE SPLASH GUARDS SO AS TO AVOID AS MUCH AS POSSIBLE THE PROJECTION OF WATER SPLASHES.
  • Page 22 On some models it is possible to remove the plastic tank for a more accurate cleaning. THE DISPOSAL OF WATER FROM THE WASTE CONTAINED WITHIN THE TANK MUST TAKE PLACE IN COMPLIANCE WITH THE LEGAL PROVISIONS IN FORCE IN THE COUNTRY OF USE. Page 22/32 Mod. EXPLOIT - BOLT - MISTRAL_REV01_11/2022...
  • Page 23 ChAPTER 8 www.raimondispa.com Via dei Tipografi 11, 41122 Modena (MO) - Italy Troubleshooting Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 TrOUBLEShOOTING NEVER ATTEMPT RISKY SOLUTIONS AND ALWAYS RESORT TO PROFESSIONAL TECHNICIANS FOR TROUBLESHOOTING BE SURE TO WEAR ALL THE PPE PROVIDED FOR IN CHAPTER 3.5 If the engine does not run, check: 1.
  • Page 24 Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 WIrING DIAGrAM 9.1 Single-phase machines The following wiring diagram is valid for the machine in the 230 Volt (50 /60 Hz) version and for EXPLOIT 110 Volt version. COMPONENT LIST LISTA COMPONENTI / LIST OF COMPONENTS...
  • Page 25 Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 10. SpArE pArTS 10.1 Exploit ELEM. COD. ITEM DESCRIPTION ELEM. COD. ITEM DESCRIPTION 114TZ08D SLIDE BAR LL.896 EXPLOIT 70/15 EXPLOIT ADV 114TZ09D SLIDE BAR LL.1126 EXPLOIT 90 16/6 297IN40D MOT.0.65KW 230V 50/60HZ M63R 156NL09D SILVER AN.AL. GRILLE...
  • Page 26 ChAPTER 10 www.raimondispa.com Via dei Tipografi 11, 41122 Modena (MO) - Italy Wiring diagram Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 16/5 16/3 16/6 16/4 16/1 16/2 Page 26/32 Mod. EXPLOIT - BOLT - MISTRAL_REV01_11/2022...
  • Page 27 ChAPTER 10 www.raimondispa.com Via dei Tipografi 11, 41122 Modena (MO) - Italy Spare parts Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 10.2 Bolt ELEM. COD. ITEM DESCRIPTION ELEM. COD. ITEM DESCRIPTION 114RE22D SLIDE BAR LL1428 BOLT 120 150) 114RE23D SLIDE BAR LL1728 BOLT 150 10 240JET230V60H 230V 60Hz IMMERSION PUMP (BOLT...
  • Page 28 ChAPTER 10 www.raimondispa.com Via dei Tipografi 11, 41122 Modena (MO) - Italy Spare parts Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 Page 28/32 Mod. EXPLOIT - BOLT - MISTRAL_REV01_11/2022...
  • Page 29 ChAPTER 10 www.raimondispa.com Via dei Tipografi 11, 41122 Modena (MO) - Italy Spare parts Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 10.3 Mistral ELEM. COD. ITEM DESCRIPTION ELEM. COD. ITEM DESCRIPTION 114RE22D1 SLIDE BAR LL. 1418 MISTRAL 120 120-150 114RE23D1 SLIDE BAR LL.
  • Page 30 ChAPTER 10 www.raimondispa.com Via dei Tipografi 11, 41122 Modena (MO) - Italy Spare parts Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 Page 30/32 Mod. EXPLOIT - BOLT - MISTRAL_REV01_11/2022...
  • Page 31 NOTES www.raimondispa.com Via dei Tipografi 11, 41122 Modena (MO) - Italy Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 Notes Page 31/32 Use and maintenance instruction manual...
  • Page 32 NOTES www.raimondispa.com Via dei Tipografi 11, 41122 Modena (MO) - Italy Tel.: +(39) 059 280888 - Fax: +(39) 059 282808 Notes Page 32/32 Mod. EXPLOIT - BOLT - MISTRAL_REV01_11/2022...
