RocwooD RWLMSP18 Owner's Manual

Self propel lawnmower
Hide thumbs

Advertisement

Quick Links

Download this manual
RocwooD Petrol
Lawnmower
RWLMSP18
OWNERS MANUAL
EN
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY,
PROPERTY DAMAGE AND MAY VOID WARRANTY.
KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary
in appearance, assembly, inclusions, specifications, description, and packaging.

Advertisement

loading
Need help?

Need help?

Do you have a question about the RWLMSP18 and is the answer not in the manual?

Questions and answers

Related Manuals for RocwooD RWLMSP18

Summary of Contents for RocwooD RWLMSP18

  • Page 1 RocwooD Petrol Lawnmower RWLMSP18 OWNERS MANUAL READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary...
  • Page 2 Introduction This manual has been produced by RocwooD and should be kept with the product and referenced for operation, maintenance and troubleshooting. This manual contains an overall description of the product, together with all the necessary information for using the product correctly and safely.
  • Page 3 Specification Brand RocwooD RWLMSP18 Drive Type Self Propel Lawnmower Engine Displacement 150cc Starting System Recoil Start Cut Width 46cm Tank Capacity 0.8L Power Source Petrol Cutting Heights 8 positions from 25-75mm Collector Capacity Blade Style Rotary Blade Noise Level 96dBA...
  • Page 4 Contents 2) Introduction 3) Specification 4) Contents 5) For Safe Operation 6-7) Safety 8) Features 9-10)Parts Assembly 11-13) Assembly 14) Pre-Operation Checklist 15) Starting the Engine 16) Stopping the Engine 17) Additional Operations 18-20) Maintenance 21) Troubleshooting 22) Warranty...
  • Page 5 For Safe Operation Risk of electric shock. Wear protective gloves. Wear ear protection Hot surface. Sharp Moving Parts Wear eye protection. Wear appropriate clothing. The manufacturer cannot anticipate every possible hazardous Risk of explosion. circumstance that the user may encounter. Therefore, the warnings in this manual, on tags, and on affixed decals are not all-inclusive.
  • Page 6 Safety Read and understand the owner's manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & Instructions in this manual and on the product.
  • Page 7 Safety Keep work area clean and well lit. Cluttered and dark areas invite accidents. Check the landscape where the machine will be used and remove all objects such as stones, toys, sticks and wires, which could be caught and thrown away from the work area. Damage of the machine or operator's injury could be caused.
  • Page 8 Features 1) Drive lever (clutch lever) 11) Height adjusting handle 2) Soft grip handle 12) Rear wheel 3) Upper handle 13) Engine oil cap 4) Brake lever /stop lever 14) Side discharge cover 5) Quick lock handle 15) Side discharge chute 6) Lower handle 16) Deck 7) Grass box...
  • Page 9 Parts Assembly...
  • Page 10 Parts Assembly...
  • Page 11 Assembly Packing List: Lawnmower Grass Catcher 4x Wheels Do not operate this item if any of the Handle parts are damaged or missing until Lower Handle the part is replaced. Using this Handle Knobs product with damaged or missing parts can cause damage to the Side Chute machine or result in serious injury or Mulching Plug...
  • Page 12 Assembly 4) Assemble the Grass Catcher 3) Tidy the Connection Cord Clip the plastic clips over the metal Fix the cord that connects the handle frame. Make sure that these clips are to the mower with the provided clip to fully secured to the metal frame avoid catching it.
  • Page 13 Assembly 7) Assembling the Side Chute 8) Add Oil Into Lawnmower When use side discharge function. First Place mower on a level surface. Remove one or both of the dipsticks to need remove the grass bag and plug the mulching plug. Lift the side discharge ensure you do not overfill the engine.
  • Page 14 Pre-Operation Checklist ☑ Read and understand this operator manual in it's entirety before operating Check oil level and add oil to the proper level if low ☑ Check fuel level and add fuel if needed ☑ Check connections of handle and all wheels to make sure they are secure ☑...
  • Page 15 Starting the Engine 1) Press the Primer (Only for Cold) 2) Pull the Engine Start Lever Stand behind the mower. Pull the engine When starting a cold engine, press down start/stop lever toward upper handle With the primer fully 3-5 times. (For lawnmower one hand and place the other hand on the with a throttle control you will need to put recoil start.
  • Page 16 Stopping the Engine 1) Press the Primer (Only for Cold) Release the engine start/stop lever, it will return to its Initial position, the engine will automatically switch off. To Clean a Flooded Engine NOTE: if the engine won’t start after you have Operated the starter several times , the engine may be flood with excess fuel .
  • Page 17 Additional Operations Working Advices Walk, never run with the mower, be very careful when mowing uneven or rough ground. Mow across slopes, never up and down. Be careful when changing the direction of the mower on a slope. Do not mow excessively steep slopes. The best result will be achieved if the grass is dry.
  • Page 18 Maintenance Before performing any maintenance or cleaning work, switch off the engine and wait until the blade has come to a stop. General cleaning The lawn mower should be cleaned thoroughly every time after it has been used. Always clean your lawnmower immediately after use. Do not allow grass cuttings and other debris to become dry and hard on any of the mower surfaces.
  • Page 19 Maintenance Storing the Lawnmower for Short Periods The lawnmower can be stored for short periods of time (less than 15 days) without performing any storage maintenance. Before placing the lawnmower into storage always carry out the following: Allow the engine to fully cool. Ensure the grass bag is empty.
  • Page 20 Maintenance Replacing the Blade For safety reasons you should only ever have your blade sharpened, balanced and mounted by an authorised service workshop. For optimum results it is recommended that the blade should be inspected once a year. Before you remove the grass collection bag, stop the engine and wait until the blade stops completely.
  • Page 21 Troubleshooting WARNING: Before performing any maintenance or cleaning work, switch off the engine and wait until the blade has come to a stop. Caution Improper repairs can result in the product functioning unsafely. This endangers yourself and your environment. Faults which cannot be rectified with the aid of the following table may be rectified by a specialist company only (customer service center).
  • Page 22 (c) RocwooD Ltd will arrange collection of faulty goods within the first 60 days and thereafter it will be a return to base Warranty (the customer must return and we will check, if found faulty the machine will be repaired and returned back to the customer.
