Maytag MAH55 Series Technical Information

Front Load Washer⎯ ⎯ ⎯ ⎯ ⎯ Technical Information
MAH5500B*, MAH55FL*
• Due to possibility of personal injury or property damage, always contact an authorized technician
for servicing or repair of this unit.
• Refer to Service Manual 16010061 for detailed installation, operating, testing, troubleshooting, and
disassembly instructions.
All safety information must be followed as provided in Service Manual 16010061.
.
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testing requires power.
Model
Power Source
Voltage AC
Amperage (Single Unit)
Frequency
Motor horsepower
Dimensions
Cabinet
Height-overall
Height of cabinet
Width
Depth with Door Open
Depth with Rear Assembly
Depth of Cabinet
Weight
Crated
Water Supply
Water Supply Temperature
Range
Effective Hose Length
Water Pressure Range
Drain
Effective Hose Length
Max Standpipe Height
Recommended Standpipe Height
August 2006
©2006 Maytag Services
!
CAUTION
!
WARNING
MAH5
Features
120 VAC High-Efficiency
15 A No-Agitator Wash System
60 Hz Extra-Large Capacity (3.34 Cu. Ft.)
1/2 Easy-To-Use Electronic Controls
Pedestal Riser Compatible
Elustra Stainless Steel Tub
42 1/2" Sloped Front Cabinet Plus Front Load Design
36 1/4" Meets ENERGY STAR Efficiency Standards
27" 2005 Energy-Compliant
50 1/2" Infinite Motor Speed
29" Odds & Ends Tray
28 1/4" Handwash Fabric Selection
Faster Spin Spin Speed
193 lbs. Extra Rinse
Presoak
AutoFill Water Level Control
120-140° F
4 feet Four Water Temperature Combinations
20-120 psi Automatic Temperature Control
Automatic Additive Dispenser
4 feet End-Of-Cycle Chime
9 feet Special Cycles Include Spin and Rinse & Spin
18"
1
Model
MAH5
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
16027401
