- Page 1 Manual Belt air compressor 31.7 gal Tank Applies for: Code Item 19358 COMP-120LV COMP-120LV COMP-120LV Read this manual thoroughly CAUTION before using the tool.
- Page 2 IF THE COMPRESSOR DOESN´T WORK AFTER A LONG PERIOD OF INACTIVITY, deactivate the thermal switch as instructed on the label attached to the tank. If the compressor doesn't work or turn on, visit a TRUPER Authorized Service Center. ASSEMBLY the rubber supports to keep the compressor level (page 7).
- Page 3 The construction class of the charger is: Class B WARNING If the power cable is damaged, it must be replaced by the manufacturer or a TRUPER Service Center to prevent any risk of electric shock or significant accident. The electrical insulation of this tool is compromised by splashes or spillage of liquids during its operation.
- Page 4 A moment of distraction while using the tool can cause personal injury. Service Use safety equipment. Always wear eye protection. To maintain the tool's safety, repair it at a TRUPER Authorized Service Center using only identical replacement parts. The use of safety equipment, such as safety glasses, dust masks, slip-resistant shoes, helmets, and ear protection, in appropriate conditions significantly reduces the risk of personal injury.
- Page 5 • Avoid using the compressor outdoors a short period. Disconnect the tool after use. during rain or on wet surfaces to prevent the risk of • The use of accessories not recommended by TRUPER electrocution. can result in personal injury.
- Page 6 Parts Pressure switch filter Motor junction Switch button Overload protection Oil fill plug Tank pressure gauge Crankcase Motor Oil level sight glass Crankcase drain screw Check valve 1/4” outlet valve Safety valve Tank Drain valve ENGLISH...
- Page 7 Start up Assembly Automatic operation Carefully place the compressor on a flat, level, and sturdy Once the compressor has started, it will stop and restart surface. Attach the rubber feet using their respective automatically. Your compressor has a factory-preset screws and hex nuts. pressure switch that stops the motor when the tank pressure reaches its maximum operating pressure and restarts the motor when the tank pressure drops to the...
- Page 8 Maintenance Regular maintenance will ensure maximum efficiency over an extended period. Daily preventive maintenance OIL: Check the oil level in the crankcase and top up if necessary. If your compressor is unused daily, check the crankcase oil level before starting. Change the oil after Crankcase 500 hours of use.
- Page 9 PISTON RINGS: Inspect the sealing and oil scraper rings if the compressor consumes excessive oil. Worn rings need replacement. Always change the oil when replacing the rings or other significant components. CAUTION These adjustments should be performed at a TRUPER Authorized Service Center. ENGLISH...
- Page 10 2. Let the compressor cool for at least 5 minutes. 3. Press the thermal switch on the motor's top cover. 4. Turn the compressor back on by lifting the switch. NOTE: Please visit a TRUPER Authorized Service Center if the unit shuts off again. Motor drive pulley...
- Page 11 • Visit the nearest TRUPER Authorized Service pistons Center. • Loose pulley or excessive axial play in • For service and repairs, visit the nearest TRUPER Knocks or rattling the motor shaft Authorized Service Center. • Carbon on top of the piston •...
- Page 12 Rust in the cylinders • Using incorrect oil • Change and use SAE-30 oil. • Compressor operated for a long time in • For service and repairs, visit the nearest TRUPER a humid environment Authorized Service Center. Excessive starts and •...
- Page 13 Notes ENGLISH...
- Page 14 Notes ENGLISH...
- Page 15 Authorized service centers In the event of any problem contacting a TRUPER Authorized Service Center, please see our webpage WWW.TRUPER.COM to get an updated list, or call our toll-free numbers 800 690-6990 or 800 018-7873 to get information about the nearest Service Center.
- Page 16 It includes transportation expenses for the product resulting from its service network compliance. Tel. 800-018-7873. Made in/Hecho en China. Importer TRUPER, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Tel. 761 782 9100.
