aspenhome
ah
ITEM NO:
I3048-444P
I3048-445P
I3048-402
I3048-442
Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts that may come loose inside the carton during shipment.
I3048-442
I3048-402
I3048-442
I3048-402
WARNING! Before using this product, please read, understand, and follow these instructions. Failure to follow
each of these assembly instructions precisely may result in damage to the product and / or injury to the consumer.
Page 1/5
Q/K Bed Tall Posts
Q/K Bed Short Posts
Queen Rails
Queen HB & FB Panels
UNIT SHOULD BE INSTALLED BY 2 OR MORE PERSONS.
I3048-444P
I3048-442
I3048-445P
I3048-442
FOR INDOOR USE ONLY
MADE IN VIETNAM
ASSEMBLY INSTRUCTIONS
R
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
All Beds need to be set up in the exact final
location so that after full assembly it will not
need to be moved. Moving the bed will cause
the support legs to move out of perpendicular
(90 degree), weaken the support system, and
may allow the bed to collapse.
01-17-2024
