- Page 1 Installation manual Washer extractor EUD-615CV, EUD-618CV, EUD-625CV, EUD-630CV, EUD-645CV, EUD-660CV, EUD-680CV Type W3..438905978/US 2025.02.11...
- Page 3 Safety WARNING: ALL OPERATING AND MAINTENANCE PROCEDURES SHOWN ON THE NEXT PAGE OF THIS MANUAL MUST BE FOLLOWED DAILY FOR PROPER OPERATION OF YOUR MACHINE. MAKE CERTAIN TO KEEP THIS MANUAL IN A SECURE PLACE FOR FUTURE REFERENCE. PLEASE ENTER THE FOLLOWING INFORMATION AS IT APPEARS ON THE MACHINE(S) DATA PLATE(S).
- Page 4 Safety IMPORTANT SAFETY INSTRUCTIONS WARNING - To reduce the risk of fire, electric shock, or injury to persons when using your appliance, including the following: 1. Read all instructions before using the appliance. 2. This machine must be securely bolted to an uncovered concrete floor. 3.
- Page 5 Safety NOTICE TO: OWNERS, OPERATORS AND DEALERS IMPROPER INSTALLATION AND INADEQUATE MAINTENANCE, POOR HOUSEKEEPING AND WILLFUL NEGLECT OR BYPASSING OF SAFETY DEVICES MAY RESULT IN SERIOUS ACCIDENTS OR INJURY. TO ASSURE THE SAFETY OF CUSTOMERS AND/OR OPERATORS OF YOUR MACHINE, THE FOLLOWING MAINTENANCE CHECKS MUST BE PERFORMED ON A DAILY BASIS. Prior to operation of the machine, check to make certain that all operating instructions and warning signs are affixed to the machine and legible.
-
Page 6: Notice To Installer
Improper fastening of this machine to its foundation, inferior foundation materials, an undersized foundation, the use of fabricated steel bases not provided by Electrolux Professional or its approved supplier(s), the use of an improper type, number, or size of mounting bolts, or failure to use proper hardware on mounting bolts may result in damage to the machine that will not be covered by the manufacturer's warranty. -
Page 7: Table Of Contents
Contents Contents 1 Safety Precautions ..........................9 General safety information......................9 Commercial use only........................9 Copyright ..........................10 Ergonomics certification ......................10 Symbols..........................10 2 Warranty terms and exclusions......................11 3 Technical data...........................12 Drawing ..........................12 3.1.1 EUD-615CV, EUD-618CV, EUD-625CV ................12 3.1.2 EUD-630CV........................13 3.1.3 EUD-645CV, EUD-660CV, EUD-680CV ................14 Technical data .........................15 Connections ..........................15 4 Setup ...............................16... - Page 8 Contents The manufacturer reserves the right to make changes to design and component specifications.
-
Page 9: Safety Precautions
Installation manual 1 Safety Precautions • Servicing shall be carried out only by authorized personnel. • Only authorized spare parts, accessories and consumables shall be used. • Only use detergent intended for water-wash of textiles. Never use dry cleaning agents. •... -
Page 10: Copyright
1.3 Copyright This manual is intended solely for consultation by the operator and can only be given to third parties with the permis- sion of Electrolux Professional AB company. 1.4 Ergonomics certification The human body is designed for movement and activity but physical stress injuries as a result of static and repetitive movements or unfavorable working postures may occur. -
Page 11: Warranty Terms And Exclusions
Warranty will be applicable where the customer has used only genuine spare parts and has performed maintenance in accordance with Electrolux Professional AB user and maintenance documentation made available in paper or electronic format. Electrolux Professional AB strongly recommends using Electrolux Professional AB approved cleaning, rinse and des- caling agents to obtain optimal results and maintain product efficiency over time. -
Page 12: Technical Data
Installation manual 3 Technical data 3.1 Drawing 3.1.1 EUD-615CV, EUD-618CV, EUD-625CV fig.X01114 Display Door opening, EUD-615CV, EUD-618CV: ⌀ 310 mm / 12 3/16 inch, EUD-625: ⌀ 365 mm / 14 3/8 inch Detergent container Cold water Hot water Cold/Hot water or Re-used water with network pressure (option) Re-used water from tank/pump or Liquid detergent supply Drain Liquid detergent supply... -
Page 13: Eud-630Cv
Installation manual 3.1.2 EUD-630CV fig.X01116 Display Door opening, EUD-630CV: ⌀ 395 mm / 15 9/16 inch Detergent container Detergent container (option) Cold/Hot water (Detergent container) Cold water Hot water Cold/Hot water or Re-used water with network pressure (option) Re-used water from tank/pump or Liquid detergent supply Drain Liquid detergent supply Electrical connection... -
Page 14: Eud-645Cv, Eud-660Cv, Eud-680Cv
Installation manual 3.1.3 EUD-645CV, EUD-660CV, EUD-680CV fig.X01115 Display Door opening, EUD-645CV, EUD-660CV, EUD-680CV: ⌀ 435 mm / 17 1/8 inch Detergent container Detergent container (option) Cold/Hot water (Detergent container) Cold water Hot water Cold/Hot water or Re-used water with network pressure (option) Re-used water from tank/pump or Liquid detergent supply Drain Liquid detergent supply... -
Page 15: Technical Data
Installation manual 3.2 Technical data EUD- EUD- EUD- EUD- EUD- EUD- EUD- 615CV 618CV 625CV 630CV 645CV 660CV 680CV Weight, net 1235 Drum volume litres 10.6 Drum diameter inch 20 1/2 20 1/2 23 7/16 25 9/16 28 9/16 31 5/16 31 5/16 Drum speed during wash Drum speed during extraction... -
Page 16: Setup
Installation manual 4 Setup 4.1 Unpacking 4.1.1 EUD-615, EUD-618, EUD-625 Removal of the bolts between the machine and pallet Remove the front and rear panel. fig.X01120F Remove the bolts between the machine and pallet. fig.X01121 Remove the machine from the pallet. Note! When moving the machine, handle it with care. - Page 17 Installation manual Removal of the transport securities When the machine is placed in final or close to final position, remove the four transport supports. Save the transport supports if the machine needs to be moved in the future. Note! Once the transport supports have been removed, handle the machine carefully to avoid damage to the sus- pension components.
-
Page 18: Eud-630, Eud-645, Eud-660, Eud-680
Installation manual 4.1.2 EUD-630, EUD-645, EUD-660, EUD-680 Removal of the bolts between the machine and pallet Note! Two persons are recommended for the unpacking. Remove the side panels. Remove the front and rear panel. fig.X01123 Remove the bolts between the machine and pallet. fig.X01124 Remove the machine from the pallet. - Page 19 Installation manual Removal of the transport securities When the machine is placed in final or close to final position, remove the four transport supports. Save the transport supports if the machine needs to be moved in the future. Note! Once the transport supports have been removed, handle the machine carefully to avoid damage to the sus- pension components.
-
Page 20: Recycling Instruction For Packaging
Installation manual 4.2 Recycling instruction for packaging fig.X02400 Fig. Description Code Type Wrapping film LDPE 4 Plastics Corner protection PS 6 Plastics Cardboard packaging PAP 20 Paper Pallet FOR 50 Wood Screw FE 40 Steel FE 40 Steel Plastic bag PET 1 Plastics... -
Page 21: Siting
Installation manual 4.3 Siting Install the machine close to a floor drain or open drain. The machine should be positioned so that there is plenty of room for working, both for the user and service personnel. The figure shows minimum distance to a wall and/or other machines. Failure to respect the prescribed distances will prevent easy access for maintenance and service operations. - Page 22 Installation manual inch EUD-615 19 1/2 18 1/8 4 5/16 4 15/16 14 3/4 6 11/16 1 9/16 3 15/16 EUD-618 19 1/2 18 1/8 4 5/16 4 15/16 14 3/4 6 11/16 1 9/16 3 15/16 EUD-625 22 5/8 18 5/16 5 1/8 5 1/2...
-
Page 23: Water Connection
Installation manual 5 Water connection All water intake connections to the machine should be fitted with manual shut-off valves and filters, to facilitate instal- lation and servicing. Water pipes and hoses should be flushed clean before installation. The machine shall be connected with new water hoses. Re-used water hoses must not be used. Hoses are to be of an approved type and grade and comply with national regulations. -
Page 24: Connection Of External Dosing Systems
Installation manual 6 Connection of external dosing systems Depending on which type of dosing system that is going to be connected, follow the instructions enclosed with the dosing system. The following is some preparations that can be made on the machine. 6.1 Jetsave and Dosave 6.1.1 Connection of the tube... -
Page 25: Drain Connection
Installation manual 7 Drain connection Connect a 75 mm / 3 inch (50 mm / 1 15/16 inch for models EUD-615, EUD-618, EUD-625) pipe or rubber hose to the machine’s drain pipe, ensuring a downward flow from the machine. Avoid sharp bends which may prevent proper draining. -
Page 26: Electrical Connection
Installation manual 8 Electrical connection 8.1 Electrical installation The electrical installation may only be carried out by qualified personnel. Machines with frequency-controlled motors can be incompatible with certain types of earth leakage circuit break- er. It is important to know that the machines are designed to provide a high level of personal safety, which is why items of external equipment such as earth leakage circuit breakers are not necessary but is recommended. - Page 27 Installation manual EUD-618 Electrical connections Heating alternative Main voltage Heating power Total power Recommended fuse ITCB A Electric heated 208-240V 1~ 2.0/3.0 5.2/3.4 15/20 208-240V 1~ 5.4/7.5 5.7/7.8 30/50 208-240V 3~ 2.0/3.0 5.2/3.4 15/15 208-240V 3~ 5.4/7.5 5.7/7.8 20/25 440V 3~ 5.4/7.5 5.7/7.8 15/15...
- Page 28 Installation manual EUD-660 Electrical connections Heating alternative Main voltage Heating power Total power Recommended fuse ITCB A Electric heated 208-240V 3~ 19.8/23.0 20.5/23.7 70/70 440V 3~ 21.0/23.0 21.7/23.7 40/40 480V 3~ 22.8/23.0 23.5/23.7 40/40 Non heated/Steam heated 208-240V 1~ 440/480V 1/3~ Total power and recommended fuse does not depend on the heating power in those cases.
-
Page 29: Machine Connection With Ferrite
Installation manual 8.3 Machine connection with ferrite 8.3.1 EUD-630CV, EUD-645CV, EUD-660CV, EUD-680CV To obtain approved level of EMC, it is mandatory to use the ferrite which is enclosed with above listed models. (Note that this is only valid for those models). Before connecting to the machine, the protective earth (PE) wire shall be wrapped around the ferrite. -
Page 30: Machine Connection
Installation manual 8.4 Machine connection Connect the earth and other wires according to the table. Single-phase connection Three-phase connection 1NAC L2 L3 3N AC L2 L3 1N/1 3N AC L2/N Single phase machines may be powered either by connection between a phase and neutral or by connecting be- tween two phases. -
Page 31: Connection Of External Functions
Installation manual 8.6 Connection of external functions 8.6.1 Outputs Depending on machine configuration, the outputs are configured according to the following table: Connection Config. 22A Config. 22B Terminal 12 Steam valve (if dual heating) Steam valve (if dual heating) Terminal 13 Liquid 1 Terminal 14 Liquid 2... -
Page 32: Inputs
Installation manual 8.6.2 Inputs Depending on machine configuration, the inputs are configured according to the following table: Connection Config. 22A Config. 22B Terminal 5 Enable start Enable start Terminal 6 Remote start /stop Remote start /stop Terminal 7 Coin 1 Coin 1 Terminal 8 Pause... -
Page 33: Functions For I/O-Boards
Installation manual 8.7 Functions for I/O-boards The electrical schematic can be one of the following: 8.7.1 Enable start (22A, 22B) This signal can be used to permit the start of the program when the machine is in standby. Once permission to start has been granted, the signal from the central payment or the booking system must remain active (high) until the machine starts. -
Page 34: Remote Start/Stop (22A, 22B)
Installation manual 8.7.2 Remote start/stop (22A, 22B) This signal can be used to start the program when the machine is in standby, to pause the cycle when running and to continue the cycle when paused. The central payment system must provide a pulse to start the program. To receive the feedback signal from the machine, 230V or 24V must be connected to terminal 19. -
Page 35: External Coin Meter/Central Payment (22A, 22B)
Installation manual 8.7.3 External coin meter/Central payment (22A, 22B) The signal received from external coin meter must be a pulse between 300–3000 ms (500 ms is recommended) with a minimum pause of 300 ms (500 ms is recommended) between two pulses. Con 112 A122 I/O type... -
Page 36: Pause (22A, 22B)
Installation manual 8.7.4 Pause (22A, 22B) This signal can be used to pause the program when running. When the signal is activated, the program will pause for as long as the signal remains active (high), e.g. while waiting for central dosing system to be ready. Con 112 A122 I/O type... -
Page 37: Dual Heating (22A, 22B)
Installation manual 8.7.5 Dual heating (22A, 22B) This output is used to activate the steam valve on machines made for dual heating. Con 112 A122 I/O type Function Steam valve (if Dual heating) fig.X01693... -
Page 38: Trigger Signals For Dosing System Without Saving (22B)
Installation manual 8.7.6 Trigger signals for dosing system without saving (22B) The following outputs can be used as trigger signals for dosing system or for activation of external pumps. Con 112 A122 I/O type Function 230V +24V fig.X01710... -
Page 39: Dual Heating And Trigger Signals For Dosing System Without Saving (22B)
Installation manual 8.7.7 Dual heating and Trigger signals for dosing system without saving (22B) On machines with Dual heating, the trigger signals refer to the internal power (230V). In this case, no other power sources are allowed. Con 112 A122 I/O type Function fig.X01711... -
Page 40: Converting Heating Elements
Installation manual 8.8 Converting heating elements 8.8.1 EUD-615, EUD—618 and EUD-625 can be converted from 400-415V 3AC to 230- 240V 1AC with reduced power Disconnect the power to the machine. Demount the front panel and remove the cover to the heating elements. Remove the blue cables. -
Page 41: Power
Installation manual 8.8.2 EUD-630 can be converted from 380-415V 3N AC to 220-240V 1N AC with reduced power Disconnect the power to the machine. Demount the cover panel to the electrical connections. Remove the cables that are connected to K21:2 and K22:6. Move the remaining cables from L2 and L3 to L1 or N ac- cording to the figure. -
Page 42: Steam Connection
Installation manual 9 Steam connection Inlet pipes connected to the machine must be equipped with a manual shut-off valve to facilitate installation and serv- icing. The connection hose must be of type ISO/1307- 1983 or equivalent. Connection size at filter: DN 15 (BSP 1/2"). Demount the top panel (A). - Page 43 Installation manual Mount the hose with wires between steam valve and machine. Connect the wires to the steam valve. Connect ground cable to the terminal ground connection. Connect the ”HEAT” cable connector to the ”HEAT” terminal on the I/O board. ”HEAT”...
-
Page 44: Steam Connection For Dual Heating (Option For Eud-630, Eud-645, Eud-660, Eud-680)
Installation manual 10 Steam connection for dual heating (option for EUD-630, EUD-645, EUD-660, EUD-680) Inlet pipes connected to the machine must be equipped with a manual shut-off valve to facilitate installation and serv- icing. The connection hose must be of type ISO/1307- 1983 or equivalent. Connection size at filter: DN 15 (BSP 1/2"). - Page 45 Installation manual Mount the hose with wires between steam valve and machine. Connect the wires to the steam valve. Connect ground cable to the terminal ground connection. Cut the wires a few centimeters from the “HEAT-connector”. ”HEAT” fig.6604E Connect the cut wires to connection 11 and 12 on the I/O board. fig.X01689...
- Page 46 Installation manual Connect jumpers between connection 1 and 9 and between connection 2 and 10 on the I/O board. fig.X01690 Steam pressure required: • minimum: 50 kPa / 7 psi • maximum: 800 kPa / 115 psi • recommended: 600 kPa / 87 psi Note! A steam heated machine is only intended to use clean steam.
-
Page 47: Machine With Level Tube And Test Tap (Option For Eud-630, Eud-645, Eud-660, Eud-680)
Installation manual 11 Machine with level tube and test tap (option for EUD-630, EUD-645, EUD- 660, EUD-680) Machines with this option is built for specific customers who need to see or inspect the water level inside the drum via a glass tube which is mounted on the side of the machine. A provided test tap is prepared for the tester/inspector and it is possible to collect sample(s) of water from the drum. -
Page 48: At First Power Up
Installation manual 12 At first power up When the installation is complete and the power is connected for the first time you will be forced to make some set- tings. Follow the instructions on the display. When one setting is ready you will automatically enter the next one. If installation is made in a public area, it is only allowed to select the below segmets: APARTMENT AUTO DOSING APARTMENT MANUAL DOSING... -
Page 49: Function Check
Installation manual 13 Function check May only be carried out by qualified personnel. A function check must be made when the installation is finished and before the machine can be ready to be used. Open the manual water valves. Start a program. •... -
Page 50: Disposal Information
Installation manual 14 Disposal information 14.1 Disposal of appliance at end of life Before disposing of the machine, make sure to carefully check its physical condition, and in particular any parts of the structure that can give or break during scrapping. The machine’s parts must be disposed of in a differentiated way, according to their different characteristics (e.g. - Page 52 www.electroluxprofessional.com...
