  • Page 1 WTSL4E300 Washer Dryer User Manual...

  • Page 2: Table Of Contents

    20. GUARANTEE ....................43 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.

  • Page 3: Safety Information

    ENGLISH Subject to change without notice. SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
  • Page 4 The appliance shall be installed as a freestanding • product or below the kitchen worktop if space margins permit. Do not install the appliance behind a lockable door, a • sliding door or a door with a hinge on the opposite side, that would prevent the appliance door from being fully opened.
  • Page 5 ENGLISH Wipe away lint or packaging debris that has • accumulated around the appliance. Items that have been soiled with substances such as • vegetable or mineral oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed separately with an extra amount of detergent before being dried in the washer dryer.

  • Page 6: Safety Instructions

    2. SAFETY INSTRUCTIONS 2.1 Installation • This appliance complies with the E.E.C. Directives. • Follow the installation instruction supplied with the appliance. 2.3 Water Connection • Do not install or use the appliance • Do not cause damage to the water where the temperature can be less hoses.

  • Page 7: Installation

    ENGLISH • Do not sit or stand on the open door. • Remove the door catch to prevent • Do not dry dripping wet clothes in the children or pets from becoming appliance. trapped in the drum. • Dispose of the appliance in 2.5 Disposal accordance with local requirements for the disposal of Waste Electrical...

  • Page 8: Positioning And Levelling

    7. Remove the polystyrene protection 10. Remove the three bolts by using the from the bottom. key supplied with the appliance. 8. Pull up the appliance in vertical 11. Pull out the plastic spacers. position. 12. Put the plastic caps, that you find in the user manual bag, in the holes.
  • Page 9 ENGLISH 2. Loosen or tighten the feet to adjust the level. WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level. Make sure that the inlet hose is not in vertical position. 3. If necessary, loose the ring nut to set it in the correct position.

  • Page 10: Water Drainage

    If this occurs, close the water tap and contact the authorized service centre to replace the hose. Make sure that the drain 3.5 Water drainage hose end is not immersed in the water. There may be a The drain hose should stay at a height of...

  • Page 11: Product Description

    ENGLISH 5. Without the plastic hose guide, to 6. Position the hose directly to a built- a sink spigot - Put the drain hose in in drain pipe in the room wall and the spigot and tighten it with a clamp. tighten it with a clamp.

  • Page 12: Control Panel

    5. CONTROL PANEL 5.1 Control panel description 11 10 Programme dial Time Save touch button Display Anti-crease touch button Drying time touch button Stains/Prewash touch button Drying level touch button Spin reduction touch button Mode touch button On/Off push button •...
  • Page 13 ENGLISH Maximum laundry indicator. It flashes when the laundry load ex‐ ceeds the maximum declared load of the selected programme. Detergent quantity indicator: the value shows the percentage of de‐ tergent quantity needed. Child safety lock indicator. Drying time indicator. Door locked indicator.

  • Page 14: Dial And Buttons

    Pre-wash indicator. Stain indicator. Energy saving indicators. It appears when you set the Cotton Eco programme. Delay start indicator. 5.3 Multilingual badges Adhesive badges in different languages are supplied with the appliance. The desired badge can be glued around the programme dial.
  • Page 15 ENGLISH This option is not The display shows the indicator available with a The drum turns regularly to reduce temperature lower than creasing. 40 °C. The door stays locked. The drum turns regularly to reduce creasing. • Prewash You must drain the water to unlock Use this option to add a prewash the door.

  • Page 16: Programmes

    On the display the relevant dryness 6.8 Anti-crease indicator goes on: This option adds a short anti-crease phase at the end of the programme. • Iron dry: laundry to be ironed. This phase reduces fabric creasing and facilitates the fabric ironing.
  • Page 17 ENGLISH Programme Programme description Synthetic items or mixed fabric items. Normal soil. Synthetics Delicate fabrics such as acrylics, viscose and mixed fabrics requiring a mild washing. Normal soil. Delicates Machine washable wool, hand washable wool and oth‐ er fabrics with «hand washing» care symbol Wool/Handwash Do not use fabric softener and make sure that Outdoor...
  • Page 18 Programme Programme description To rinse and spin the laundry. All fabrics, except woollens and very delicate fabrics. Reduce the spin speed accord‐ Rinse ingly to the type of laundry. To spin the laundry and to drain the water in the drum. All fabrics, except woollens and delicate fabrics.
  • Page 19 ENGLISH Programme options compatibility Options ■ ■ ■ ■ ■ ■ ■ ■ ■ Spin ■ ■ ■ ■ ■ ■ ■ Rinse Hold ■ ■ ■ ■ Extra Silent ■ No Spin ■ ■ ■ ■ ■ ■ ■ Extra Rinse ■...

  • Page 20: Automatic Drying

    Options ■ ■ Drying Levels 1) If you set No Spin option, the appliance only drains the water. 2) This option is not available with temperature lower than 40 °C. 3) If you set the shortest duration, we recommend that you decrease the load size. It is pos‐...
  • Page 21 ENGLISH Dryness Level Type of fabric Load Cottons and Linen up to 6 kg Cupboard Dry (bathrobes, bath towels, For items to be stored etc) Synthetics and mixed up to 4 kg fabrics (jumpers, blouses, under‐ wear, household linen) Delicate fabrics up to 2 kg (acrylics, viscose and deli‐...

  • Page 22: Before First Use

    Dryness Level Type of fabric Load Spin Suggested (kg) spee duration (mins) (rpm) Cupboard Dry Cottons and Linen 1600 235 - 255 For items to be (bathrobes, bath towels, etc) 1600 155 - 175 stored 1600 115 - 125...

  • Page 23: Daily Use

    ENGLISH 9.2 Acoustic signals 9.3 Permanent Extra Rinse This appliance is provided with different With this option you can permanently acoustic signals, that operate when: have one or two extra rinses when you set a new programme. • You activate the appliance (special short tune).

  • Page 24: Loading The Laundry

    4. If necessary, touch the related buttons to add some options and/or to set a delayed start. The display shows the symbol of the set option and/or the digit shows the delayed time. 10.4 Loading the laundry 1. Open the appliance door.

  • Page 25: Starting A Programme

    ENGLISH 4. To use liquid detergent, turn the flap down. Always follow the instructions that you find on the packaging of the detergent products, but we recommend that you do not exceed the maximum indicated level ( ). This quantity will however guarantee the best washing results.
  • Page 26 The related indicator stops flashing and 3. Touch the Start/Pause button again stays on. to start the new countdown. In the display, the indicator of the 10.9 The ProSense load operating phase starts flashing and the detergent percentage indicator goes off.

  • Page 27: End Of The Programme

    ENGLISH If you select the Steam programme the The programme or the delay start continues. steam phase indicator comes on. 10.14 End of the programme 10.11 Interrupting a programme and changing the options When the programme has finished, the appliance stops automatically. The When the programme is running, you acoustic signals operate (if they are can change only some options:...

  • Page 28: Daily Use - Washing & Drying

    10.16 Stand-by option • The door stays locked. • You must drain the water to open the The Stand-by function automatically door: deactivates the appliance to decrease 1. If necessary, touch the Spin button to the energy consumption when: decrease the spin speed proposed •...

  • Page 29: Daily Use - Drying Only

    ENGLISH 11.2 Washing and Drying - drying level indicator goes off and the Automatic levels indicator comes on. Each time you tap on this button the time 1. Tap on the Drying Levels button value increases by 5 minutes. The repeatedly until the display shows the display shows the set new time value.
  • Page 30 4. Tap on the Mode button twice to value (see the "Timed drying" table exclude washing and perform drying the "Programmes" chapter). The only. The Dry indicator is on. The drying level indicator goes off and the indicator comes on.

  • Page 31: Fluff In The Fabrics

    ENGLISH 13. FLUFF IN THE FABRICS During the washing and/or drying phase, To remove the fluff inside the drum, some types of fabric, (sponge, wool, set a special programme: sweatshirt) could release fluff. • Empty the drum. • Clean the drum, the gasket and the The released fluff could stick to the door with a wet cloth.

  • Page 32: Drying Hints

    14.3 Detergents and other Use the correct quantity of water softener. Follow the instructions that you treatments find on the packaging of the product. • Only use detergents and other 14.6 Drying hints treatments specially made for washing machines: Prepare the drying cycle –...

  • Page 33: Care And Cleaning

    ENGLISH • weight of the load Experience will help you to dry the laundry better. Take note of the duration 14.10 Additional drying of the cycles done before. To avoid the static charge at the end of If, at the end of the drying programme, the drying cycle: the laundry is still damp, set a short drying cycle again.

  • Page 34: Cleaning The Drum

    15.5 Cleaning the drum Regularly examine the drum to prevent rust forming. For a complete cleaning: 1. Clean the drum with special products for stainless steel. Always follow the instructions that you find on the packaging of the product.
  • Page 35 ENGLISH 4. Let the water flow out. Regularly check the drain pump filter and make sure that it is clean. Clean the drain pump if: • The appliance does not drain the water. • The drum does not turn. • The appliance makes an unusual noise because of the blockage of the drain pump.
  • Page 36 10. Clean the filter under the water tap. When you drain the water with the emergency drain procedure, you must activate the drain system again: a. Put 2 litres of water in the main wash compartment of the detergent dispenser.

  • Page 37: Troubleshooting

    ENGLISH 15.9 Emergency drain If the appliance cannot drain the water, carry out the same procedure, described in 'Cleaning the drain filter' paragraph. If necessary, clean the pump. When you drain the water with the emergency drain procedure, you must activate the drain system again: 1.
  • Page 38 • - The appliance does not fill with • - The mains supply is unstable. water properly. Wait until the mains supply is stable. • - The appliance does not drain • - No communication between the water. electronic elements of the appliance.
  • Page 39 ENGLISH Problem Possible solution • Make sure that the water tap is open. • Make sure that the pressure of the water supply is not too low. For this information, contact your local water authority. • Make sure that the water tap is not clogged. The appliance does not •...
  • Page 40 Problem Possible solution • Make sure the levelling of the appliance is correct. Refer to "Installation instruction". The appliance makes • Make sure that the packaging and/or the transit bolts an unusual noise and are removed. Refer to "Installation instruction".

  • Page 41: Consumption Values

    ENGLISH After the check, activate the appliance. The programme continues from the point of interruption. If the problem occurs again, contact the Authorised Service Centre. If the display shows other alarm codes. Deactivate and activate the appliance. If the problem continues, contact the Authorised Service Centre. 16.3 Emergency door opening To open the door, proceed as follows: 1.

  • Page 42: Technical Data

    During the washing programme, the Prosense technology can vary the wash duration and the consumption values. For more details see 'The Prosense load detection' paragraph in 'Daily Use' chapter. Programmes Load Energy Water con‐ Approximate pro‐ (kg) con‐ sumption...

  • Page 43: Accessories

    ENGLISH 19. ACCESSORIES 19.1 Available in Verify the compatible www.aeg.com/shop or from stacking kit by checking the authorised dealer depth of your appliances. The stacking kit can be used only with Only appropriate the appliances specified in the leaflet accessories approved by provided with the accessory.

  • Page 44: Environmental Concerns

    Point of Service Morgenstrasse 131 3018 Bern Zürcherstrasse 204E 9000 St. Gallen Seetalstrasse 11 6020 Emmenbrücke Schlossstrasse 1 4133 Pratteln Comercialstrasse 19 7000 Chur Spare parts service Industriestrasse 10, guarantee covers the costs of materials, 5506 Mägenwil, Tel. 0848 848 111 labour and travel.
  • Page 45 ENGLISH...
  • Page 46 www.electrolux.com...
  • Page 47 ENGLISH...
  • Page 48 www.electrolux.com/shop...
