BS
®
Motor
Link
(wired/battery powered)
USER MANUAL
EN
NL
DE
FR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BS Link and is the answer not in the manual?

Questions and answers

Related Manuals for Forest BS Link

Summary of Contents for Forest BS Link

  • Page 1 Link ® Motor (wired/battery powered) USER MANUAL...

  • Page 2: Table Of Contents

    (2.4mtr) (EU 3636000004 & UK 3636000005) Date: 07-01-2025 Function: Head R&D Signature: FEATURES & BENEFITS • Motor including Bluetooth capabilities • Works directly with Forest Connect app • Both cable-operated and battery-powered options available SUPPORTED PROTOCOL • 4kg weight load This BS Motor is equipped with ®...

  • Page 3: Your Bs® Link Motor

    Group. Forest Group does not assume liability for resulting damages to AREAS OF USE The BS® Link motor is designed for use with the Forest Roman Blind persons, animals and/or property, defects, labour on location, System. service calls, reinstallation or expenses involved shipping, packing or...

  • Page 4: Product Info

    2. Product info 3. Instructions PRODUCT INFO CONTROL FUNCTIONS To operate the tubular motor, you need a Forest remote control Power line with the Link protocol (EasyTouch line). Pairing Button Button EasyTouch Description/ function Module connection wire Antenna Opens the curtains...

  • Page 5: Get Started

    4. Get started TUBULAR MOTOR PAIRING BUTTON FUNCTIONS PAIRING MOTOR WITH FOREST EASYTOUCH REMOTE CONTROL Jogging 1: Pairing procedure after assembly Functions Paring button Note time Can only be used OPEN/STOP/CLOSE Short press when limits are already set. Select Remove...

  • Page 6: Settings

    5. Settings DIRECTION REVERSE UPPER & LOWER LIMITS SETTINGS The blind moves in the right direction. & Open or close Fix upper Hold Open Jog 2x Upper point + Fav for 2s limit set Roman Press Roman Press open goes up close goes down &...

  • Page 7: Adjusting Motor Speed

    ADJUSTING UPPER & LOWER LIMITS SETTING UP THE FAVOURITE FUNCTION The Favourite Function allows you to set a preferred Adjust Upper limit position that can be activated with a single press of a button. & Setting the Favourite Function Hold Open + Fav Jog 1x Open or Fix new upper...
  • Page 8 SWITCHING BETWEEN CONSTANT TOUCH MODE UNPAIR REMOTE CONTROLS AND ONE-TOUCH MODE Unpair a single remote control Once the end positions are set, the motor operates in Pairing Button one-touch mode (the curtain moves in a continuous motion). To switch to step-by-step mode, follow these steps: Press pairing Jog 1x...

  • Page 9: Installation & Connecting Bluetooth Module

    DOWNLOAD APP d. Find the added Bluetooth gateway on the “Forest Connect app” App, click “+” to add a subdevice, a. Search “Forest Connect” in the and then click “LED already blink”, the APP will app store or scan the QR-Code.

  • Page 10: Support & Technical Specification

    8. Support & Technical specification TECHNICAL SPECIFICATION Why isn’t the motor working? • Voltage 12Vdc • Power max. 9.6W • Check if you have paired a remote control. • Current max. 0.8A If your remote is not paired yet you need to pair •...
