  • Page 1 FOREST SHUTTLE® AC...
  • Page 2 Both wires brown and black of the power cable are connected to constant Live AC voltage. Blue wire is connected to Neutral, yellow/green wire to earth. The motor will respond to a Forest RF remote control, also to Touch Impulse (manual opening/closing the curtain) Wiring diagram: 2.
  • Page 3 → DIRECTLY AFTER STOPPING OF THE MOTOR (AT OPEN POSITION) THE YELLOW LED WILL LIGHT UP. NOW YOU CAN ADJUST THE OPEN POSITION TO DESIRED POSITION. → WAIT UNTIL THE YELLOW LED GOES OFF, THE END POSITIONS ARE NOW STORED INTO MEMORY. 3 │ Installing the Forest Shuttle AC...
  • Page 4 ⑤ The Shuttle AC can be connected in 2 ways: 1. Remote controlled mode: the Shuttle AC is connected to constant AC power to a socket. 2. Building automation mode: the Shuttle AC is controlled by building automation 4 │ Installing the Forest Shuttle AC...
  • Page 5 ⑥ Setting the end limits of the FOREST SHUTTLE® AC SETTING MOTOR DIRECTION AND CLOSE LIMIT FOR REMOTE CONTROLLED MODE: The Shuttle detects automatically the motor direction. By pulling the master carrier(s) towards closed position first, the Shuttle will automatically learn that motor direction. The master carrier will travel automatically towards the closed position.
  • Page 6 For resetting only the end limits: press button 4x. To confirm, press and hold once more for 4 seconds until the led blinks 3 times and goes OFF. When a Forest remote is programmed to the Shuttle®, the end limits can also be reset by pressing 5 times the P button and 5 times the STOP button on the remote.
  • Page 7 10 – 80% Maximum useable altitude above sea level: 2000m (6561ft.) Certification & Marking: CE Shuttle S 225mm 77mm 49mm Shuttle AC 305mm 77mm 49mm Shuttle M 270mm 77mm 49mm Shuttle L 305mm 77mm 49mm 7 │ Installing the Forest Shuttle AC...
  • Page 8 It is important for the safety of persons to follow these instructions. Save these instructions. Do not use the product for any other purpose than intended. In order for the Forest Shuttle® AC to function correct and safe, the complete curtain system must be assembled with original parts and devices of Forest Group Nederland B.V.
