  • Page 1 A MITEL PRODUCT GUIDE Mitel TA7102 Hardware Installation Guide 03/2023 58014904 REV00...
  • Page 2: Table Of Contents

    Installing the Unit on the Wall ..........................11 Connecting the Telephony Cables .........................12 Connecting the Mitel Unit Using a DHCP Server....................12 Connecting the Mitel Unit Using a Static IP address .....................13 Verifying the Installation .............................14 Cables ..................................14 FXS Connections (RJ-11) ............................14...
  • Page 3 Mitel TA7102 - Hardware Installation Guide Troubleshooting ..............................16 Locating the Product Serial Number ........................16 Troubleshooting ..............................16 Partial Reset ................................18 Performing a Partial Reset ..........................20 Factory Reset .................................21 Performing a Factory Reset ..........................21 Disabling the Rescue Interface ........................21 Standards Compliance and Disclaimers .........................22 Federal Communications Commission (FCC) Disclaimer ..................22...
  • Page 4: Safety Recommendations And Information

    300 V between conductors or is subject to lightning strikes. Warning: The Mitel unit must be installed on a circuit equipped with a breaker so that you can easily power the unit off if required. Warning: Hazardous network voltages might be present in WAN, LAN, Sync, and telephony port connectors regardless of whether power to the device is OFF or ON.
  • Page 5: General Safety Practices

    • bare skin. • Attach the ESD wrist strap end to an earth ground i.e. the grounding screw on the back of the Mitel unit or on an unpainted bare metal spot of a grounded equipment rack. Requirements Location Requirements To avoid premature aging of the unit, insure user security and facilitate access, upgrades and maintenance, the following guidelines must be followed.
  • Page 6: Wiring Guidelines

    Mitel TA7102 - Hardware Installation Guide Humidity lower than 85% and non-condensing Do not install the Mitel unit in a location exposed to direct sunlight or near stoves or radiators. Excessive • heat could damage the internal components. Unit should be positioned to be accessible for future upgrade, maintenance and troubleshooting and where •...
  • Page 7: Getting Started

    Mitel TA7102 - Hardware Installation Guide Getting Started Installation Check List Task Verified by Date Network information available and recorded in site log. Location requirements verified. Site power Voltage. Installation site pre-power check completed. Mounting tools and equipment available. Additional equipment available.
  • Page 8: Package Check List

    1 Printed flyer 1 Bumpon kit for desktop use Cleaning Instructions To clean a Mitel unit, wipe with a soft dry cloth. Caution: Do not use volatile liquids such as benzine and thinner as they can damage the unit's casing.
  • Page 9: Connectors And Indicators

    Connectors and Indicators LEDs Behavior Condition Ready Green, steady ON All lines are enabled (operational state) All lines are disabled (operational state) Blinking 1 cycle per 4 At least one line is enabled and at least one line is disabled (operational state) seconds, 75% duty In-Use Lines idled and unlocked...
  • Page 10: Switches

    Allows setting the unit to default (known) values. Refer to Reset/Default RESET/ DEFAULT Button Power External 12 Vdc 1.5 A power supply. Installing the Mitel Unit Before you start Warning: Before performing this procedure, you must first read and understand the Safety Recommendations listed in this document. Note: Note or take a picture of your unit's serial number before starting the installation, and place the card stickers of the cards not factory installed.
  • Page 11: Installing The Unit On A Flat Surface

    3. Connect the Telephony Interface Cables. Refer to Connecting the Telephony Cables Caution: To prevent damage to the Mitel unit, make sure to connect the cables to their proper location on the Mitel unit. 4. Connect the Ethernet Cables. Refer to:...
  • Page 12: Connecting The Telephony Cables

    1. Wear an ESD wrist strap, ensuring it makes good contact with your bare skin. 2. Attach the ESD wrist strap end to an earth ground (grounding screw on the back on the Mitel unit or unpainted bare metal spot of a grounded equipment rack).
  • Page 13: Connecting The Mitel Unit Using A Static Ip Address

    3. Make sure the circuit breakers of AC power sources used to power the Mitel unit are OFF. 4. Make sure the provided external Power Adaptor is connected to the DC connector of the Mitel unit and in an appropriate AC electrical outlet.
  • Page 14: Verifying The Installation

    Steps 1. Contact the Mitel unit via the Web Browser, or go to step 2 a) In your Web browser, enter the IP address used by your Mitel unit to communicate with the Web interface. If your computer is connected to the Ethernet port, commonly used to be connected to •...
  • Page 15: 10/100 Ethernet Connection (Rj-45)

    Category 5 cables can be used for 10/100 Base T-Connections. • It is possible to use either a crossover or a straight Ethernet cable as the Mitel units perform • automatic MDI/ MDIX detection, meaning that they adapt to the type of cables connected to them.
  • Page 16: Troubleshooting

    Problem Cause Unable to contact the Management Interface. Wrong Eth port used for the Network configuration (Mitel unit on the edge or in the LAN with or without a DHCP server). The card is broken. • Card does not appear in the Management Interface.
  • Page 17: Led Patterns

    Problem Cause Card appears in the Management interface, but The card is not configured properly. Refer to the cannot be used (For example, unable to make calls). Software Configuration Guide. • CLI service not activated in the configuration. Unable to contact the Management Interface via the Protocol used to contact the CLI not activated.
  • Page 18: Reset/Default Button

    The partial reset provides a way to contact the Mitel unit in a known and static state while keeping most of the configuration unchanged. A partial reset can be performed at the initial start-up of the Mitel unit or on a unit already in use where the...
  • Page 19 In both cases, the user can manage the Mitel unit through its Rescue interface, which is bound to the unit's WAN port (wan for the Mitel TA7102, and ETH1 for all other Mitel units). The IP address of the Rescue interface is 192.168.0.1 (IPv4) or an IPv6 Link Local address.. These connections give access to the Rescue Management Interface where the configuration of a new unit can be completed and where an existing configuration can be modified.
  • Page 20: Performing A Partial Reset

    Make sure the unit is connected to the WAN port, as the Rescue interface is bound to the unit's WAN port (wan for the Mitel TA7102, and ETH1 for all other Mitel units). The IP address of the Rescue interface is 192.168.0.1 (IPv4) or an IPv6 Link Local address.
  • Page 21: Factory Reset

    By default the Rescue interface is disabled. However, after a partial reset the rescue interface is enabled. IMPORTANT: The Rescue interface is bound to the unit's WAN port (wan for the Mitel TA7102, and ETH1 for all other Mitel units). The IP address of the Rescue interface is 192.168.0.1 (IPv4) or an IPv6 Link...
  • Page 22: Standards Compliance And Disclaimers

    Local address. Steps 1. Go to Management/Misc. 2. From the Network Interface drop-down menu, select the interface that will be used to manage the unit. IMPORTANT: If you keep the Rescue Interface selected, you will not be able to get into the management interface after disabling it.
  • Page 23: Supported Standards

    (2) this device must accept any interference • received, including interference that may cause undesired operation Supported Standards Note: The standards compliance of the Mitel units are printed on the same sticker as the product serial number. Category Specification • Agency approvals •...
  • Page 24: Disclaimers

    Declaration Of Conformity please contact Media5 at the above address. RoHS Declaration Of Compliance This Mitel unit is in compliance with the Council Directives 2011/65/EC on the restriction of the use of certain hazardous substances in electrical and electronic equipment.
  • Page 25 © Copyright 2023, Mitel Networks Corporation. All Rights Reserved. The Mitel word and logo are trademarks of Mitel Networks Corporation. Any reference to third party trademarks are for reference only and Mitel makes no representation of ownership of these marks.
