Quick start guide
(Canada version)
Technical specifications
Frequency control
Transmit frequency
Channels
LCD
Nominal effective range
Power requirements
CONFORMS TO
UL STD.
62368-1
CERTIFIED TO
CSA STD.
C22.2 NO.62368-1
Crystal controlled PLL synthesizer
Baby unit:2406 - 2475MHz
24
7'' Color LCD
(IPS 1200x800 pixels)
Maximum power allowed by FCC and IC. Actual operating range
may vary according to environmental conditions at the time of use.
Parent unit: 3.7V 5000mAh, 18.5Wh Lithium-ion battery
Baby unit power adapters: Output: 5V DC @ 1A
Parent unit power adapters: Output: 5V DC @ 2A
Full Color Pan and Tilt
For more support information
Specifications are subject to change without notice.
© 2024 VTech Technologies Canada Ltd. All rights reserved.
03/24. VM919-XHD_CA_QSG_V2.
VM919HD
VM919-2HD
HD Video Monitor
Advertisement
Table of Contents
Related Manuals for VTech VM919HD
Summary of Contents for VTech VM919HD
- Page 1 Baby unit power adapters: Output: 5V DC @ 1A Parent unit power adapters: Output: 5V DC @ 2A Specifications are subject to change without notice. CONFORMS TO © 2024 VTech Technologies Canada Ltd. All rights reserved. UL STD. 62368-1 CERTIFIED TO 03/24.
-
Page 2: Important Safety Instructions
To protect them from overheating, these openings must not be blocked This VTech product complies with all standards regarding by placing the product on a soft surface such as a bed, sofa electromagnetic fields (EMF). -
Page 3: What's In The Box
What’s in the box Quick start guide 1 set for VM919HD 2 sets for VM919-2HD Connect the baby monitor NOTES NOTE • The rechargeable battery in the parent unit is built-in. • Use only the power adapters supplied with this product. - Page 4 Connect the baby monitor (Cont’d) Charge the parent unit battery before use When you have connected and turned on the parent unit, the battery will be charged automatically. Notes NOTES NOTE • Before using the baby monitor for the first time, charge the parent unit battery for 12 hours.
-
Page 5: Positioning The Baby Monitor
Positioning the baby monitor > 3ft (1m) ≥ 3ft (1m) < 3ft (1m) Note NOTES NOTE • To avoid interference from other electronic devices, place your baby monitor at least 3 feet (1 meter) away from devices such as wireless routers, microwaves, mobile phones and computers. - Page 6 Basic operation - Parent unit Adjust speaker volume Zoom Press -VOL / VOL+ to adjust your parent unit Press to zoom in or out. speaker volume. It determines the volume of sound transmitted from your baby unit. Muted Talk to your baby via the baby unit Turn on/off the parent unit screen 1.
- Page 7 Press MENU to enter the menu, choose a Use the menu menu item, or save a setting. You can use Press to enter the menu, choose a MENU the parent unit for advanced settings or menu item, or save a setting. You can use operations, such as to play or stop the baby the parent unit for advanced settings or unit lullaby, or to adjust the baby unit sound...
-
Page 8: Overview - Baby Unit
Overview - Baby unit Microphone Antenna Camera lens Speaker Light sensor Power jack LED indicator Wall mount slots Infrared LEDs Pair button Power switch Need help? For operations and guides to help you using your video monitor, and for latest information and supports, go and check the online help topics and FAQs. -
Page 9: Main Menu Icons
Parent unit icons Main menu icons Main menu Monitoring mode (For VM919-2HD only) • Baby unit 1 in Single mode • Baby unit 2 in Single mode • Patrol mode • Split mode Melodies and soothing sounds Melodies and Soothing Sounds •... -
Page 10: General Settings
Main menu Temperature • Turn on/off Temperature Alert. Set the parent unit to beep whenever the room temperature detected by the baby unit falls outside of the set temperature range. • Select Minimum temperature for alert range. • Select Maximum temperature for alert range. -
Page 11: Status Icons
Status icons Current view status • The baby unit number that is being viewed when in: - Single CAM mode. - Patrol mode (* For VM919-2HD only). - Split mode (* For VM919-2HD only). Split mode (* For VM919-2HD only) Patrol mode (* For VM919-2HD only) Night vision feature is activated automatically. - Page 12 Sound Detection and Auto Wake UP Adjust sound detection sensitivity You can turn on Sound Detection Alert and adjust the Sound Sensitivity to detect sounds and turn on the parent unit while its screen is switched off or dimmed. When the baby unit detects sounds that exceed certain levels, the parent unit screen will turn on and the baby unit starts transmitting the sounds to the parent unit, and you can see and hear your baby.
-
Page 13: Motion Detection
Motion Detection Adjust motion detection sensitivity You can turn on Motion Alert and adjust the Motion Sensitivity to detect motions and turn on the parent unit while its screen is switched off or dimmed. When the baby unit’s camera detects motions that exceed certain levels, the parent unit screen will turn on and the baby unit starts transmitting the sounds to the parent unit, and you can see and hear your baby. -
Page 14: Dim Mode
Dim mode The dim mode helps save parent unit power. When your parent unit is not charging, the display will automatically dim after 5 minutes of inactivity if no keys are pressed or alerts are received from the baby unit. 5 minute inactivity Press any buttons For VM919-2HD only... - Page 15 Mount the baby unit on dry wall (optional) Notes NOTES NOTE • Check for reception strength and baby unit’s angle before drilling the holes. • The types of screws and anchors you need depend on the composition of the wall. You may need to purchase the screws and anchors separately to mount your baby units. 1.
-
Page 16: Frequently Asked Questions
Frequently asked questions Below are the questions most frequently asked about the baby monitor. Why does the Try the following (in the order listed) for common cure: baby monitor 1. Disconnect the power to the baby units and the parent unit. not respond 2. -
Page 17: Cable Management
The program provides a convenient alternative to placing used lithium-ion batteries into the trash or municipal waste, which may be illegal in your area. VTech’s participation makes it easy for you to drop off the spent battery at local retailers participating in the program or at ®... -
Page 18: Limited Warranty
Consumer for Products purchased and used in the United States of America and Canada. What will VTech do if the Product is not free from defects in materials and workmanship during the limited warranty period (“Materially Defective Product”)? During the limited warranty period, VTech’s authorized... -
Page 19: Other Limitations
Product under this limited warranty. Transportation, delivery or handling charges are prepaid. VTech assumes no risk for damage or loss of the Product in transit. If the Product failure is not covered by this limited warranty, or proof of purchase does not meet...
