Operator's Manual
Wet/Dry Vacuum
Manuel d'utilisation
Libro de Instrucciones
120V
READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure to read
this book prior to operating or attempting any service or maintenance procedure to your Clarke
machine could result in injury to you or to other personnel; damage to the machine or to other property
could occur as well. You must have training in the operation of this machine before using it. If your
operator(s) cannot read English, have this manual explained fully before attempting to operate this
machine.
All directions given in this book are as seen from the operator's position at the rear of the machine.
For new books write to: Clarke
®
, 2100 Highway 265, Springdale, Arkansas 72764.
Clarke
®
Form No. 70973A
3/05
Printed in the U.S.A.
Advertisement
Table of Contents
Related Manuals for Clarke CTV 7
Summary of Contents for Clarke CTV 7
- Page 1 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
-
Page 2: Table Of Contents
CTV 15 & 20 Tank Assembly Drawing and Parts List ..........34 CTV 15 & 20 Frame Assembly Drawing and Parts List ........... 35 CTV 7, 15 & 20 Squeegee Assembly Drawing ............36 Parts List ......................37 CTV 7, 15 & 20 Accessory Tools ................38 CTV 15 &... -
Page 3: Libro De Instrucciones
CTV 15 & 20 Gráfico del ensamblado del depósito y listado de piezas ........34 CTV 15 & 20 Gráfico del ensamblado del bastidor y listado de piezas ........35 CTV 7, 15 & 20 Gráfico del ensamblado de la escobilla de goma ..........36 Listado de piezas ......................37 CTV 7, 15 &... -
Page 4: Manuel D'utilisation
CTV 15 & 20 Schéma de l'assemblage du réservoir et Liste des pièces ........34 CTV 15 & 20 Schéma de l'assemblage du bâti et Liste des pièces ........... 35 CTV 7, 15 & 20 Schéma de l'assemblage de la racle ..............36 Liste des pièces ......................... 37 CTV 7, 15 &... -
Page 5: Important Safety Instructions
12. Do not use without dust bag and/or filters in place. Use the machine only with an undamaged filter element. 13. Turn off all controls before unplugging. 14. Use extra care when cleaning on stairs. 16. Connect to properly grounded outlet. See "Grounding Instructions". SAVE THESE INSTRUCTIONS Clarke ® Page Wet/Dry Vacuums Operator's Manual... - Page 6 Failure to read the Owner's Manual prior to operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
-
Page 7: Instrucciones De Seguridad
16. Conecte la máquina sólo con una caja de enchufe con puesta a tierra. Véase las "Instrucciones para la conexión". GUARDE CUIDADOSAMENTE ESTAS INSTRUCCIONES DE SEGURIDAD Clarke ® Page Wet/Dry Vacuums Operator's Manual... - Page 8 Compruebe cuidadosamente el estado de la máquina antes de cada utilización. Siga las instrucciones de utilización descritas en este libro. Use sólo accesorios Clarke. AVISO: Si no sigue las instrucciones de seguridad indicadas por los adhesivos, se pueden causar lesiones o daños materiales.
-
Page 9: Importantes Mesures De Securite
16. "Ne brancher qu'à une prise de courant avec mise à la terre. Voir les instructions visant la mise à la terre." CONSERVER CES INSTRUCTIONS Clarke ® Page Wet/Dry Vacuums Operator's Manual... - Page 10 Vérifier soigneusement l'état de la machine avant chaque utilisation. Respecter le mode d'utilisation figurant dans ce manuel. N'utiliser que des accessoires Clarke. AVERTISSEMENT: Le non-respect des consignes de sécurité signalées par les autocollants peut provoquer des blessures ou des dégâts matériels.
-
Page 11: Specifications And Accessories
(unit) 11754000 11754000 11754000 11754000 11754000 11754000 11754000 Clothe Filter Liner / Washable 61156103 61156103 61156103 61156103 61156103 61156103 61156103 Squeegee Floor Tool 70007035 70007035 Replacement Squeegee Blades 30292A 30292A Clarke ® Page -11- Wet/Dry Vacuums Operator's Manual... - Page 12 (unidad) Revestimiento interior filtro tela/ 61156103 61156103 61156103 61156103 61156103 61156103 61156103 Lavable Herramienta escobilla de goma 70007035 70007035 de piso Hojas de la escobilla --- 30292A 30292A de goma p/recambio ® Clarke Page -12- Wet/Dry Vacuums Operator's Manual...
-
Page 13: Caractéristiques Et Accessoires
11754000 11754000 11754000 11754000 11754000 11754000 permanents de filtrage (unité) Sac filtre vêtements/ Lavable 61156103 61156103 61156103 61156103 61156103 61156103 61156103 Outil sol racle 70007035 70007035 Lames racles de replacement 30292A 30292A Clarke ® Page -13- Wet/Dry Vacuums Operator's Manual... -
Page 14: Grounding Instructions
CAUTION: The operating instructions and the safety precautions contained therein must be observed when using appliances connected to the appliance plug socket of the machine. ® Clarke Page -14- Wet/Dry Vacuums Operator's Manual... -
Page 15: Instructions Pour La Mise À La Terre
être observées lors de este manual al usar artefactos conectodos al l'utillisation d'apparells connectés à la prise appareils de la machine. tomacorriente de la máquina. ® Clarke Page -15- Wet/Dry Vacuums Operator's Manual... -
Page 16: How To Assemble The Machine
On delivery, the accessories - are lying in the tank and must be removed before the machine is used for the first time. See figure 2 (figure is for CTV 7, but other units are similar). To assemble the machine, remove the machine top... -
Page 17: Comment Assembler La Machine
Voir figure usar la máquina por primera vez. Consulte la figura 2 2 (la figure se réfère au modèle CTV 7 mais les autres (la figura se refiere al modelo CTV 7, pero las otras unités sont similaires). -
Page 18: Machine Operation
3. Inspect the power cord and hoses for damage. WARNING: Inflammable liquids must not be picked up with the machine! Switching On The Machine (CTV 7, 15, 20) Turn the switch to position "I" . Switching On The Machine (CTV 7 AS) Two operating modes are possible. -
Page 19: Funcionamiento De La Máquina
AVERTISSEMENT: Les liquides inflammables ne Encendido de la máquina (CTV 7, 15, 20) doivent pas être aspirés avec la machine! Coloque el interruptor en la posición "I". Allumage de la machine (CTV 7, 15, 20) Encendido de la máquina (CTV 7 AS) - Page 20 After Finishing Work 1. Switch off the machine and pull the plug of the power cord out of the plug socket. 2. Wind up the power cord. ® Clarke Page -20- Wet/Dry Vacuums Operator's Manual...
-
Page 21: Instrucciones De Funcionamiento
1. Apague la máquina y desconecte el enchufe del 1. Éteignez la machine et retirez de la prise la fiche cable de energía del tomacorriente. du cordon d'alimentation. 2. Enrolle el cable de energía. 2. Enroulez le cordon d'alimentation. Clarke ® Page -21- Wet/Dry Vacuums Operator's Manual... -
Page 22: Maintenance And Repair
MAINTENANCE AND REPAIR CAUTION: Before cleaning and servicing the machine, always remove the power cord. Carry out only maintenance operations described in these operating instructions. Use only original Clarke spare parts. Figure 8 CAUTION: Do not make any technical modifications to the machine. Your safety... -
Page 23: Entretien Et Réparation
¡Puede techniques à la machine. Votre sécurité poner en peligro su seguridad! pourrait être compromise! Consulte al departamento de servico Clarke Pour tout autre travail d'entretien et de autorizado para cualquier otra tarea de réparation, veuilez contacter un service mantenimiento y reparación. -
Page 24: Troubleshooting
3. Nettoyez et replacez l'élément de filtrage. 3. L'élément de filtrage est bouché. Aucune force d'aspiration 1. Videz le réservoir. 1. Le réservoir est plein (le commutateur à pendant nettoyage flotteur refermant l'ouverture d'aspiration). humide. ® Clarke Page -24- Wet/Dry Vacuums Operator's Manual... -
Page 25: Recommended Spare Parts
Clarke ® CTV 7, 15 & 20 Recommended Spare Parts Part No. Description 60608 Caster 60610 Gasket, Vacuum 60867 Switch, Main Power 11754000 Filter, Permanent 21448070 Knob, Squeegee 26771800 Cord, Power 26771900 Cord, Power 27000410 Frame, Squeegee Weldment 27000411 Retainer, Squeegee Blade... - Page 26 Clarke ® CTV 7, 15 & 20 Repuestos recomendados Pieza N° Descripción 60608 Rolanda pivotante 60610 Junta, aspiradora 60867 Interruptor, Potencia principal 11754000 Filtro, Permanente 21448070 Perilla, Escobilla de goma 26771800 Cable, Energía 26771900 Cable, Energía 27000410 Bastidor, Soldadura escobilla de goma...
-
Page 27: Pièces Détachées Recommandées
® Clarke CTV 7, 15 & 20 Pièces détachées recommandées Pièce n° Description 60608 Roulette 60610 Joint d'étanchéité, Vide 60867 Commutateur, Alimentation secteur 11754000 Filtre, Permanent 21448070 Bouton, Racle 26771800 Cordon, Alimentation 26771900 Cordon, Alimentation 27000410 Bâti, Assemblage soudé de la racle... - Page 28 NOTES ® Clarke Page -28- Wet/Dry Vacuums Operator's Manual...
- Page 29 Wet/Dry Vacuum 120V Section II Parts and Service (70973A) ® Clarke Page -29- Wet/Dry Vacuums Operator's Manual...
-
Page 30: Ctv 15 & 20 Head Assembly Drawing
Clarke ® CTV 15 & 20 Head Assembly Drawing 3/05 ® Clarke Page -30- Wet/Dry Vacuums Operator's Manual... -
Page 31: Parts List
Clarke ® CTV 15 & 20 Head Assembly Parts List 3/05 Ref. Part No. Description Qty Qty Qty Qty Qty 60603000 Handle 60601000 Cover, Top 538423 Clamp 60604000 Housing, Upper 60867 Switch, Main Power 30001200 Foam, 20 x 60 60610200 Ring Distance... -
Page 32: Ctv 7 Assembly Drawing
® Clarke CTV 7 Assembly Drawing 8/02 ® Clarke Page -32- Wet/Dry Vacuums Operator's Manual... -
Page 33: Parts List
® Clarke CTV 7 Assembly Parts List 10/03 Ref. Part No. Description 11754000 Filter Element, P.P. 60606000 Float 60607000 Cage, Float` 61156103 Filter, Cloth 60910 Filter Bag, (pkg. of 5)` 2364 Cap Nut 2793 U-Disc 8.4 mm Zinc 90000136 Tank... -
Page 34: Ctv 15 & 20 Tank Assembly Drawing And Parts List
® Clarke CTV 15 & 20 Tank Assembly Drawing and Parts List 3/05 Ref. Part No. Description Qty Qty. 50170 Screw, 3.5 x 14 Screw, M8 x 12 53840A Tank, 20 Gallons 53841A Tank, 15 Gallons 30001507 Hose, Drain Assembly... -
Page 35: Ctv 15 & 20 Frame Assembly Drawing And Parts List
Clarke ® CTV 15 & 20 Frame Assembly Drawing and Parts List 3/05 Ref. Part No. Description Qty Qty 53843A Frame Weldment 70020032 Wheel 21532060 Retainer 70000145 Retainer, Cover 60608100 Caster Washer, M8.4 x 17 x 1.5 Nut, M8 Hex 43625 Handle Bar SQ. -
Page 36: Ctv 7, 15 & 20 Squeegee Assembly Drawing
® Clarke CTV 7, 15 & 20 Squeegee Assembly Drawing 9/04 17 16 2728 As needed Tank Tubular Frame Step Bracket FIGURE A ® Clarke Page -36- Wet/Dry Vacuums Operator's Manual... -
Page 37: Parts List
® Clarke CTV 7, 15 & 20 Squeegee Assembly (70007035) Parts List 9/04 Ref. Part No. Description 27000405 Pedal, Squeegee Lift 27000404 Support, Pedal Left 27000406 Support, Lift 30001508 Hose, Squeegee Screw, M6 x 1 x 40 Shoulder Hex 27000414... -
Page 38: Ctv 7, 15 & 20 Accessory Tools
® Clarke CTV 7, 15 & 20 Accessory Tools Drawing and Parts List 4/03 Repair Parts 70000219 Brush Strips for 11604703 70000220 Squeegee Blades for 7270 70000221 Wheel & Axles for 7270 & 11604703 30340A Squeegee Blades for 52851A 30341A... -
Page 39: Ctv 15 & 20 Electrical Schematic
® Clarke CTV 7, 15 & 20 Accessory Tools Drawing and Parts List 8/02 Clarke ® Page -39- Wet/Dry Vacuums Operator's Manual... -
Page 40: Ctv 7 Electrical Schematic
Clarke ® CTV 7-AS Electrical Schematic 8/02 ® Clarke Page -40- Wet/Dry Vacuums Operator's Manual... - Page 41 29815 John R. Gilwilly Industrial Estate (810) 544-6300 Penrith Cumbria CA11 9BN ® American Lincoln / Clarke, Marietta, Georgia 30066 +44 1768 868 995 1455 Canton Road (770) 973-5225 ALTO France S.A. Strasbourg B.P. 44, 4 Place d’Ostwald F-67036 Strasbourg...
- Page 42 (c). Clarke will repair the product and or replace any defective parts without charge within a reasonable time after receipt of the product. Clarke's liability under this warranty is limited to repair of the product and/or replacement of parts and is given to purchaser in lieu of all other remedies, including INCIDENTAL AND CONSEQUENTIAL DAMAGES.
