Summary of Contents for Supratech RONDEO
- Page 1 RONDEO PANEL MOUNTED AUTOMATIC SOAP DISPENSER INSTALLATION AND MAINTENANCE GUIDE INSTALLATION AND MAINTENANCE GUIDE...
- Page 2 The tradenames, trademarks, logos, and service marks presented in this document, including their design, are the property of SUPRATECH or other third parties and you are not permitted to use them...
- Page 3 T E C H N I C A L C H A R A C T E R I S T I C S L=5m L=1,5m L=0,86m Ø90 RONDEO RONDEO Ref. RES-37 Ref. RES-37P transformer battery box RES-37: 230/12v transformer...
-
Page 4: Check Contents
P A C K C O N T E N T S 1 X BODY AND FIXING ACCESSORIES 1 X QUICK-CONNECT FITTING 1 X PUMP ASSEMBLY WITH BOTTLE SUPPORT 2 X 3.5X1 1/4’’ SCREWS AND SOAP TANK 2 X M4X4 SCREWS RES-37P: RES-37: IP67 BATTERY... - Page 5 Thicker liquid soap flows slower and inhibits the pump valve, causing strain and damage. The pH level of all soaps used in SUPRATECH liquid soap dispensers should be between 6.5 and 8.5. Lower levels will cause corrosion of the metal dispenser and even the rubber and plastic components.
- Page 6 I N S T A L L A T I O N STEP 1 – PREPARATION Drill a hole (23-24 mm) at the desired location for the soap dispenser spout installation. Drill a small hole (2-3 mm) above the previous one for the anti-rotation pin. Remove the hexagonal nut and the disk 23-24 from the base of the soap dispenser...
-
Page 7: Step 3 - Connecting The Power Source
I N S T A L L A T I O N STEP 3 – CONNECTING THE POWER SOURCE Remove the protective sticker covering the sensor and move away from detection range. Connect the soap pump NOT CONNECTED PROPERLY - connector to the matching O-RING VISIBLE connector from the sensor. - Page 8 F I L L I N G T H E S O A P T A N K Unscrew the soap tank from the pump assembly. Fill the tank up to the top line. Insert the soap tank along with the tube back into the bottle support Screw the soap tank back...
- Page 9 S E T T I N G A D J U S T M E N T S If necessary, use the (optional) RES-38 remote control to adjust the soap dispenser’s settings. To use the remote control, hold it straight in front of the sensor, at a distance of about 10-15 cm.
- Page 10 M A I N T E N A N C E CARE AND CLEANING OF CHROME AND SPECIAL FINISHES DO NOT use steel wool or cleansing agents containing alcohol, acid, abrasives, or the like. Use of any prohibited cleaning or maintenance products or substances could damage the surface of the soap dispenser.
- Page 11 B A T T E R Y R E P L A C E M E N T When the battery weakens, the blue indicator light will blink at a constant rate when user’s hands are within the sensor range. The battery must be replaced within 2 weeks.
- Page 12 S P A R E P A R T S L I S T RONDEO screws and wall plugs kit S07210098 Detection kit S08002195 1 L soap tank S07100020 Transformer S06522042 Pump assembly S07222001 Bottle support S07120175 Add-ons: Remote control...
- Page 13 L I M I T E D W A R R A N T Y This soap dispenser is warranted for 2 years from the date of purchase. In the event of a defect during this period of regular use, SUPRATECH will, at its discretion, repair, provide a replacement part or product, or make appropriate adjustments.
-
Page 14: Troubleshooting
T R O U B L E S H O O T I N G PROBLEM INDICATOR CAUSE SOLUTION ILLUSTRATION Soap Continuous AUX connector The connectors should be dispensing discharge not fully inserted fully until the white NOT CONNECTED PROPERLY from the inserted. - Page 15 T R O U B L E S H O O T I N G PROBLEM INDICATOR CAUSE SOLUTION ILLUSTRATION Soap not Pump not AUX connector The connectors should be dispensing making not fully inserted fully until the white NOT CONNECTED PROPERLY sound when connected.
- Page 16 2, rue des Cyprès - 37240 Bossée - France Tel : (33)2 47 92 23 31 - Fax : (33)2 47 92 84 71 info@autosanit.com www.autosanit.com 01.2024...
