- Page 1 RONDEO PANEL-MOUNTED AUTOMATIC HAND DRYER INSTALLATION INSTALLATION MAINTENANCE MAINTENANCE GUIDE GUIDE...
- Page 2 The tradenames, trademarks, logos and service marks presented in this document, including their design, are the property of SUPRATECH or other third parties and you are not permitted to use them...
- Page 3 T E C H N I C A L C H A R A C T E R I S T I C S Ø60 Max 250 Operating voltage 220 - 240 V, 50/60 Hz, 6.1 - 6.7 A, 1.34 - 1.6 Kw Heater element 450 - 900 W (adjustable) Heater thermal...
- Page 4 P A C K C O N T E N T S 2 X CLAMPS 1 X HAND DRYER AND ATTACHMENT 1 X FLEXIBLE HOSE 1 X HAND DRYER UNIT 1 X ALLEN KEY 2.5 MM 1 X ALLEN KEY 3 MM 1 X POWER SUPPLY 1 X ALLEN KEY 7 MM CORD WITH PLUG...
- Page 5 G E N E R A L S A F E T Y I N F O R M A T I O N - Connect to a 230V earthed cable. Protect the equipment using a 30mA differential cut-off switch. - When connecting the unit to the power supply, the means of disconnection must be incorporated into the fixed wiring in accordance with local wiring regulations.
-
Page 6: Check Contents
P R E - I N S T A L L A T I O N CHECK CONTENTS Separate all parts from the packaging and check each item using the PACK CONTENTS section. Make sure all parts are accounted for before discarding any packaging material. -
Page 7: Step 2 - Installing The Motor Unit
I N S T A L L A T I O N STEP 1 – INSTALLING THE HAND DRYER SPOUT Ø 29-33 Cut a Ø29-33 mm hole in the wall at the desired location. Insert the hand dryer spout into the hole in the wall and secure the base from the rear using the nut and disk. - Page 8 I N S T A L L A T I O N BARE WIRE CONNECTION VARIANT - CABLE CHANGE PRESS Remove the Hepa filter cover by pressing through the hole on the clip. Remove the knob cover using a flat-head screwdriver. Remove screw using Allen key before removing the knob.
-
Page 9: Step 3 - Connecting The Power Source
I N S T A L L A T I O N STEP 3 - CONNECTING THE POWER SOURCE Before proceeding, check that no objects are in front of the sensor. OBJECT Remove the protective sticker and exit sensor range. Connect to power. - Page 10 S E T T I N G A D J U S T M E N T S DETECTION RANGE DELAYED STOP TEMPORARY OFF ACTIVATION TIME FUNCTION SECURITY STOP RESET SELF ADJUSTMENT MODE SETTING ADJUSTMENTS WITH THE (OPTIONAL) RES-31 REMOTE CONTROL The ideal detection range will be set automatically.
- Page 11 S E T T I N G A D J U S T M E N T S the detection range represents the optimum distance DETECTION RANGE at which a hand must be placed to trigger the system. Press the RANGE button. Wait for the blue LED to flash on the sensor. Then press (+) t o increase the range and (–) to decrease it.
- Page 12 M A I N T E N A N C E CARE AND CLEANING OF CHROME AND SPECIAL FINISHES: Regular cleaning of the hand dryer is recommended to ensure optimum performance. Access to the dryer must only be conducted when it is switched off. Ensure that the HEPA filter in the motor block is cleaned regularly, depending on the intensity of use.
-
Page 13: Troubleshooting
T R O U B L E S H O O T I N G PROBLEM INDICATOR CAUSE SOLUTION ILLUSTRATION The hand Continuous AUX connectror The connectors should dryer runs airflow not fully inserted. be inserted fully until the without white o-ring is no longer interruption visible. - Page 14 T R O U B L E S H O O T I N G PROBLEM INDICATOR CAUSE SOLUTION ILLUSTRATION Weak airflow Filter Ensure a 50 mm gap housing is below the filter outlet. obstructed. To access the filter, remove the Hepa filter cover by pressing through the hole on the clip.
- Page 15 L I M I T E D W A R R A N T Y This hand dryer is warranted for 3 years from the date of purchase. In the event of a defect during this period of regular use, SUPRATECH will, at its discretion, repair, provide a replacement part or product, or make appropriate adjustments.
