Summary of Contents for VTech VM352
- Page 1 VM352 Go to www.vtechphones.com to register your product for VM352-2 enhanced warranty support and Full Color Video Monitor the latest VTech product news. with Wide-Angle Lens User’s manual...
-
Page 2: What's In The Box
VTech product. For support, shopping, and everything new at VTech, visit our website at www.vtechphones.com. What’s in the box 1 set for VM352 2 sets for VM352-2 1 set for both VM352 and VM352-2... -
Page 3: Install The Battery
Install the battery The parent unit runs on rechargeable battery or AC power. To continuously monitor your baby, make sure you use both battery and AC power at the same time. With the battery alone, the parent unit can cordlessly run for a short time only. - Page 4 Connect and charge the battery NOTES • Use only the power adapters supplied with this product. • Make sure the electrical outlets are not controlled by wall switches. • The power adapters are intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if they are plugged into a ceiling, under-the-table or cabinet outlet.
- Page 5 Charge the parent unit battery When you have connected the parent unit and installed its battery for the first time or after power outage, the parent unit powers on automatically. The battery icon indicates the battery status (see the following table). NOTES •...
-
Page 6: Before Use
Before use NOTE • This baby monitor is intended as an aid. It is not a substitute for proper adult supervision, and should not be used as such. Test your baby monitor You may test the baby monitor before initial use, and at regular times thereafter. -
Page 7: Positioning The Baby Monitor
Positioning the baby monitor CAUTION • Keep the baby units out of the reach of your baby. Never place or mount the baby units inside the baby’s crib or playpen. NOTE • To avoid interference from other electronic devices, place your baby monitor far away from devices such as wireless routers, microwaves, cell phones and computers. -
Page 8: Operating Range
CAUTION • The default volume of your parent unit is level 4, and the maximum volume is level 7. If you experience high-pitched screeching noise from your baby monitor while positioning: Make sure your baby units and parent unit are more than 3 feet (1 meter) apart, OR Turn down the volume of your parent unit. -
Page 9: Baby Unit Overview
NOTES • When the lens is not in use, cover both sides of the lens with the lens covers provided to avoid scratches. • You can purchase and install an extra new wide-angle lens (VM101) onto your baby unit if necessary. - Page 10 Light sensor Camera Infrared LEDs ON/OFF light • On when the baby unit is turned on. • Flashes when the baby unit is not being viewed; or when the link to the parent unit is lost. Play/Stop • Press to play or stop lullaby on the baby unit.
-
Page 11: Parent Unit Overview
Parent unit overview LED lights • Indicate the different statuses of the parent unit. For details, refer to Parent unit lights. LCD Display • Press to increase the parent unit speaker volume. • Press to decrease the parent unit speaker volume. •... - Page 12 Microphone POWER • Press and hold to power on. • Press and hold again to power off. TALK • Press and hold to talk to the selected baby unit in Single CAM or Patrol mode. • While in a menu, press to return to the main menu or idle screen.
-
Page 13: Parent Unit Lights
Power jack Battery compartment cover Parent unit lights LINK • On when the parent unit is linked to the baby unit. • Flashes when the link to the baby unit being viewed in Single CAM or Patrol mode is lost; or when the link to at least one baby unit being viewed in Split mode is lost. - Page 14 Split mode. Patrol mode • Displays when the parent unit is in Patrol mode. • For VM352-2 only Split mode • Displays when the parent unit is in Split mode. • For VM352-2 only Night vision •...
-
Page 15: Parent Unit Main Menu Icons
Monitoring Mode If you have two baby units, you can select a monitoring mode (Single CAM, Patrol or Split). • For VM352-2 only Alert Tone You can set the parent unit to beep when • the parent unit operates in low battery condition;... -
Page 16: Parent Unit Display Messages
VOX Sensitivity With this feature, you can choose to hear sounds from the baby unit all the time, or to hear sounds that exceed a certain level. You can use the parent unit to adjust the microphone sensitivity of your baby unit. -
Page 17: Using The Baby Monitor
The battery level of the Battery low at parent unit is very low and Parent Unit needs to be recharged. Battery empty. The battery is empty and Powering off ... needs to be recharged. The sound level exceeds the threshold at CAM # in Sound Split mode. -
Page 18: Adjust Speaker Volume
• Press any keys on the parent unit to turn on the screen again. Adjust speaker volume To adjust parent unit speaker volume: • Press on the parent unit at any time when viewing images NOTE • When the parent unit speaker volume is set to zero, appears on the screen and the light... - Page 19 To play lullaby using the parent unit: You can play lullaby on the baby unit by controlling remotely with the parent unit. Press MENU when the parent unit is idle. to choose Lullaby on CAM, Press then press SELECT. to choose Play Melodies, Press then press SELECT.
-
Page 20: Set The Language
to choose Lullaby on CAM, Press then press SELECT. to choose Auto Timer, then Press press SELECT. Press to choose the desired lullabies duration, then press SELECT to confirm your selection. After 15/30/45/60 minutes, the lullaby or soothing sound will stop automatically. Set the language You can select a language (English, French or Spanish) to be used in all screen displays. -
Page 21: Adjust The Sound Sensitivity Of The Baby Unit
Adjust the sound sensitivity of the baby unit You can choose to hear sounds from the baby unit all the time, or to hear sounds that exceed a certain level. You can use the parent unit to adjust the microphone sensitivity of your baby unit. -
Page 22: Monitoring Mode
This depends on whether the baby unit detects any sounds. Monitoring mode for VM352-2 only Every time the parent unit is turned on, it displays a baby unit in Single CAM mode. If there are two baby units in your system, you can also monitor your baby in Patrol or Split mode. - Page 23 You can choose the desired monitoring mode. Press MENU when the parent unit is idle. to choose Monitoring Mode, Press then press SELECT. to choose Single CAM, Press Patrol or Split, then press SELECT. In Single CAM or Patrol mode: Press VIEW to view the next baby unit.
-
Page 24: Set Alert Tone
unit. Your voice is broadcast to the baby unit. Release TALK to stop the broadcast. The TALK light goes off. The speaker is then turned on for around 20 seconds, so you can hear your baby. NOTES • The parent unit speaker is muted during voice broadcast. -
Page 25: Monitor The Temperature
NOTES The sound alert feature is only available in Split • mode. Monitor the temperature Your baby unit monitors the temperature of your baby’s room with its built-in temperature sensor. If the detected temperature is outside of the preset temperature range, the parent unit will display alert message. -
Page 26: Night Vision
to choose Temperature, Press then press SELECT. to choose Format, then Press press SELECT. F or C, then Press to choose press SELECT to confirm your selection. Turn on or off the vibration You can turn on the vibration feature so that the parent unit vibrates when it receives any of these alerts (after turning on the respective alert tones):... -
Page 27: General Product Care
NOTES • It is normal if you see a short white glare on your parent unit screen as the baby unit is adapting to the dark environment. • When the infrared LEDs are on, the images are in black and white. This is normal. •... - Page 28 Why does the Try the following (in the order baby monitor listed) for common cure: not respond 1. Disconnect the power to the normally? baby units and the parent unit. 2. Remove the batteries in the parent unit. Then, install the batteries again.
-
Page 29: Important Safety Instructions
Why does the The baby units may be out of parent unit range. Move the parent unit beep? closer to the baby units (but not less than 3 feet). If the parent unit is powered by the provided battery, it may not have enough charge for the parent unit to perform normally. - Page 30 This product is not intended for use as a medical monitor. Do not use this product near water. For example, do not use it next to a bath tub, wash bowl, kitchen sink, laundry tub or swimming pool, or in a wet basement or shower.
- Page 31 dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used. You should test the sound reception every time you turn on the units or move one of the components. Periodically examine all components for damage. Be aware of possible loss of privacy while using public airwaves.
-
Page 32: Fcc And Ic Regulations
VTech product service centers. Please call ® 1 (800) 8 BATTERY for information on Li-ion battery recycling and disposal bans/restrictions in your area. VTech’s involvement in this program is part of its commitment to protecting our environment and conserving natural resources. ® ®... - Page 33 different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. WARNING: Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
-
Page 34: For Cetl Compliance Only
Your baby monitor is set up to comply with the energy- conserving standards right out of the box. Follow the instructions to install and charge the battery. The CEC battery charging testing mode is activated while charging. Even if the parent unit is paired to baby units, the CEC battery charging testing mode is activated while it is powered off and charging. -
Page 35: Limited Warranty
Consumer for Products purchased and used in the United States of America and Canada. What will VTech do if the Product is not free from defects in materials and workmanship during the limited warranty period (“Materially Defective Product”)? - Page 36 Product under this limited warranty. Transportation, delivery or handling charges are prepaid. VTech assumes no risk for damage or loss of the Product in transit. If the Product failure is not covered by this limited warra nty, or proof of...
-
Page 37: Technical Specifications
In no event shall VTech be liable for any indirect, special, incidental, consequential, or similar damages (including, but not limited to lost profits or revenue, inability to use...
