  • Page 1 Quick Installation Guide 300Mbps Wireless N Access Point TL-WA901ND MODEL NO.

  • Page 2: Package Contents

    Package Contents TL-WA901ND Power Adapter 300Mbps Wireless N Access Point TL-WA901ND MODEL NO. Ethernet Cable Resource CD System Requirement · Windows 8 · Windows 7 · Windows Vista · Windows XP · Mac OS · UNIX · Linux...
  • Page 3 Connecting the Device for Con g Connecting the Device for Con guration Connect to the Access Point with the Ethernet cable or via Connect to the Access Point with the Ethernet cable or via LED explan wireless. The default wireless network name (SSID) of the wireless.
  • Page 4 LED explanation: Status Indication Power off. Power on. The device has a system error. The device is initialising. Flashing The device is working properly. There is no device linked to the corresponding port. There is a device linked to the corresponding port but no activity.
  • Page 5 Con guring the Device Please make sure that your wired device’s IP address is set as O Please make sure that your wired device’s IP address is set as Obtain an IP address automatically before configuring the device. Open your web browser, type in http://tplinkap.net in the Then you will see the Start page shown as below.
  • Page 6 Then you will see the Start page shown as below. Select your region and click Next to continue. The Operation Mode page will appear then. The TL-WA901ND supports up to five operation modes. Please select the proper operation mode according to your needs and click Next.
  • Page 7 a) Access Point Mode Introduction In this mode, the product will act as a wireless central hub for your wireless LAN clients, giving a wireless extension for your current wired network. Wired Network Access Point Settings 1. Create an easy-to-remember name for your wireless network. 2.
  • Page 8 SSID:abc SSID:abc SSID:abc SSID:abc SSID:abc SSID:abc Repeater Settings 1. Select the repeater mode, Universal Repeater is recommended as for better compatibility. Click Survey. 2. The window displaying a list of available SSIDs will appear. 3. Find the SSID of the main Router/AP that you want to repeat, and then click Connect in the corresponding row.
  • Page 9 Con guring the Device (contin Con guring the Device (continued) c) Bridge with AP mode c) Bridge with AP mode Introduction Introduction In this mode, the product can wirelessly connect two or more In this mode, the product can wirelessly connect two or more remote LANs together.
  • Page 10 d) Client Mode Introduction In this mode, the product will act as a wireless adapter to connect your wired devices (eg. IPTV Set-top-box, Smart TVs, Game Consoles, DVD and Blu-ray Players, etc. ) to a wireless network. Client...
  • Page 11 Settings 1. Click Survey. 2. Find the SSID of the Access Point/Router or WISP, and click Connect in the corresponding row.You will then return to the previous page. 3. The security mode will be selected automatically, please confirm it and enter the password that is the same as on the main Router/AP.
  • Page 12 Settings 1. Select ON to enable VLAN function for this access point. 2. Configure the SSID and its corresponding VLAN ID. You can create up to 4 SSIDs and rename them. 3. Configure the wireless security for each SSID. 4. Click Next. For the configuration of VLAN, please refer to the User Guide on the Resource CD.
  • Page 13 The Network Setting page will appear then. It is recom- mended that you keep the default settings on this page. Click Next． For advanced configurations on this page, please refer to the User Guide on the Resource CD. After Network Settings, the Finish page will appear. Check your settings and click Save to save your settings on your desktop for future reference.

  • Page 14: Appendix 1: With Poe Setup

    1. Passive PoE Injector supports a maximum cable length up to 30 meters due to the environment. 2. For longer powered cable up to 100 meters, please choose TP-LINK's 48V PoE adapters: TL-POE200 or TL-POE150S & TL-POE10R. Product information can be found on our official website...

  • Page 15: Appendix 2: Troubleshooting

    3) Please make sure your hardware connection is OK. You can con rm this by the LAN LED on the front panel of TL-WA901ND. If the LED of the LAN port, which your Ethernet cable is connected to, is lighting green, your hardware connection is OK;...

  • Page 16: Technical Support

    Service time: From 10:00 to 18:00 (Moscow Service time: Monday to Friday, 09:00 to time) *Except weekends and holidays in 12:30 and 13:30 to 17:30. GMT+1 or Russian Federation GMT+2 (Daylight Saving Time in Germany) *Except bank holidays in Hesse www.tp-link.com TP-LINK TECHNOLOGIES CO., LTD.
