Samsung UH55F-E Quick Setup Manual

− The colour and the appearance may differ depending on the product, and the specifications are subject to change without prior
notice to improve the performance.
− Download the user manual from the website for further details.
http://www.samsung.com/displaysolutions
Checking the Components
(1) Quick Setup Guide (2) Warranty card (Not available in some locations) (3) Regulatory guide (4) Power cord
(5) Batteries (Not available in some locations) (6) Remote Control (7) DP cable (8) RS232C(IN) adapter
(9) Holder-Ring x 4 / Screw x 4
Contact the vendor where you purchased the product if any components are missing.
Components may differ in different locations.
External sensor KIT
Remote Control Sensor
1
Aim the remote control towards this spot on the LCD Display.
- Keep the area between the remote sensor and remote control obstacle-free.
Light sensor
2
Automatically detects the intensity of ambient light around a selected display and adjusts the screen brightness.
Power indicator
3
The power indicator will turn off when the product is turned on. It will blink in power-saving mode.
POWER button
4
Use this button for turning the LCD Display on and off.
SOURCE button
5
Switches from PC mode to Video mode. Selects the input source that an external device is connected to.
1
2
3
4
5
Quick Setup Guide
UH55F-E UM55H-E
BN68-08080P-01
POWER
